- Page 1 2- Leg Height Adjustable Desk ASSEMBLY & OPERATION MANUAL...
- Page 2 Technical Specification Height Range 620 - 840 mm (excluding desktop) Base Width 1005 -1600 mm Weight Capacity 100 kg Table Of Contents Parts & Components………………………………………………… Page 3 Explore Diagram………………………………………………………… Page 4 Assembly Instructions…………………………………………… Page 5-6 Operation Instructions……………………………………………… Page 7...
- Page 3 Parts & Components Tools Required Phillips Head Screwdriver 4 mm Allen Wrench (Include) and/or Power Drill Components Included Legs Feet Crossbar No.3 No.1 x2 No.2 x2 Side Plate Leveling Studs No.4 x2 No.5 x4 Hardware Frame System Machine Screws Machine Screws Rubber Pads M6X16 M6X10...
- Page 4 Components Diagram Description Legs Feet Crossbar Side Plate Leveling Studs Machine Screws M6x10 Machine Screws M6x16 Rubber Pad Wood Screws ST4x16...
- Page 5 Assembly Instruction BEFORE YOU BEGIN Lay out all components and hardware to ensure that you have all the parts listed on the parts page. Step 1 Extend the Crossbar("A") and assembly lift legs according "B" diagram. Assembly table feet via 8 M6x16 and 4 leveling studs.
- Page 6 Step 2 Assembly side plate via 4 M6x10. Step 3 Use 12 ST5x18 assembly desktop. Then tighten crossbar screw according "C" diagram.
- Page 7 Operation Instruction Turn screw to adjust height via screwdriver At the highest point, the column will have 9 holes on the outside.
