Item No.: 75.BUR.002
Technical data
3
100- 240V
Column Stage
Input Voltage
Max. Weight
125KG
Max Speed
38mm
Capacity
Height Range
600-1230mm
Temperature
0-4 0°C
Width Range
1100-1800mm
Certification
C E F CC CU L
Duty Cycle
10%, Max. 2 min on/ Min. 18 min off
Component list
No.
Part
Qty No.
Part
Qty
1
2
2
2
Left Lifting
Right Lifting
Column
Column
Qty No.
Qty
No.
Part
Part
3
2
4
4
Connecting Beam
Cover
Qty No.
Qty
No.
Part
Part
5
2
6
4
Supporting Beam
Side Bracket
No.
Part
Qty No.
Part
Qty
7
4
8
2
Control Box
Cable Management Tray
No.
Part
Qty No.
Part
Qty
Hand Switch
9
10
2
2
Power Plug
Qty No.
Qty
No.
Part
Part
11
12
4
12
Panel Fixed Base
Adhesive Pad
Installation guide
Accessory list
Attention: The drawings below are only for reference which might be slightly
different from the actual object, please in kind prevail. Any tools missing or
installation problems,please contact the customer service firstly.
No.
Allen Key
A
4x4mm
B
M6X16mm
C
M8X35mm
/
s
D
ST4.2x16mm
E
ST4.8x16mm
10
11
4
12
11
5
2
7
3
1
STEP 1
A
5x5
Spec
Qty
Allen Key
1
5x5mm
8
STEP 2
16
C
52
1
x16
A
10
A
C
5x5
Install the supporting beam(5) use 5*5
wrench(A) to tighten the screws(C).
8
6
STEP 3
9
1
A
4x4
2
10
Install the connecting beam(3) use
5*5 wrench(A) to tighten the screws.
3
1
Install the side bracket(6), and use
5*5 wrench(A) to tighten the screws(C).
2
5
6
Install the tabletop
D
2
x44
Loosen
Pull
Tighten
Tabletop
1
2
Install the connecting
beam(3)
2
3
Use 5*5 wrench(A)
to tighten the screws
A
6
C
D
Attach the adhesive pad
12
