Assembly diagram

1. Staged measuring surface
2. Inner measuring surface
3. LCD display
4. Safety screw
5. Button cell (1.5 V)
6. Battery lid
7. Slider
8. Protective cover
1 2 3
OFF
10
AFTER SALES SUPPORT 0800 / 328 6020
00800 / 4467 5888
GT-DC-02, 02/13, E45316
9. Depth bar
10. Outer measuring surface
11. Power on and off
switch (ON/OFF)
12. Zero gauge (ZERO)
13. Switch for metric / inches
(mm/inch)
14. Fine-tuning wheel
4 5 6 7 8 9
mm
ZERO
11 12 13 14
4
info@dariolondon.com

Safety instructions

• Injury hazard: The measuring edges are sharp and pointed!
Therefore, only hold the measuring device on the handles.
• Do not let children play with the measuring device. They can
injure themselves on the sharp measuring edges or swallow the
battery/battery compartment lid.
• Measure very carefully on sensitive surfaces, in order to avoid
leaving scratch marks.
• Do not connect any voltage to any part of the digital caliper
gauge (e.g. for engraving with an electric pen), as the switch
could otherwise be damaged.
• The digital caliper gauge is designed for private household use.
It is unsuitable for use in workshops, jewellery shops, etc.
