- Page 1 ULTRASONIC DISTANCE MEASURER Instruction Manual AFTER SALES SUPPORT: Telephone: 1800 269 981 E-mail: support@eurocentra.com.au...
-
Page 2: Table Of Contents
Contents Warranty details Introduction Proper use Safety advice Additional safety advice for lasers Disposal of device Ultrasonic Distance Measurer Battery instructions List of contens Description of parts / scope of delivery Warranty Details Operation Insert battery The product is guaranteed to be free from defects in workmanship and Displays parts for a period of 12 months (dependant on product) from the date Avoiding measurement errors... -
Page 3: Introduction
Introduction Proper use GT-UDM-02 We congratulate you on your new ultrasound distance measurer The electronic multi-measurement device deter- and are convinced that you will be satisfied with this state-of-the-art mines the distance of an object through electronically generated device. The device conforms to the relevant safety regulations. -
Page 4: Safety Advice
Safety advice Safety advice The electronic multi-measurement device GT-UDM-02 is a class II laser Take environmental influences into consideration! device and conforms with international safety guidelines 21CFR Do not expose the device to rain. Do not use the device in a damp 1040.10, 1040.11 and EN 60825-1:2007... -
Page 5: Additional Safety Advice For Lasers
Safety advice Safety advice eyes of another person. Do not look at the laser beam with binocu- Additional safety advice for lasers lars or a magnifying glass. Use the correct device! The proper use is described in these operating instructions. Caution! Laser beams! Warning! The use of attachment devices or accessories other than those recommended in these instructions or carrying out work with... -
Page 6: Disposal Of Device
Safety advice Safety advice Disposal of device • Avoid contact with skin, eyes and mucous membranes. Upon Please dispose of this product and battery responsibly at contact with battery acid, rinse the affected areas with plenty of end of life. Do not throw away with household waste. Please clear water and immediately call on a doctor. -
Page 7: Description Of Parts / Scope Of Delivery
Description of parts / scope of delivery Description of parts / scope of delivery 1. Ultrasound transmitter/receiver 10. Measurement reference --- The distance can be calculated from 2. Direction-finding laser the baseline or the top of the device. By pressing the BASE 3. -
Page 8: Operation
Operation Operation Insert battery Avoiding measurement errors Open the battery compartment cover on the Note the following points in order to avoid measurement errors: reverse of the device, pull the connector forward 1. Measurements through glass are not possible slightly and press the battery (9 V block battery, 2. -
Page 9: Distance Measurement
Operation Operation 9. Nearby additional ultrasound devices or high frequency sounds: Distance measurement switch off the source(s) of noise during measurement. • Keep the device loop in the direction of the measured object (e.g. the 10. With unfavourable measurement conditions: Temperature and humidity wall) and the device vertical to the measured object: by repositioning influence the precision of measurement –... -
Page 10: Addition (Without M+Storage)
Operation Operation Tips: READ • Press the button again in order to carry out a second mea- A. The measured object should have a hard surface and not be blocked by surement – the measurement value appears in the upper section of obstacles;... -
Page 11: Area
Operation Operation • Adding memory to last measurement result: Press for at least • The width symbol “W“ in the display flashes and shows the next READ 2 sec. until a double beeping tone sounds. “M” will disappear from the measurement to be carried out. -
Page 12: Area Addition In Area Mode
Operation Operation • Press the button – the sum of both areas appears in the bottom Area addition in the area mode: section of the display; MODE • Keep the button pressed down in order to save the calcu- lated area from the first measurement; at the same time, the “M+” symbol appears on the display. -
Page 13: Volume Addition In Volume Mode
Operation Operation • The width symbol “W“ in the display flashes to indicate the next Volume addition in the volume mode: measurement to be carried out. Press the READ button in order to MODE • Press the button in order to store the calculated volume measure the width, the result appears in the upper section of the from the first measurement –... -
Page 14: Temperature Display
Operation Operation Battery display • Press the button – the sum of both volumes will appear in the lower section of the display; Empty battery: Here, the symbol constantly appears in the display in order to remind you to change the battery. •... -
Page 15: Cleaning
Technical data The ultrasound distance measurement device is maintenance-free. Name Ultrasonic distance measurer Clean the device with a dry or slightly damp cloth. Type GT-UDM-02 Recommended use In enclosed spaces Storage Measurement range 0.6 to 16 m (2’ to 53’) - Page 16 AFTER SALES SUPPORT: AFTER SALES SUPPORT: Telephone: 1800 269 981 Telephone: 1800 269 981 E-mail: support@eurocentra.com.au E-mail: support@eurocentra.com.au...
