Fuji Electric FA Components & Systems Co., Ltd.
I n s t r u c t i o n M a n u a l
OPC-LM1-PS1
Option Card for Permanent
Magnet Synchronous Motor
Drive
CAUTION
■
Deliver this instruction manual without fail to
those who actually operate the equipment.
■
Read
this
instruction
understand the description before installing,
connecting (wiring), operating or performing
maintenance and inspection of the option.
■
Keep this instruction manual in a safe place
until the option is discarded.
■
The product is subject to change without
prior notice.
manual
and
INR-SI47-1182-E
Advertisement
Table of Contents
Related Manuals for Fuji Electric OPC-LM1-PS1
Summary of Contents for Fuji Electric OPC-LM1-PS1
- Page 1 (wiring), operating or performing maintenance and inspection of the option. ■ Keep this instruction manual in a safe place until the option is discarded. ■ The product is subject to change without prior notice. Fuji Electric FA Components & Systems Co., Ltd. INR-SI47-1182-E...
- Page 2 Preface Thank you for purchasing our OPC-LM1-PS1 inverter option card. Before using the option card, read this manual carefully to understand how to use the option card correctly. Improper handling blocks correct operation or causes a short life or breakdown. This manual does not describe how to use the inverter. Refer to the FRENIC-Lift Instruction Manual for details about the inverter.
-
Page 3: Table Of Contents
Contents Page General Information ..........................3 Introduction to OPC-LM1-PS1 .....................3 Applicable Inverter ROM Versions ....................3 Before Using the Option Card ......................3 Accessories..........................4 Installation Procedure ........................4 Product Guarantee........................6 Specifications ............................6 Storage Environment........................6 2.1.1 Temporary Storage........................6 2.1.2 Long-term Storage ........................6 Operating Environment ........................7 Terminal Arrangement ........................7... -
Page 4: General Information
(1) The option card is contained in the package. (2) The option card is not damaged during transportation--no defective electronic devices, dents or warps. (3) The model name "OPC-LM1-PS1" is printed on the option card. (See Figure 1.1.) Front View... -
Page 5: Accessories
Nameplate Production week in the month (1 to 6) Production month (1 to 9：January to September, X：October, Y：November, Z：December) Production year：Last digit of year (7 ⇒2007) Production lot serial number Figure 1.2 Nameplate 1.4 Accessories Confirm that the following accessories are included in the package: 1. - Page 6 【STEP2】 Option Card Insert the four spacers and CN1 on the back OPC-LM1-PS1 of the OPC-LM1-PS1 into the spacer holes and connector (CN1) on the control circuit board in the inverter. Option Terminal Block Visually check that the spacers and CN1 are firmly inserted.
-
Page 7: Product Guarantee
1.6 Product Guarantee The product guarantee term is one year after installation or two years after manufacturing on the nameplate, whichever expires first. However, the guarantee will not apply in the following cases, even if the guarantee term has not expired. (1) The cause includes incorrect usage or inappropriate repair or modification. -
Page 8: Operating Environment
2.2 Operating Environment Install the inverter in an environment that satisfies the requirements listed in Table 2.2. Table 2.2 Environment Requirements Item Specifications Location Indoors Ambient -10 to 45°C temperature Relative 5 to 95% (No condensation) humidity The option card must not be exposed to dust, direct sunlight, corrosive gases, flammable gas, oil mist, vapor or water drops. -
Page 9: Terminal Function And Specifications
2.4 Terminal Function and Specifications Table 2.4 Terminal Function and Electrical Specifications of OPC-LM1-PS1 Abbreviation Terminal name Terminal function Electric specifications Power supply for Terminal which supplies ・5 VDC±5%, Max. 300 mA encoder power for encoder ・5 VDC±5% Allowable wiring length. -
Page 10: Applicable Encoder
3 Applicable Encoder CAUTION • Check the encoder specification again before operating the inverter. Improper encoder specification may cause unexpected inverter operation or device operation. There is a risk of accident or injury. 3.1 Specifications of Applicable Encoder Table 3.1 Specifications of Applicable Encoder Item Specifications 2 sinusoidal signals A and B as sine and cosine with 2048 periods per... -
Page 11: Wiring
The encoder connection cable must use cable made by HEIDENHAIN 17 pin (4 x 0.14) +4(2 x 0.14) + (4 x 0.5) mm Connect 0.5 mm with PO and terminal CM of the option card. Table 4.2 Terminal Wiring of OPC-LM1-PS1 Terminal Wiring color... -
Page 12: Basic Wiring Diagram
Terminal Side. 4.3 Basic Wiring Diagram CAUTION • Keep the power supply voltage of encoder in the specification voltage of encoder. There is a risk of failure. L1/R L2/S L3/T FRN-LM1S OPC-LM1-PS1 Encoder User Controller Figure 4.1 Basic Wiring Diagram... -
Page 13: Function
5 Function 5.1 Function Code Setting CAUTION • Set the function code in the following order at first. (1) C21 (2) P01 (3) F03 (4) L31 (5)P02 Because when you change them, some other function codes synchronize and change. There is a risk of accident or injury. Set the function code as follows before beginning magnetic pole position offset tuning. - Page 14 3. Tuning procedure (1) Apply the brakes and fix the rotor. It is acceptable without the brake in the case of the tuning at the motor unit. (2) Confirm the motor is connected with the inverter. (3) If you use Multi Function Key Pad (MFKP), we recommend local mode. Keep pushing the "REM/LOC" key of MFKP until the indicator “REM”...
-
Page 15: Procedure Of Adjusting The Unbalanced Load Compensation
5.3 Procedure of Adjusting the Unbalanced Load Compensation 1. Procedure of control parameter setting Set the function code as follows. Code Name Data setting ACR P Constant 1.5 to 4.0 ACR I Constant 0.80 ms Unbalanced Load Compensation (Operation) 1 (Enable) Unbalanced Load Compensation (ASR P constant) 4.00 Unbalanced Load Compensation (ASR I constant) - Page 16 ⅰ) Using multistep speed command Reference speed (final) (= Actual speed) High speed Creep speed Time Release Brake Zero speed High speed Creep speed Zero speed command command command command : The time when real brake open. : The time when unbalanced load compensation control is finished. : The time when speed command switch "High speed command"...
