  • Page 1 English Version...

  • Page 3: Preface

    Preface Thank you for purchasing our SX-bus Communications Card OPC-G1-SX. Mounting this communications card on your FRENIC-MEGA allows you to connect the FRENIC-MEGA to a Fuji programmable logic controller MICREX-SX series via SX bus and control it as a slave unit using run and frequency commands, and accessing function codes.
  • Page 4 Installation and wiring • Before starting installation and wiring, turn OFF the power and wait at least five minutes for inverters with a capacity of 22 kW or below, or at least ten minutes for inverters with a capacity of 30 kW or above.
  • Page 5 Disposal • Treat the communications card as an industrial waste when disposing of it. Otherwise injuries could occur. Others • Never modify the communications card. Doing so could cause an electric shock or injuries. Icons The following icons are used throughout this manual. This icon indicates information which, if not heeded, can result in the product not operating to full efficiency, as well as information concerning incorrect operations and settings which can result in accidents.

  • Page 6: Table Of Contents

    Table of Contents Preface ..............1 Chapter 6 ESTABLISHING AN SX-BUS COMMUNICATIONS LINK ......15 Safety precautions ............1 Chapter 7 COMMUNICATIONS FORMAT ....... 21 Chapter 1 BEFORE USE ........... 5 Data Allocation in the SX-bus I/O Area of the Acceptance Inspection ..........

  • Page 7: Chapter 1 Before Use

    Chapter 1 BEFORE USE Acceptance Inspection Unpack the package and check the following: (1) A communications card, two screws (M3 8), and the SX-bus Communications Card Instruction Manual (this document) are contained in the package. (2) The communications card is not damaged during transportation--no defective parts, dents or warps. (3) The model name "OPC-G1-SX"...

  • Page 8: Chapter 2 Names And Functions

    Chapter 2 NAMES AND FUNCTIONS Parts Names Figure 2.1 shows the names of the parts on the SX-bus communications card. LED status indicators Screw hole (left) Release knob Model name Positioning cutout RSW1 RSW2 (Front) (Back) Screw hole (right) Station address switches SX-bus connector (OUT) SX-bus connector (IN) Figure 2.1 Names of Parts on SX-bus Communications Card...

  • Page 9: Led Status Indicators

    LED Status Indicators The communications card has two LED status indicators that indicate the operation status of the communications card as listed in Table 2.1. Table 2.1 LED Indicators and Operation Status LED (Color) LED state Meaning The SX-bus communications link is established. RUN (Green) (If the ERR LED is also ON, a light alarm has occurred.)

  • Page 10: Communications Card

    Chapter 3 INSTALLATION AND REMOVAL OF THIS COMMUNICATIONS CARD Before starting installation and wiring, turn OFF the power and wait at least five minutes for inverters with a capacity of 22 kW or below, or at least ten minutes for inverters with a capacity of 30 kW or above. Make sure that the LED monitor and charging lamp are turned OFF.

  • Page 11: Removing The Communications Card

    Fit the positioning cutout of the communications card over the tab on the inverter to determine the mounting position. Insert connector CN1 on the communications card into the corresponding port on the inverter's control PCB. Note: Be sure to follow the order of Inserting CN1 first may lead to insufficient insertion, resulting in a contact failure.

  • Page 12: Chapter 4 Wiring And Cabling

    Chapter 4 WIRING AND CABLING • Before starting installation and wiring, turn OFF the power and wait at least five minutes for inverters with a capacity of 22 kW or below, or at least ten minutes for inverters with a capacity of 30 kW or above. Make sure that the LED monitor and charging lamp are turned OFF.
  • Page 13 Figure 4.1 shows the basic connection diagram. When connecting the communications card to an SX bus, observe the following precautions. Precautions for SX bus connection (1) Be sure to use SX-bus dedicated cables. Model: NP1C-P3 (0.3 m) to NP1C-25 (25 m) For details about the cable specifications, refer to the MICREX-SX user's manual (Hardware version) which can be downloaded for free from our website at: http://www.fujielectric.com/...

  • Page 14: Wiring To Inverter

    Wiring to Inverter Route the SX-bus cables as far from the wiring of the main circuit as possible. Otherwise electric noise may cause malfunctions. Pass the SX-bus cables between the control circuit terminal block and the front cover. • For inverters with a capacity of 22 kW or below In the case of 0.4 kW •...

  • Page 15: Chapter 5 Configuring Inverter's Function Codes For Sx-Bus Communication

    Chapter 5 CONFIGURING INVERTER'S FUNCTION CODES FOR SX-BUS COMMUNICATION Inverter's Function Codes Before starting actual inverter operation, configure the inverter's function codes listed in Table 5.1. It is recommended to configure them before starting SX-bus communication, since an SX-bus network break could occur immediately after the start of communication.

  • Page 16: O31 Display Value

    o31 Display Value o31 displays the actual station address of the communications card which is currently assigned by the connected SX bus. The actual station address may be different from the one configured by the station address switches (RSW1 and RSW2 described in Section 2.2) since the SX bus has priority over those switches. Even writing any data to o31 from the keypad or via SX bus cannot change the actual station address or overwrite the o31 data with the written data.

  • Page 17: Communications Link

    Only Expert version 3.4.4.1 or later can define the SX-bus communications card. Choose Help|Info… from the menu bar on the top screen. Expert version 3.4.4.1 or later * * If your Expert version is earlier than 3.4.4.1, consult your Fuji Electric representative.
  • Page 18 (2) Adding a module In the project tree pane in Expert, double-click System_Definition under Physical Hardware. Double-click System_Definition. The system definition window appears as shown below. Right-click 11 slots Base: to display the pull-down menu and then choose Insert.
  • Page 19 The Module insert window appears. Select items as shown below and then click OK. The screen returns to the system definition window as shown below. Check that the inverter FRN-G1 is registered under the System structure in the system definition tree.
  • Page 20 (3) Configuring the I/O group Allocate the module (inverter) in the MICREX-SX CPU. Incorrect allocation of the I/O group disables input/output control from the CPU. In the system definition window, right-click CPU: to display the pull-down menu and then choose Properties..
  • Page 21 The CPU parameters window appears. Double-click the I/O group setting tab to display the window shown below. Click Standard setting, and the FRN-G1 is automatically allocated to the Input and Output. Note: In a multi-processor system, if an individual CPU module has a different control target, configure the I/O group for an individual CPU.
  • Page 22 (5) Configuring the station address switches (RSW1 and RSW2) on the communications card (Refer to Section 2.2). Before accessing the station address switches, make sure that the inverter power is OFF. Use the station address switches to configure the station address of the SX-bus communications card. The station address should be the one that has been registered by Expert.

  • Page 23: Chapter 7 Communications Format

    Chapter 7 COMMUNICATIONS FORMAT Data Allocation in the SX-bus I/O Area of the Communications Format (MSB) (LSB) %IW****.0 Function code group (1) polled Function code number (1) polled %IW****.1 Function code group (2) polled Function code number (2) polled %IW****.2 Data of function code (1) polled Inverter %IW****.3...

  • Page 24: Details Of Communications Format

    Details of Communications Format Standard format: o30 = 0 (factory default) Inverter MICREX-SX Word Function code group (1) polled Function code number (1) polled Function code group (2) polled Function code number (2) polled Data of function code (1) polled Data of function code (2) polled Empty (Fixed at 0) Empty (Fixed at 0)
  • Page 25 MICREX-SX Inverter Word Selecting function code group (1) Selecting function code number (1) Selecting function code group (2) Selecting function code number (2) Data of function code (1) selected Data of function code (2) selected Frequency command (100% = 20000 p.u.) REV FWD Polling function code group (1) Polling function code number (1)

  • Page 26: Configuring Inverter's Function Codes

    Configuring Inverter's Function Codes Configure a function code by specifying the function code group in upper 8 bits and the function code number in lower 8 bits as shown below. Function code number Function code group (see Table 7.1) Table 7.1 Function Code Group Conversion Table Function Code Group Code Function Code Name...

  • Page 27: Example Of Communication Data

    Example of Communication Data This section shows an example of communication data in the standard format (factory default). The example assumes that the maximum frequency is 60 Hz (F03 = 60) and the number of poles is 4 (P01 = 4). (1) Example of operation pattern Figure 7.1 shows an example of an inverter's operation pattern.
  • Page 28 Response: Running forward Commands: Arrived at the reference speed Run forward command Speed command 1800 r/min (= 2710h) IW****.0 00 00 QW****.8 00 00 IW****.1 00 00 QW****.9 00 00 IW****.2 00 00 QW****.10 00 00 IW****.3 00 00 QW****.11 00 00 IW****.4 00 00...

  • Page 29: Chapter 8 List Of Inverter Alarm Codes

    Chapter 8 LIST OF INVERTER ALARM CODES Through SX bus, the MICREX-SX can monitor the information on alarms that have occurred in the inverter. Their alarm codes are stored in the inverter's communication-dedicated function codes M16 to M19 (latest, last, 2nd last, and 3rd last alarm codes), as listed below.

  • Page 30: Chapter 9 Protective Functions

    Chapter 9 PROTECTIVE FUNCTIONS If the inverter judges that any error relating to the SX-bus communications card has occurred, it trips with displayed. If this happens, check the communications card following the instructions below. Option communications error (Communications card hardware error) ( Problem A communications error occurred between the SX-bus communications card and the inverter.

  • Page 31: Chapter 10 Specifications

    Chapter 10 SPECIFICATIONS 10.1 General Specifications Table 10.1 lists the environmental requirements for the inverter equipped with the communications card. For the items not covered in this section, the specifications of the inverter itself apply. Table 10.1 Environmental Requirements Item Specifications Site location Indoors...

  • Page 32: 10.2 Sx-Bus Specifications

    10.2 SX-bus Specifications Table 10.2 lists the SX-bus specifications for this communications card. For the items not covered in this section, the specifications of the SX bus apply. Table 10.2 SX-bus Specifications Item Specifications Name SX-bus communications card Model name OPC-G1-SX Applicable inverters FRENIC-MEGA series of inverters, ROM Ver.
  • Page 33 In no event will Fuji Electric Co., Ltd. be liable for any direct or indirect damages resulting from the application of the information in this manual.
  • Page 34 Fuji Electric Co., Ltd. Gate City Ohsaki, East Tower, 11-2, Osaki 1-chome, Shinagawa-ku, Tokyo, 141-0032, Japan Phone: +81 3 5435 7283 Fax: +81 3 5435 7425 URL http://www.fujielectric.co.jp/ URL http://www.fujielectric.com/ 2011-04 (D11b/G08) 1CM...
