- Page 1 Item #1000 848 294 Model #L-GZ513PST USE AND CARE GUIDE CHATHAM GAZEBO Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON WWW.HOMEDEPOT.CA...
- Page 2 Table of Contents Table of Contents ............2 Hardware Included ..............3 Safety Information ............2 Package Contents ..............4 Warranty ................. 2 Assembly ..............5-6 What is Covered ...............2 Care and Cleaning ............7 What is Not Covered ..............2 Pre-Assembly ..............3 Planning Assembly ..............3 Safety Information DANGER: This unit is heavy! Do not assemble this item...
- Page 3 Pre-Assembly PLANNING ASSEMBLY Before beginning assembly of this product, make sure all parts are present. Compare parts with the Hardware Included and Package Contents lists. If any part is missing or damaged, do not attempt to assemble the product. Contact customer service for replacement parts..
- Page 4 Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Upper post Base Lower post Beam connector Long support Top connector Short support Small canopy Top short beam Big canopy Top long beam Mosquito netting...
- Page 5 Assembly Assembling the top beam and Assembling the support canopies □ □ Insert long supports (C) into both ends of each short support (D). Insert the small end of the top short beams (E) into top long Then insert the other end of the long supports (C) into the tube beams (F), then insert the top long beams (F) into three of the of beam connector (H), creating 90°...
- Page 6 Assembly (continued) Completing the assembly □ Unfold the big canopy (K) and tie the gazebo with rope (BB) and secure them using the big stakes (CC). Hang the mosquito netting (L) on the beams (C and D) using rings (DD)
- Page 7 Care and Cleaning □ Before using, clean the gazebo completely with a soft dry towel. □ Do not put your gazebo in wet conditions where there is a risk of rust developing. □ When not in use, store in a cool, dry area. WWW.HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance.
- Page 8 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON WWW.HOMEDEPOT.CA Retain this manual for future use.
