Item #1000 683 167
Model #L-GZ747PST-A
USE AND CARE GUIDE
LANSING GAZEBO
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 6 p.m., EST, Monday-Friday
1-877-527-0313
WWW.HOMEDEPOT.CA
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this gazebo. We strive to continually create quality
products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for
choosing Hampton Bay!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L-GZ747PST-A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HAMPTON BAY L-GZ747PST-A

  • Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this gazebo. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for...
  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............2 Hardware Included ..............3 Safety Information ............2 Package Contents ..............4 Warranty ................. 2 Assembly ..............5-7 What is Covered ...............2 Care and Cleaning ............8 What is Not Covered ..............2 Pre-Assembly ..............3 Planning Assembly ..............3 Safety Information DANGER: This unit is heavy! Do not assemble this item...
  • Page 3: Pre-Assembly

    Pre-Assembly PLANNING ASSEMBLY Before beginning assembly of this product, make sure all parts are present. Compare parts with the Hardware Included and Package Contents lists. If any part is missing or damaged, do not attempt to assemble the product. Contact customer service for replacement parts.
  • Page 4: Package Contents

    Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Screen 1 Screen 2 Beam 1 Beam 2 Shelf Connector Big canopy Beam Lower tube Middle beam Top connector Mosquito netting Hook Small canopy...
  • Page 5: Assembly

    Assembly (continued) Assembling the beams Assembling the screens Insert beam 1 (B1) into beam 2 (B2) and secure together using Attach screen 2 (A2) to screen 1(A1) using bolts (DD) flat bolts (AA) and flat washers (BB). Repeat for each beam 1 (B1) washers (BB).
  • Page 6: Big Canopy

    Assembly (continued) Connecting the lower tubes to the Attaching the top connector screens Insert the lower tubes (G) into the screens (A1 and A2). Insert the assembled beam (F) into the small connector tube of the top connector (I). Then install the hook (K) to the top connector (I).
  • Page 7: Assembly

    Assembly (continued) Attaching the small canopy Attaching the shelves Assemble the four corners of the small canopy (L), then unfold Put the shelves (C) on the lower beams of the screens (A1 and the big canopy. A2). NOTE: To avoid destroying the finish, please handle it with care.
  • Page 8: Care And Cleaning

    Care and Cleaning Before using, clean the gazebo completely with a soft dry towel. Do not put your gazebo in wet conditions where there is a risk of rust developing. When not in use, store in a cool, dry area.
  • Page 9 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 6 p.m., EST, Monday-Friday 1-877-527-0313 WWW.HOMEDEPOT.CA Retain this manual for future use.
