DHP Futon 2388479 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Weight Limit: 600 Lb / 272 Kg
A.N. - 2020/3/25
2014 Dorel Home Products All Rights Reserved
2388479(Gray Velvet), 2388979(Green Velvet)
Thank you for purchasing from DHP!
DO NOT RETURN TO THE STORE !
If parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Visit www.dhpfurniture.com/eng/replacement-parts
or call Toll-Free 1-800-267-1739
Date of Purchase
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Futon
Lot Number
(TAKEN FROM CARTON)
B34238897900
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Futon 2388479 and is the answer not in the manual?

Questions and answers

Related Manuals for DHP Futon 2388479

Summary of Contents for DHP Futon 2388479

  • Page 1 2388479(Gray Velvet), 2388979(Green Velvet) Futon Weight Limit: 600 Lb / 272 Kg Thank you for purchasing from DHP! DO NOT RETURN TO THE STORE ! If parts are missing or damaged, we will gladly ship your replacement parts free of charge.

  • Page 2: Limited 1-Year Warranty

    Limited 1 year Warranty Read Before Beginning Assembly DHP warrants this product to be free from defects in material and workmanship Work in a spacious area and near where the unit will be used, preferably on a and agrees to remedy any such defect. This warranty covers one year from the carpet, or use a piece of the cardboard packaging to protect your floor and product.
  • Page 3 Assembled View For Futon...
  • Page 4 PARTS LIST - BOX 1/2 Legs and Hardware inside Legs and Hardware inside Seat 1 PC 1 PC 1 PC Legs and Hardware are packed inside Seat A. Bracket Bracket Middle Leg 2 PCS 4 PCS 2 PCS 1 PC IMPORTANT: Each part has unique part number.
  • Page 5 PARTS LIST - BOX 2/2 1 PC 1 PC IMPORTANT: Each part has unique part number. Please reference the appropriate part number when contacting customer service for replacement parts. Before throwing any packaging, please verify all contents and make sure you have received all the parts listed above! 2388479 2388979 PART...

  • Page 6: Hardware List

    HARDWARE LIST M6 X 6mm 5/16" X 4 3/4" 5/16" X 9/10" 5/16" X 1 11/20" 5/16" X 2 3/4" Washer Spring Washer X 20 X 20 Plastic Washer Allen Key 4mm Allen Key 5mm Hardware Pack Please do not completely tighten all the hardware, until the entire assembly is complete, unless Hardware Pack #: T2259679-00 otherwise indicated in the step-by-step instructions.
  • Page 7 Step 1 Attach H x 2 to D & E with as shown.
  • Page 8 Step 2 Hand tighten into B & C, as shown. 3 49/64" 95mm Note: Only screw in the 13/64" shortest threaded part of the Bolts. 20mm 25/32"...
  • Page 9 Step 3 Attach D & E to A with  as shown.
  • Page 10 Step 4 Attach I to D & E with  as shown.
  • Page 11 Step 5 Attach B & C to A with  as shown.
  • Page 12 Step 6 Attach H x 2 to B & C with  as shown.
  • Page 13 Step 7 Please remove the protective cap on the tip of thread before assembling. 7.1 Manually screw F x 4 to B & C with 7.2 Attach G x 2 to A with , as shown.

  • Page 14: Helpful Hints

    Bed. Move your new furniture carefully, with two people lifting and carrying the unit to its new location. Your DHP furniture can be disassembled and reassembled to move. Clean the product with a soft damp cloth. DO NOT use harsh chemicals or abrasive cleaners.
  • Page 15 SEGURIDAD. POR FAVOR LEA Y GUARDE PARA SU REFERENCIA FUTURA. Lea antes de comenzar a ensamblar Gracias por tu compra DHP! Llame a nuestro n mero gratuito si necesita asistencia. Trabaje en un rea espaciosa y cerca de donde su producto ser utilizado,...
  • Page 16 Partes Paquete de componentes Paquete #: T2259679-00 Piezas de reemplazo, visite www.dhpfurniture.com/spa/replacement-parts Nota: Por favor no apriete completamente los pernos hasta que el Todo se incluye en 2 caja(s) grande(s)! ensamblaje sea completado, a menos de que se indique espec ficamente en Las piezas nombradas abajo est n en la Caja A.
  • Page 17 Apriete a mano en B y C. levantar y trasladar su mueble a su nueva ubicaci n. Sus muebles DHP se pueden desmontar y volver a ensamblar en caso de Paso 3 mudanza. Una D & E con A usando , como se muestra a continuaci n.
  • Page 18 Travaillez dans un endroit spacieux et pr s du lieu o l'unit sera utilis e, DHP garantit que ce produit est exempt de tout vice de mat riaux et de fabrication pr f rablement sur un tapis, ou sur un morceau de l'emballage, afin de...
  • Page 19 Pi ces Quincaillerie Pour des pi ces de rechange, visitez www.dhpfurniture.com/fre/replacement-parts # de paquet : T2259679-00 IMPORTANT: La liste des r f rences ci-dessous est propre votre produit. Remarque: Sauf indication contraire dans les instructions, ne pas resserrer Veuillez l'avoir sous la main lorsque vous appelez pour des pi ces de rechange. compl tement les vis et les boulons, jusqu' ce que l'assemblage soit Tout dans 2 grande(s) bo te(s)! termin .

  • Page 20: Conseils Utiles

    B et C, comme montr ci-dessous. personnes pour soulever et transporter le mobilier vers son nouvel emplacement. Votre mobilier DHP peut tre d mont et reassembl pour faciliter les tape 3 d m nagements.
