Weight Limit:600 Lb / 272 Kg
Image is not an exact representation of the arms/mattress.
X.P. - 2016.03.09
© 2014 Dorel Home Products All Rights Reserved
Thank you for purchasing from DHP!
DO NOT RETURN TO THE STORE !
If parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Visit www.dhpfurniture.com/eng/support-home
or call Toll-Free 1-800-267-1739
Date of Purchase
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
FF2104259
Wood Arm Futon
Lot Number
B34FF210425900 - 10125 - M
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FF2104259 and is the answer not in the manual?

Questions and answers

Related Manuals for DHP FF2104259

Summary of Contents for DHP FF2104259

  • Page 1 FF2104259 Wood Arm Futon Thank you for purchasing from DHP! Weight Limit:600 Lb / 272 Kg DO NOT RETURN TO THE STORE ! If parts are missing or damaged, we will gladly ship your replacement parts free of charge. Visit www.dhpfurniture.com/eng/support-home...

  • Page 2: Warranty Information

    ● Call our toll free number if you need assistance. DHP warrants this product to be free from defects in material and workmanship and ● Work in a spacious area and near where the unit will be used, preferably on a agrees to remedy any such defect.
  • Page 3 B34FF210425900...
  • Page 4 Parts Replacement Parts, Visit www.dhpfurniture.com/eng/support-home All in 1 big box! There are inner box(es) that include components required to complete this assembly. Mesh Frame Mesh Frame Brace Frame Connector Before you throw the package, please use the T617480 T617490 T612370 T612300 Check Box to identify the parts and ensure that you have all the parts needed for the assembly.
  • Page 5 Parts Replacement Parts, Visit www.dhpfurniture.com/eng/support-home All in 1 big box! Arm Brace Arm Brace Mechanism Mechanism There are inner box(es) that include components T601680 T601670 T612380 T612390 required to complete this assembly. Before you throw the package, please use the Check Box to identify the parts and ensure that you have all the parts needed for the assembly.

  • Page 6: Hardware Pack

    Hardware Pack Hardware Pack #: T2104259W-01 #8 X 14mm #10 X 15mm 1/4" X 9/16" X 20 1/4" X 3/4" X 12 1/4" X 1 5/16" 1/4" X 1 7/8" 5/16" X 2 3/4" X 12 Hardware Note: Please do not completely tighten all the hardware, until the entire assembly is complete, unless 1/4"...
  • Page 7 Step 1 Attach (L) to (B), then attach (R) to (C) with BOLTS 5 & NUTS 8. The top of Mechanisms (L) & (R) may look different due to the movable joints. Please determine the orientation based on their bottom sides. B34FF210425900...
  • Page 8 Step 2 Attach (B) to (A), then attach (C) to (A') with BOLTS 1 & NUTS 9; Then secure them with SCREWS 6. B34FF210425900...
  • Page 9 Step 3 Insert (H) to (G) then secure with SCREWS Repeat the same actions to join another Rail. B34FF210425900...
  • Page 10 Step 4 Attach (D) to (Z) with BOLTS 4. B34FF210425900...
  • Page 11 Step 5 Attach (G) to (A) & (A') with BOLTS 1 and NUTS 9. B34FF210425900...
  • Page 12 Step 6 Attach (Z) to (H) with BOLTS 2 & NUTS 8. B34FF210425900...
  • Page 13 Step 7 7.1 Insert (E) X 2 to (O) & (P), then secure with SCREWS 7; 7.2 Attach (Q) to (O & P) with BOLTS 4. B34FF210425900...
  • Page 14 Step 8 Repeat Step 7 to assemble the rest (O), (P) & (Q). B34FF210425900...
  • Page 15 Step 9 Attach (O) to (L) then (P) to (R) with BOLTS 3 & NUTS 8. B34FF210425900...
  • Page 16 Step 10 Lift the Seat Frame to the position shown. B34FF210425900...
  • Page 17 Step 11 Attach (O) to (R) then (P) to (L) with BOLTS 3 & NUTS 8. B34FF210425900...
  • Page 18 Step 12 Hook (O) with (P) using (T) X 3. B34FF210425900...
  • Page 19 Step 13 Attach (S) X 2 to (O & P) with SCREWS 7 as shown. B34FF210425900...
  • Page 20 Step 14 Stick PADS 10 to the locations as shown. B34FF210425900...
  • Page 21 Step 15 Stick PADS 10 on the front side. B34FF210425900...
  • Page 22 Step 16 Cetain models come with a Frame Cover. If it is the case for you, then please slide the Frame Cover to cover the Seat Frame then close with velcro. B34FF210425900...
  • Page 23 Step 17 You can switch the status of your futon as shown. Please note that the futon will be easier to transfer without the Mattress on the frame. B34FF210425900...

  • Page 24: Helpful Hints

    ● Move your new furniture carefully, with two people lifting and carrying the unit to its new location. ● Your DHP furniture can be disassembled and reassembled to move. ● Some parts have been pre-assembled for this item. They are illustrated on this page and available for replacement.
  • Page 25 Garantía Gracias por su compra DHP! DHP garantiza que este producto está libre de defectos de material y de fabricación, comprometiéndose a corregirlos en caso de ser hallados. Esta garantía es valida por Registra tu producto y participa para ganar! un año a partir de la fecha de compra original.
  • Page 26 Partes Lea antes de comenzar a ensamblar ● Llame a nuestro número gratuito si necesita asistencia. Piezas de reemplazo, visite www.dhpfurniture.com/spa/support-home ● Trabaje en un área espaciosa y cerca de donde su producto será utilizado, preferiblemente sobre una alfombra o utilice el cartón del empaque para proteger su Todo se incluye en 1 caja grande! piso y su producto.

  • Page 27: Consejos Útiles

    ● Mueva sus muebles nuevos con cuidado, con dos personas levantando y llevando el aparato a su nueva ubicación. Paso 8 ● Sus muebles DHP se pueden desmontar y volver a ensamblar en caso de Repita el paso 7 para ensamblar las otras partes (O), (P) & (Q). mudanza.

  • Page 28: Garantie

    Garantie Merci d'avoir acheté un produit de DHP ! DHP garantit que ce produit est exempt de tout vice de matériaux et de fabrication et Enregistrez votre produit et s'engage à remédier à un tel défaut. Cette garantie couvre un an à compter de la date d'achat originale.

  • Page 29: Avant De Commencer L'assemblage

    Avant de commencer l'assemblage Pièces ● Si vous avez besoin d'aide, appelez notre service à la clientèle sans frais. Pièces de rechange, visitez www.dhpfurniture/fre/support-home ● Travailler dans un endroit spacieux et près du lieu où l'unité sera utilisée, préférablement sur un tapis, ou sur un morceau de l'emballage pour protéger le Tout dans 1 grosse boîte! plancher et le produit.

  • Page 30: Conseils Utiles

    ● Déplacez votre nouveau mobilier avec soin, nous recommandons deux 7.2 Fixer (Q) au (O & P) avec BOULONS 4. personnes pour soulever et transporter le mobilier vers son nouvel emplacement. ● Votre mobilier DHP peut être démonté et reassemblé pour faciliter les Étape 8 déménagements.
