Terminal Connections - M-system R7F4HEIP-DC16B Instruction Manual

TERMINAL CONNECTIONS

Connect the unit as in the diagram below.
■ EXTERNAL DIMENSIONS unit: mm [inch]
■ CONNECTION DIAGRAM
Note: In order to improve EMC performance, bond the FE terminal to ground.
Caution: FE terminal is NOT a protective conductor terminal.
*1
EtherNet/IP RJ-45 MODULAR JACK
*1
EtherNet/IP RJ-45 MODULAR JACK
4
24V DC
5
0V
1
FE
*1. The network cable can be connected to either one.
138 [5.43]
123 [4.84]
115 [4.53]
3 +24V1
4 GND1
OUTPUT Y0
Y0
2
+24V1
25
GND1
26
OUTPUT Y7
Y7
24
+24V1
1
GND1
14
29 +24V2
GND2
30
OUTPUT Y8
Y8
28
+24V2
51
GND2
52
OUTPUT Y15
50 Y15
+24V2
27
40 GND2
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
2‑4.3 dia. 4 deep.
EXC. SUPPLY (IN)
EXC. SUPPLY (IN)
R7F4HEIP-DC16B
72 [2.83]
55 [2.17]
DIN rail
(35mm wide)
(4 [.16])
EM-8005-C P. 5 / 7
