Workflow: Create a Juggler System

Workflow: Create a Juggler System
Configure the Connections: physical
1. Unbox Jugglers and perform an all-round physical check for any signs of transit damage.
2. Rack the Jugglers so that the units are fully supported at the back and bolted securely at the
front.
3. Connect power, press the front panel power button, and confirm that each unit comes to life.
4. The front panel will go through an initialising routine and settle to show an IP address for the unit
and the Juggler logo.
5. Reassign IP addresses
6. Switch off all units.
7. Connect any data bus
8. Connect all input devices available at this stage, and required output devices.
9. Switch on or boot all the components of your system. You may find it best to establish your own
preferred order, for example projectors first, working back through devices that take most time to
boot up.
Configure the Connections: Compere Juggler view
Ø
See Terms and Definitions Used in Compere
The precise sequence will depend on the requirements of the overall system of Juggler modules, but
this outline gives you the sequence of steps.
Assemble your Compere group
1. With Compere installed on a
2. Open Compere and make sure it is in
Network Configuration
3. In Network Configuration, ensure that all the devices running Compere that are involved in your
Project, belong to the same
4. Assign one member (Juggler) of the Project Group (any) as server, with a binding NIC, and all the
rest as clients.
5. All Jugglers in the same Project Group as you as the Control PC, will now be visible in the Project
panel on the left of the Compere screen.
6. Drag each of these Jugglers from the Project Panel into the
arrange.
7. Connect the bus nodes between the Jugglers
M512-3 Juggler : User Guide
for each Juggler as required.
14
or buses between Jugglers that will combine to form a system.
26
37
remote ('control') PC
Juggler View
68 . You should see all Jugglers and any other devices running Compere.
Project Group . Create your Project Group(s) here as necessary.
75
103
, log into the network.
35
38 (top left icon), go to Configuration >
Nodes assembly panel
in Compere.
24
and
94
