Manual:
CSP−HMI−2, Handbook of Maintenance Instructions
Models:
369D/E/FF − 500/600N Helicopters
Issued:
31 October 1990
Revision 39:
10 April 2007
FILING INSTRUCTIONS:
1. Before inserting this change, ensure the manual is current.
Check the existing List of Effective Pages in the manual to ensure all prior revisions are
inserted. (Do not insert this revision if prior revisions are not inserted).
2. Incorporate this change by removing old pages and inserting new pages as indicated below.
Remove Pages
Cover/Title
Cover/Title
1 and 2
List of Effective Pages
TR 06−001
A thru J
Bulletins
7 and 8
04−00−00
1 thru 14
05−20−00
1 and 2
7 thru 12
05−20−10
1 thru 4
06−00−00
205 and 206
08−10−00
201 and 202
18−10−00
509 and 510
18−20−00
205 and 206
Insert Pages
Cover/Title
TR
1 and 2
None
A thru J
7 and 8
1 thru 14
1 and 2
7 and 12
1 thru 4
205 and 206
201 and 202
509 and 510
205 and 206
369/500/600 Series
Remove Pages
28−00−60
201 and 202
28−25−00
1 and 2
Chapter 53
i thru vi
53−40−30
205 thru 212
63−10−00
409 and 410
Chapter 64
i thru iv
64−25−30
601 and 602
Chapter 67
i thru xii
67−00−00
105 and 106
67−10−00
417 and 418
603 thru 610
67−20−30
603 thru 606
71−10−10
601 and 602
HMI Revision
Insert Pages
201 and 202
1 and 2
i thru vi
205 thru 214
409 and 410
i thru iv
601 and 602
i thru xii
105 and 106
417 and 418
603 thru 610
603 thru 606
601 and 602
