Optimal 1700 Manual page 25

TREE SPADE OPTIMAL 1700
TELESCOPIC SPADE CYLINDER
Item Quantity
1 1
2 1
3 1
4 1
5 1
6 1
7 1
8 1
9 1
10 1
11 1
12 1
13 1
14 1
15 1
16 1
17 1
18 1
- 23 -
- SPARE PARTS
Description
eye joint GK 40
guide bush 013011
oil scraper PW 105
rod seal T7L 105-115
cylinder pipe 010011
O-ring 119.2 x 5.7 Sh
guide bush 013011
hydraulic union 107039-12-21
slotted nut 16040
tension block
cylinder body 010021
piston seal DAS 9076
piston 012012
O-ring 84 x 3 70 Sh
piston seal DAS 125108
O-ring 92 x 3 70 Sh
loocking ring 100 x 3
hydraulic union 107051-16-21
Part Number
5070400
311013011
51603105
516021051152
302010011
5171192057
311013011
515070391221
31316040
3091700010
302010021
51604090076
312012012
5170840030
51604125108
5170920030
599021003
515070511621
