Optimal 1700 Manual page 23

TREE SPADE OPTIMAL 1700
MAIN FRAME AND SPADES
Item Quantity
22 4
23 4
24 8
25 2
26 2
27 4
28 4
29 8
30 8
31 160
32 72
33 88
- 21 -
- SPARE PARTS
Description
blade
bush
bush
screw M 20 x 120, DIN 933
nut M 20, DIN 934
bolt M 30 x 220, DIN 931
nut M 30, DIN 985
plastic lining for guide
34 x 10 x 680 mm long
plastic lining for guide
34 x 10 x 782 mm long
countersunk screw with internal
wrenching, M 6 x 25, DIN 7991
nut M 6, DIN 934
nut M 6, DIN 985
Part Number
1630001
311163061
31116305
50120120933
5022009341
50130220931
502300985
3061702400
3061702401
501060257991
5020609341
502060985
