  • Page 1 Here's one for the books. NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. English pg 1-18 Français pg 19-21 Español pg 22-24 Share your journey!
  • Page 2 Table of Contents Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 5-18 Hammer Not actual size Français 19-21 Español 22-24 Skip the power trip. Safety 25-26 This time. Warranty Part Identifi...
  • Page 3 Now you know Part Identifi cation our ABCs. Page 3...
  • Page 4 Hardware Identifi cation å Screws are shown actual size. You may receive extra hardware with your unit. ® TWIST-LOCK HIDDEN CAM - 3 CAM SCREW - 3 FASTENER - 12 FOOT SCREW - 2 ANGLE BRACKET - 14 TIE PLATE - 4 RUBBER SLEEVE - 12 NAIL - 41 METAL PIN - 12...
  • Page 5 Step 1 Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. To begin assembly, push a TWIST-LOCK® å FASTENER (10F) into the large holes in the ENDS (A and B). Repeat this step for the SHELF (D) and BOTTOM (E).
  • Page 6 Step 2 Turn three CAM SCREWS (14F) into the SHELF MOLDING (M38). å NOTE: Be sure to use the exact holes shown. å Push three HIDDEN CAMS (1F) into the SHELF (D). å Arrow Arrow Hole The arrow in the HIDDEN CAM must point toward the hole in the edge of the board.
  • Page 7 Step 3 Fasten fourteen ANGLE BRACKETS (27G) to the å ENDS (A and B). Use fourteen BLACK 9/16" LARGE Remember: HEAD SCREWS (1S). Righty tighty. Lefty loosey. NOTE: Be sure the edges of the ANGLE BRACKETS å are even with the edges of the ENDS. BLACK 9/16"...
  • Page 8 Step 4 Fasten the RIGHT END (A) to the TOP (C2). Tighten å ® How to use the TWIST-LOCK FASTENER two TWIST-LOCK® FASTENERS. 1. Insert the dowel end of the FASTENER into the hole of the adjoining part. Fasten the SHELF (D) and BOTTOM (E) to the RIGHT å...
  • Page 9 Step 5 Fasten the LEFT END (B) to the TOP (C2), SHELF (D), and å BOTTOM (E). Tighten six TWIST-LOCK® FASTENERS. Edge with ANGLE BRACKETS Page 9...
  • Page 10 Step 6 Fasten the TOP MOLDING (M12) to the TOP (C2). Use å three BLACK 1-7/8" PAN HEAD SCREWS (16S). NOTE: Do not overtighten the SCREWS into the TOP. å Fasten the SHELF MOLDING (M38) to the SHELF (D). å Tighten three HIDDEN CAMS.
  • Page 11 Step 7 Fasten four TIE PLATES (3G) to the VALANCE (M59). Use four å BLACK 9/16" LARGE HEAD SCREWS (1S). BLACK 9/16" LARGE HEAD SCREW (4 used in this step) Page 11...
  • Page 12 Step 8 Fasten the VALANCE (M59) to the TOP MOLDING (M12). Use two BLACK å 9/16" LARGE HEAD SCREWS (1S). Fasten the LONG END MOLDINGS (M71) to the ENDS (A and B) and å VALANCE (M59). Use ten BLACK 9/16" LARGE HEAD SCREWS (1S). NOTE: There are no holes in the LONG END MOLDINGS (M71).
  • Page 13 Step 9 Fasten the SHORT END MOLDINGS (I) to the ENDS (A and B). å Use six BLACK 9/16" LARGE HEAD SCREWS (1S). NOTE: There are no holes in the SHORT END MOLDINGS (I). å Turn the screws into the grooves of the SHORT END MOLDINGS. Do not overtighten.
  • Page 14 Step Step 10 Fasten the SKIRT (M61) to the BOTTOM MOLDING (M13). å Use two BLACK 1-7/8" FLAT HEAD SCREWS (2S). BLACK 1-7/8" FLAT HEAD SCREW (2 used in this step) Flat surface Rounded edge Page 14...
  • Page 15 Step Step 11 Fasten the BOTTOM MOLDING (M13) to the BOTTOM (E). å Use three BLACK 1-1/8" PAN HEAD SCREWS (9S). Turn a FOOT SCREW (23F) a few turns into the two holes å in the BOTTOM MOLDING (M13). Next, turn a FOOT (J) onto each FOOT SCREW (23F). Turn å...
  • Page 16 Step Step 12 Carefully turn your unit over onto its front edges. Unfold å Caution the BACK (G) and lay it over your unit. Do not stand the unit upright without the Make equal margins along all four edges of the BACK (G). å...
  • Page 17 Step 13 Carefully stand your unit upright in its fi nal location. We recommend using the SAFETY STRAP for added stability. å Open the FURNITURE TIPPING RESTRAINT KIT (97). å NOTE: Do not turn the SAFETY DRYWALL ANCHOR into a wall stud. If you prefer to fasten the SAFETY å...
  • Page 18 Step 14 Push the RUBBER SLEEVES (2R) over the METAL PINS (1R). Insert the METAL PINS into the hole å locations of your choice in the ENDS (A and B). Set the ADJUSTABLE SHELVES (F) onto the METAL PINS. NOTE: Please read the back pages of the instruction booklet for important safety information. å...
  • Page 19 Bibliothèque Utilisez les instructions d’ a ssemblage en français avec les NOUS SOMMES LA POUR VOUS AIDER! schémas étape par étape du manuel d’instruction en anglais. Nous faisons de notre mieux pour nous assurer que votre meuble Chaque étape en français correspond à la même étape arrive dans d’excellentes conditions.
  • Page 20 ÉTAPE 1 ÉTAPE 5 Ne pas serrer les FIXATIONS TWIST-LOCK® à cette étape. Fixer l'EXTRÉMITÉ GAUCHE (B) au DESSUS (C2), à la TABLETTE (D) et au DESSOUS (E). Serrer six FIXATIONS TWIST-LOCK®. Assembler l'élément sur un sol à moquette ou sur le carton vide pour éviter d'endommager l'élément ou le sol.
  • Page 21 ÉTAPE 9 ÉTAPE 13 Fixer les MOULURE D'EXTRÉMITÉ COURTES (I) aux EXTRÉMITÉS (A Relever, avec précaution, l'élément dans sa position verticale et et B). Utiliser six VIS TÊTE LARGE 14 mm NOIRES (1S). placer l'élément dans son emplacement fi nal. Il est recommandé d'utiliser la SANGLE DE SÉCURITÉ...
  • Page 22 Modelo 420477 Biblioteca Use estas instrucciones de ensamblaje en español junto con las ESTAMOS AQUI PARA AYUDAR! fi guras paso-a-paso provistas en el folleto inglés. Cada paso Tratamos de asegurar que su mueble llega en condición excelente. en español corresponde al mismo paso en inglés. Se destacan Nuestros representantes de Servicio al Cliente son amables y las fi...
  • Page 23 PASO 1 PASO 5 No apriete los SUJETADORES TWIST-LOCK® en este paso. Fije el EXTREMO IZQUIERDO (B) al PANEL SUPERIOR (C2), al ESTANTE (D) y al FONDO (E). Apriete seis Ensamble la unidad sobre un piso alfombrado o sobre el cartón SUJETADORES TWIST-LOCK®.
  • Page 24 PASO 9 PASO 13 Fije la MOLDURA CORTA DE EXTREMO (I) a los Cuidadosamente ponga la unidad en posición vertical y coloque EXTREMOS (A y B). Utilice seis TORNILLOS NEGROS DE su unidad en su posición fi nal. Se recomienda que utilice la CABEZA GRANDE de 14 mm (1S).
  • Page 25 WARNING Please use your furniture correctly and safely. Improper use can cause safety hazards, or damage to your furniture or household items. Carefully read the following chart. Look out for: What can happen: How to avoid the problem: • Overloaded shelves. •...
  • Page 26 ADVERTENCIA Por favor use el mobiliario correcta y seguramente. El mal uso puede causar riesgos de seguridad o daño a las unidades o artículos domésticos. Cuidadosamente lea la tabla a continuación. Esté alerto de: Puede ocurrir: Evitar el problema: • Estantes sobrecargados. •...
  • Page 27 5-YEAR LIMITED WARRANTY 1. We provides limited warranty coverage to the original purchaser of this product for 4. This Warranty applies only to warranted defects that fi rst arise and are reported a period of fi ve years from the date of purchase against defects in materials or to within the warranty coverage period.
