Desk
Model 420203
Share your journey!
to order replacement parts, view video assembly tips, or chat with a live rep.
1-800-445-1527
.
Sit and surf.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-28
Français pg 29-32
Español pg 33-36
Lot # 531643
Purchased: __________________
07/16/19

Advertisement

loading
Need help?

Need help?

Do you have a question about the 420203 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sauder 420203

Summary of Contents for Sauder 420203

  • Page 1 Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays) Sit and surf. Desk NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Model 420203 PLEASE READ AND KEEP FOR FUTURE REFERENCE. English pg 1-28 Français pg 29-32 Español pg 33-36...
  • Page 2 Table of Contents Assembly Tools Required Part Identifi cation Hardware Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Assembly Steps 5-28 Français 29-32 Español 33-36 Skip the power trip. This time. Safety 37-38 Warranty Page 2 www.sauder.com 420203...
  • Page 3 LONG BRACE (2) DRAWER BOTTOM (1) CENTER UPRIGHT (1) SHORT BRACE (2) DRAWER BRACE (1) LEFT UPRIGHT (1) LARGE RIGHT DRAWER SIDE (1) DRAWER FRONT (1) BACK (1) LARGE LEFT DRAWER SIDE (1) AA LARGE DRAWER FRONT (1) 420203 www.sauder.com Page 3...
  • Page 4 BLACK 11/16" FLAT HEAD SCREW - 4 BLACK 1/2" MACHINE SCREW - 4 BLACK 1/2" PAN HEAD SCREW - 22 BLACK 1/2" FLAT HEAD SCREW - 12 BLACK 1/2" MACHINE SCREW - 4 BLACK 5/16" MACHINE SCREW - 1 Page 4 www.sauder.com 420203...
  • Page 5 BLACK 1-3/4" PAN HEAD SCREWS (13) and two BLACK 1/2" PAN HEAD SCREWS (18). BLACK 1-3/4" PAN HEAD SCREW (2 used in this step) Surface with holes Edge with holes BLACK 1/2" PAN HEAD SCREW (2 used in this step) 420203 www.sauder.com Page 5...
  • Page 6 LEFT UPRIGHT. Turn a SCREW into this hole. BLACK 11/16" FLAT HEAD SCREW (2 used in this step) These edges should be even. Line up the This hole is closer to this edge. back hole fi rst. Finished surface Page 6 www.sauder.com 420203...
  • Page 7 Step 3 Fasten four METAL BRACKETS (9) to the CENTER å LEG (C) exactly as shown. Use four BLACK 1/2" PAN HEAD SCREWS (18). BLACK 1/2" PAN HEAD SCREW (4 used in this step) 420203 www.sauder.com Page 7...
  • Page 8 Turn two CAM SCREWS (7) into the CENTER END (F). å BLACK 1/2" PAN HEAD SCREW (4 used in this step) Surface with fewer holes Edge without holes BLACK 1-3/4" PAN HEAD SCREW (4 used in this step) Page 8 www.sauder.com 420203...
  • Page 9 CENTER END (F). Use two BLACK 1" PAN HEAD SCREWS (14) in the outer holes. BLACK 1" PAN HEAD SCREW (2 used in this step) Surface with more holes This hole is closer to this edge. 420203 www.sauder.com Page 9...
  • Page 10 UPRIGHT. Turn a SCREW into this hole. BLACK 11/16" FLAT HEAD SCREW (2 used in this step) These edges should be even. Line up the back hole fi rst. Finished surface This hole is closer to this edge. Page 10 www.sauder.com 420203...
  • Page 11 Step 7 Fasten two METAL BRACKETS (9) to the RIGHT å LEG (A) exactly as shown. Use two BLACK 1/2" PAN HEAD SCREWS (18). BLACK 1/2" PAN HEAD SCREW (2 used in this step) 420203 www.sauder.com Page 11...
  • Page 12 Finish fastening the RIGHT LEG (A) to the RIGHT END (E). å Use two BLACK 1-3/4" PAN HEAD SCREWS (13). BLACK 1/2" PAN HEAD SCREW (2 used in this step) Edge without holes BLACK 1-3/4" PAN HEAD SCREW (2 used in this step) Page 12 www.sauder.com 420203...
  • Page 13 RIGHT END (E). Use two BLACK 1" PAN HEAD SCREWS (14) in the outer holes. BLACK 1" PAN HEAD SCREW (2 used in this step) Surface with more holes This hole is closer to this edge. 420203 www.sauder.com Page 13...
  • Page 14 å Push on the black lever and pull the SLIDE from the RAIL. Open end BLACK 1/2" FLAT HEAD SCREW (4 used in this step) Use these holes. Back hole Open end Back hole Open end Page 14 www.sauder.com 420203...
  • Page 15 These edges r f a o l e should be even. w i t Surface without holes These edges should be even. BLACK 1/2" MACHINE SCREW Surface without holes (2 used for the SHORT BRACES) 420203 www.sauder.com Page 15...
  • Page 16 Fasten the CENTER LEG (C) to the SHORT BRACES (P). Use å two BLACK 1/2" MACHINE SCREWS (20). The arrow must point toward the edge of the board. BLACK 1/2" MACHINE SCREW (2 used for the SHORT BRACES) Page 16 www.sauder.com 420203...
  • Page 17 Insert four HIDDEN CAMS (5) into the ENDS (E and F). å Fasten the SHELF (K) to the ENDS (E and F). Tighten four å HIDDEN CAMS. The arrow must point toward the edge of the board. 420203 www.sauder.com Page 17...
  • Page 18 Fasten the BRACE (N) to the LEFT LEG (B). Use two å BLACK 1/2" PAN HEAD SCREWS (18). The arrow must point toward the edge of the board. Finished edge Surface with holes BLACK 1/2" PAN HEAD SCREW (2 used for the BRACE) Page 18 www.sauder.com 420203...
  • Page 19 Fasten the BRACE (N) to the CENTER LEG (C). Use two å BLACK 1/2" PAN HEAD SCREWS (18). The arrow must point toward the edge of the board. BLACK 1/2" PAN HEAD SCREW (2 used for the BRACE) 420203 www.sauder.com Page 19...
  • Page 20 Fasten the TOP (D) to the RIGHT LEG (A). Use two BLACK å 1-3/4" PAN HEAD SCREWS (13). The arrow must point toward the edge of the board. BLACK 1-3/4" PAN HEAD SCREW (2 used for the RIGHT LEG) Page 20 www.sauder.com 420203...
  • Page 21 SCREWS in the LEGS and then retighten once the LONG BRACES are fastened together. NOTE: Tighten the NUT using the TOOL (12). å BLACK 1/2" PAN HEAD SCREW (4 used in this step) BLACK 5/16" MACHINE SCREW (1 used in this step) 420203 www.sauder.com Page 21...
  • Page 22 DRAWER SIDES (Q and R). Use four BLACK 1/2" FLAT HEAD SCREWS (19). BLACK 1" FLAT HEAD SCREW (4 used in this step) Groove BLACK 1/2" FLAT HEAD SCREW (4 used for the SLIDES) Use these holes. Page 22 www.sauder.com 420203...
  • Page 23 Use two BLACK 1/2" MACHINE SCREWS (17). point toward the edge of the board. BLACK 1/2" MACHINE SCREW (2 used for the PULL) Be sure the LARGE DRAWER BOTTOM (T) inserts into the groove in the LARGE DRAWER FRONT (AA). 420203 www.sauder.com Page 23...
  • Page 24 DRAWER BACK (W). Slide the DRAWER BOTTOM (X) into the grooves in the å DRAWER SIDES (U and V) and DRAWER BACK (W). Groove Groove BLACK 1" FLAT HEAD SCREW (4 used in this step) Page 24 www.sauder.com 420203...
  • Page 25 Fasten a PULL (10) to the DRAWER FRONT (Z). Use å two BLACK 1/2" MACHINE SCREWS (17). BLACK 1/2" MACHINE SCREW (2 used for the PULL) Be sure the DRAWER BOTTOM (X) inserts into the groove in the DRAWER FRONT (Z). 420203 www.sauder.com Page 25...
  • Page 26 V) with the brackets on the RAILS. Fasten the DRAWER (Z) to the RAILS (1 and 2). Use four å BLACK 1/2" FLAT HEAD SCREWS (19). BLACK 1/2" FLAT HEAD SCREW (4 used in this step) Page 26 www.sauder.com 420203...
  • Page 27 RAILS on the unit and push the drawer into the unit until the drawer is fully inserted. The drawer will push in hard until it is all the way in, then it will slide in and out easier. 420203 www.sauder.com Page 27...
  • Page 28 NOTE: Please read the back pages of the instruction booklet for important safety information. å This completes assembly. Clean with a damp cloth. Wipe dry. å And to celebrate, why not share your success story at Walmart.com or 60 lbs. 30 lbs. 30 lbs. 20 lbs. Page 28 www.sauder.com 420203...
  • Page 29 Modèle 420203 Bureau Utilisez les instructions d’ a ssemblage en français avec les NOUS SOMMES LA POUR VOUS AIDER! schémas étape par étape du manuel d’instruction en anglais. Nous faisons de notre mieux pour nous assurer que votre meuble Chaque étape en français correspond à la même étape arrive dans d’excellentes conditions.
  • Page 30 Utiliser deux VIS TÊTE GOUTTE DE SUIF 44,5 mm NOIRES (13). et au MONTANT CENTRAL (G). Utiliser quatre VIS TÊTE GOUTTE DE SUIF 44,5 mm NOIRES (13). Faire tourner deux VIS D’EXCENTRIQUE (7) dans l'EXTRÉMITÉ CENTRALE (F). Page 30 www.sauder.com 420203...
  • Page 31 Fixer le PIED CENTRAL (C) sur les ENTRETOISES COURTES (P). EXCENTRIQUES ESCAMOTABLES. Utiliser deux VIS À MÉTAUX 13 mm NOIRES (20). Fixer le DESSUS (D) au PIED DROIT (A). Utiliser deux VIS TÊTE GOUTTE DE SUIF 44,5 mm NOIRES (13). 420203 www.sauder.com Page 31...
  • Page 32 Appuyer l'ENTRETOISE DE TIROIR (Y) sur les CHEVILLES EN BOIS de l'ARRIÈRE DE TIROIR (W). Enfi ler le FOND DE TIROIR (X) dans les rainures des CÔTÉS DE TIROIR (U et V) et de l'ARRIÈRE DE TIROIR (W). Page 32 www.sauder.com 420203...
  • Page 33 RIEL IZQUIERDO ............1 PATA IZQUIERDA ............1 su referencia futura. Si RIEL DERECHO ..............1 necesita ponerse en PATA CENTRAL..............1 contacto con Sauder en RIEL DE EXTENSIÓN ..........2 PANEL SUPERIOR ............1 cuanto a esta unidad, CORREDERA DE EXTENSIÓN ......2 EXTREMO DERECHO ..........1 refi...
  • Page 34 Termine de fi jar la PATA CENTRAL (C) al EXTREMO CENTRAL (F) REDONDA de 44,5 mm (13). y al PARAL CENTRAL (G). Utilice cuatro TORNILLOS NEGROS DE CABEZA REDONDA de 44,5 mm (13). Gire dos PASADORES DE EXCÉNTRICO (7) en el EXTREMO CENTRAL (F). Page 34 www.sauder.com 420203...
  • Page 35 TORNILLOS NEGROS DE CABEZA REDONDA de 44,5 mm (13). Fije el EXTREMO CENTRAL (F) al DORSO GRANDE (J). Apriete dos EXCÉNTRICOS ESCONDIDOS. Fije la PATA CENTRAL (C) a las RIOSTRAS CORTAS (P). Utilice dos TORNILLOS NEGROS PARA METAL de 13 mm (20). 420203 www.sauder.com Page 35...
  • Page 36 Empuje la RIOSTRA DE CAJÓN (Y) sobre los PASADORES DE MADERA en el DORSO DE CAJÓN (W). Deslice el FONDO DE CAJÓN (X) dentro de las ranuras de los LADOS DE CAJÓN (U y V) y del DORSO DE CAJÓN (W). Page 36 www.sauder.com 420203...
  • Page 37 à Les téléviseurs peuvent être particulièrement un téléviseur. cet eff et. lourds. De plus, le poids et l’emplacement du tube image ont tendance à rendre les téléviseurs instables et enclins à tomber vers l’ a vant. 420203 www.sauder.com Page 37...
  • Page 38 Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y propensa a volcarse hacia adelante. Page 38 www.sauder.com 420203...
  • Page 39 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
  • Page 40 Walmart.com in the product detail page. General Conformity Certifi cate 1. This certifi cate applies to the Sauder Global Sourcing Product identifi ed by this Instruction Book. 2. This certifi cate applies to compliance of this product with the CPSC Ban on Lead-Containing Paint (16 CFR 1303).
