ASSEMBLY OF THE COOKIES CAP

13
1. Hold the mincer's case (3) with the largest opening facing towards the top.
2. Put the screw (4) into the case.
3. Insert the spacer (11) and make sure the two clips are inserted correctly into the
two holes in the mincer's case.
4. Insert the mount of the cookies cap (12) in the middle of the spacer and seize
the lock (7). The two openings are aligned horizontally.
5. Slide the cookies rack (13) into the mount (12) from the side until the desired
motive is placed in front of the opening.
6. Hold the assembled mincer with the opening facing to the top and the cookies
cap towards you. Connect it to the stand mixer's engine top via turning. The
large opening faces towards the top when assembled.
7. Put the funnel (2) onto the mincer.
16
7 12 11 4
2
3
