Trango Flexcam User Manual

Ⓡ
TRANGO
User's Manual for New Flexcam
EN 12276:1998 Mountaineering equipment
Frictional anchors
Caution!
Read and follow carefully before use.
Only the trained and experienced expert or one who are under his
direct or indirect control can use this.
Minimum holding force and Width size
Min.holding
Width
Size force
(mm)
(kN)
1 7 kN 11 - 17
2 7 kN 15 - 21
3 10 kN 19 - 27
4 10 kN 24 - 33
5 12 kN 27 - 43
Marking (fig1)
New Flexcam : Model name
Size : Width size of cam (see table)
kN : Kilo Newton which manufacturer ensures
CE : CE Marking for Directive89/686/EEC Article 11
0120 : Number of official organism controlling the quality system
EC Type-examination by :
SGS United Kingdom Ltd
Weston-super-Mare, somerset BS22 6WA, United Kingdom
0810 : Lot number (year & Month)
Ⓡ
#147-17, Seoun-dong, Gyeyang-gu, Incheon, 407-070 Korea
Min.holding
Width
Size force
(mm)
(kN)
6 12 kN 34 - 55
7 12 kN 44 - 68
8 12 kN 53 - 86
9 12 kN 63 - 107
-
How to use ...
∙ Improper use of this product may cause serious injury or damage.
Careful attention and limitation is required to use this product.
Read and understand the properties and characteristics of this product.
∙ Only the persons trained and experienced on mountaineering or ones who
are under his/their direct or indirect control can use this product.
∙ It may be used in conjunction with any appropriate items of climbing equip-
ment of suitable specification and according to the EN standards with due
consideration to the limitations of each individaul piece of equipment.
∙ in wet or frozen condition, it may not operate smoothly.
∙ Sling or any other parts can be damaged by sharp edged things
※ See detailed instructions on next page.
How to maintain ...
∙ Always check the operation status before/after use.
∙ If the cam can not open easily, lubricate cam shaft.
∙ If after oiling cam does not work well, discard cam.
Replace the unit with signs of wear and corrosion. Replace the cam when
opening and closing are difficult. Avoid any contact of the cam with corroding
substance and heat sources. Lubricate when necessary, the mobile components
with silicone based lubricant only. If the cam comes in contact with seawater,
wash it and lubricate with oil.
Lifespan or how to assess it.
∙ 3-5 years when monthly used.
∙ 4-6 months when daily used.
The load indicated in always the lowest guaranteed value.
A cam lasts several years when use intermittently, but this can not exactly
evaluated. In frequent use condition, for your safety, a replacement each 3 years is
recommended.
Limitation on use
Never use the products having
∙ sudden impact like fall, even if not default or damage is visible.
∙ defects, cracks, damages.
∙ abrasion, corrosion.
∙ unsmooth opening of the cam.
Effects of chemical reagents and temperature
∙ High temperature over 100℃ can shorten the lifetime.
∙ Chemical reagents like strong acid can corrode the cam.
Effects of storage and ageing
∙ When cam is stored in damp air, cam will be rusted and malfunctioned.
Do not store in damp air.
∙ There is no ageing effect on the metallic components, however the sling will
age if stored in sunlight.
∙ keep in a cool, dry, dark place away from high temperature, high humidity,
sharp edges, icy conditions, corrosive or other possible causes of damage
and/or chemicals.
∙ 1-2 years when weekly used.
∙ Sudden impact will end useful life.
UM02-2(0)
