Installation

1
Once your Hub is working satisfactorily, if you temporarily set up
your Hub before a more permanent installation, find a suitable
permanent location for it. Please familiarize yourself with the
Installation Considerations section before you finalize your
installation
K
Introduction to the App
1
Immediately after opening the app for the first time, the app will
give you a quick visual tour, highlighting and identifying the
various areas of the app
2
See Figure 1, below, for an example Rooms screen, which serves
as a home screen for the app. Your Hub will appear on this page,
along with any other devices you have bound
Rooms Page
(Tap)
Figure 1
3
Tap the device to open the Device Page There are options to
control and/or view the status of your device, and view the history
of the device. Refer to Figure 2
4
Tap the 3 dots icon to access the Detail Page. Refer to Figure 3. To
exit, tap the "<" icon. Any changes you make the device name or
settings will be saved
Device Page
(Tap)
Figure 2
2
Wall-mount the Hub, or place it on a stable surface, as desired
Figure 3
TYPE OF DEVICE
(FACTORY SET)
DEVICE NAME (TAP TO EDIT)
DEVICE'S ROOM (TAP TO EDIT)
FAVORITE (TAP TO ADD TO FAVORITES)
HISTORY (TAP TO VIEW)
DEVICE SETTINGS: SIREN VOLUME
(TAP TO EDIT)
DEVICE SETTINGS: ALARM DURATION
(TAP TO EDIT)
BATTERY LEVEL
ONLINE/OFFLINE STATUS
MODEL NUMBER (FACTORY SET)
UNIQUE EUI NUMBER
UNIQUE DEVICE SERIAL NUMBER
DEVICE SIGNAL LEVEL
FIRMWARE REVISION
TAP TO REMOVE DEVICE FROM SYSTEM
