GA
103
T
A.
Make sure the door is connected to the motor
B.
Turn the power off to the motor
C.
Press and hold the T button
D.
Turn power supply back on while still pressing the T button
E.
Keep holding T button 5 seconds minimum
F.
Release T button
G.
Press T button momentarily and release
H.
Door will perform 4 - 5 test operations automatically
I.
Door now should work correctly
•
Suitable for garages with up to 2 spaces
•
Pulling force 600 N
•
Door sizes up to 12m
•
Opening speed max. 135 mm/sec.
•
Plus optional battery back up
The GA103 garage door operator is loaded with technical innovations.
The second opening height is a standard programmable feature, and the
opening power is 600 N. Owners can also expect the highest level of security
and user safety, along with a 2 Year warranty.
All units are TUV tested and exceed or surpass the most stringent industry
requirements for reliability and performance.
T
1
2
HOW TO PROGRAM
A REMOTE
1
2
Let go (release) both buttons
2
Press and hold button 1
Press the button on the remote
you want to program
