Model: GR-C4
Subject
:
The print job of the previous user is printed
From:
Overseas info.Sect., OPQuality Management Dept.
Classification:
SYMPTOM
The job of the user who was previously logged in is printed when printing under the
following conditions.
Affected firmware/models:
-
Gr-C4 printer firmware ver. 1.01
Affected solution:
-
Enhanced Locked Print NX v2.5.000 or later (except v2.5.202).
Occurrence conditions:
- Location free environment
- It takes over 15 seconds (but less than the app. default time-out limit of 60 seconds) for
the print data to be received by the device once the device's print button is pressed.
- Print job originates from above solution
CAUSE
Printer firmware bug (included in package version 1.00).
SOLUTION
Enhanced Locked Print:
Update Enhanced Locked print v2 to v2.5.202.
GR-C4:
Update the package firmware to ver 1.01 or newer.
Model
GR-C4
*Printer [GRIC4e_printer] D0C95474 Ver. 1.02 must be installed.
T
echnical
Troubleshooting
Mechanical
Paper path
Product Safety
Firmware Type
Package (ALL)
B
ulletin
Date: 9-Dec-19
Prepared by: K. Yamamoto
Part information
Electrical
Transmit/receive
Other (
)
Version
1.01
PAGE: 1/1
No.: RD0CA001
Action required
Service manual revision
Retrofit information
Tier 2
P/N
D0C95492A
