Samsung SDS SHP-P72 User Manual

GC68-02399D, ED01
SHP-P72
User Manual
Table of Contents
Components
Names and functions
Open door from outside
Open/Close door from inside
Register authentication method
(password/fingerprint/keytag)
and install app
Additional functions and
setting method
How to use security function
Initialization
How to replace the battery and
open the door during an emergency
※
Color may be added and specifics will be determined by
future policy.
smarthome.samsungsds.com
Safety Caution
Safety caution protects the safety of users, and prevents
property damage from accidents and usage inconvenience.
Please read and comply with the following safety caution.
•Do not install or repair this product without permission.
•The gap between the door and door frame should not exceed 5mm during installation.
•Fracture in the door lock touchpad may result in an environment where
the door lock is exposed to direct sunlight for a long period of time.
Therefore, avoid the environment from being exposed to direct sunlight
for installing the door lock.
•Do not apply excessive force or press the door lock button with sharp tools.
•Do not operate this product with wet hands, and do not let liquids such as water
and beverage to infi ltrate the product.
•Wipe the lock with soft and dry cloth, and do not wipe this product with water,
benzene, alcohol, etc.
•Check that the door is completely locked when leaving home.
•Manage your password carefully and regularly change your password to prevent
password leak.
•Insert the batteries accurately according to the terminal (+/-) of the battery.
•Be mindful that battery leak or rupture may result from inserting the batteries at
opposite terminals (+/-).
•Battery consumption may vary depending on the wireless communication
environment. Battery use time may decrease if the communication environment
is unfavorable.
•Wireless radio waves or another device may cause interference when using this product.
•Wireless radio wave interference may take place during operation of the wireless
device of this product, and this results in suspension of human safety-related services.
•Product performance may suffer if used in an environment with high humidity.
•Maintain at least 20cm of distance from the product when using the product.
※
The company reserves the right to change the contents of the user manual without
notice in advance to upgrade product functionality.
1
Components
Exterior
Unit
Product specifications
Item
Rated voltage
Emergency Power
Entry method
Weight
Product size
(Includes Push-Pull lever)
2
Names and functions
Exterior Unit
Keypad
Entry complete/
Switch to
manner mode
Indication LED
Keytag sensor
Emergency
LED
Battery
replacement LED
Interior Unit
Battery
cover
Module Cover
Register but-
ton
Interior
Push-Pull lever
3
Open door from outside
Fingerprint
The door opens when the registered fingerprint accurately
makes contact with the fingerprint sensor.
Master Password & User Password
❶
Stand close to the door lock and then press the two
random digits displayed. (Randomizer function)
❷
When all buttons on the keypad are displayed,
enter your password (4~12 digits) and then press [ * ]
to open the door.
TIP
User manner function (sound muted) to open door
Press [*] button when temporarily turning off the sound in the evening and enter password to mute the sound.
References
• Enter the password when the keypad is turned on. If the keypad is turned off,
touch the keypad to turn on the keypad and then enter the password.
• Error alarm is triggered and the door lock operation is suspended for 3 minutes after entering an
incorrect password 5 times. You can enter the accurate password to open the door once the door
lock suspension disarming alarm is triggered by the door lock system after 3 minutes.
• Press the [Security] (
re-enter the accurate password.
Keytag/Mobile Key
The door opens when a registered keytag or mobile key
(smartphone) accurately makes contact with the fingerprint sensor.
References
• Touch the keypad when the welcome function has been disabled and then place the
mobile key on the sensor to open the door.
• You can open the door with mobile key after installing the door lock app and
requesting for the service.
• Mobile key door open function only supports Android mobile phones and devices
equipped with NFC USIM card.
• You can use the mobile key to open the door only when the smartphone screen is on.
• Refer to user guide provided in the app for details.
4
Open/Close door from inside
Open by Pulling or Pushing the Push-Pull Lever
You can choose to open by pulling or pushing the Push-Pull lever depending on
the direction of door installation.
Close Door
Auto lock (A)
The door is automatically locked when closed. (Default)
Manual lock (M)
The door is not locked even after being closed for unrestricted access.
(Party, moving, etc.)
TIP
How to Confi gure Auto/Manual Lock
Open the battery cover on the interior unit.
Confi gure with [Auto/Manual Lock] conversion switch.
• After enabling manual lock mode, the door can only lock if the [DOUBLE LOCK] button
Caution
is pressed from the inside or if the keypad is pressed from the outside.
• Regardless of the manual lock mode configuration, the door is automatically locked
if the door is not opened within 7 seconds after disabling the lock.
5
Register authentication method
You can only register the authentication method when the door is open.
After opening the battery cover on the interior unit, press
enter the master password. Then press [ * ] button to enter registration mode.
※ Read the caution for registering authentication mode, and it is recommended to only register
when there is a person present inside the house.
※ Registration mode is terminated automatically when incorrect password has been entered,
and you can register again after pressing the [Register] button.
Press the [Register] button on the interior unit if you have to suspend
registration before completion.
Each setting can be checked through the door lock keypad.
Registration
and configuration
complete
( O )
Registration Mode
Enter registration mode and then register authentication method
(password, keytag, fingerprint) according to the voice guidence.
※ Registration mode is maintained for 60 seconds by default and the door does not lock even if it is closed
within 60 seconds.
Change Master Password
You can enter 4~12 digits for the password, and you can only register a single master
password. Default password is "1234".
※ You must change the password after installing the product.
0
Register (Add) User Password/Delete
Individual User Password/Delete All User Passwords
You can register up to 100 keytags including passwords and mobile keys.
Registered passwords can be deleted individually or collectively. (4~12 digits)
1
Register (Add) Keytag/Delete
Individual Keytag/Delete All Keytags
You can register up to 100 keytags including passwords and mobile keys.
Registered keytags can be deleted individually or collectively.
2
References • Press the door open sensor with the door open to artificially close the door, and then open
the door with the keytag (whether the dead bolt goes inside the mortise) to check
if registration has been completed normally.
• Close the door after adding or deleting is complete.
•This product only supports keytags provided by Samsung SDS.
Caution
•Warranty is void if the door lock is malfunctioning from opening the door using alternate
authentication method aside from the keytags prescribed by the company.
Register (Add) Fingerprint/
Delete Individual Fingerprint/Delete All Fingerprints
You can register up to 100 fingerprints.
Registered fingerprints can be deleted individually or collectively.
3
How to Register Fingerprint
Place a finger on the fingerprint sensor to register.
Change the angle of the finger 6 times and make contact with
the sensor when registering a fingerprint.
※ Number of contacts made by fi ngerprint appears on the keypad with the 'Ding' sound when registering
fi ngerprint. Register the fi ngerprints in the same method according to voice guidence when adding
fi ngerprints. Press the [Register] button on the interior unit when registration is complete.
❶
References • It is recommended to register thumbs or index fingers when registering fingerprints.
• Register the fingerprint for a finger you use often if you wish to improve
fingerprint recognition rate.
• Recognition rate may be low if it is a fingerprint of a child or if the fingerprint is faint
(or damaged). Fingerprint may not register or be recognized in such instance.
• If the surface of the fingerprint is too rough (damaged or bubble present on the finger),
fingerprint may not be recognized. Recognition rate may suffer if the finger is too small or thin,
or if the finger is bent, or if only the fingertip is used for authentication.
You must cover the entire fingerprint sensor with your finger when registering your fingerprint.
• If the fingerprint sensor or the finger is dirty or wet, try again after wiping.
• If the surrounding environment is dry, static may occur for the product. In such an instance,
avoid using fingerprint recognition or make contact with another metallic object before
fingerprint recognition to eliminate static and try again.
• Be careful not to scratch the fingerprint sensor with coins, keys, necklaces,
and other metallic objects.
• Close the door after checking that the fingerprint has been added or deleted accurately.
Samsung Smart Doorlock app
Installation and registration
When you register a door lock to Samsung Smart Doorlock app,
you can use various IoT services including remote door open,
access function, push notification, etc. Android users can search for
'Smart Doorlock' app in Play Store to download and install, and iOS users can
search for 'Smart Doorlock' app in the App Store to download and install.
TIP
How to Register Wi-Fi
Press [Register] button on the interior unit
for 5 seconds to register Wi-Fi.
• Wi-Fi router must be on to register door lock. When using dual-band router
Caution
•Refer to user guide provided by the app for door lock registration method and other
Interior
Unit
4 AA 1.5V alkaline batteries (LR6) (DC 6V)
Smartphone portable charger with micro USB 5-pin
connector
Fingerprint, password, keytag, Mechanical override
3.686Kg (includes exterior unit, interior unit, and mortise)
[Exterior] 88(W) x 392.1(H) x 63.8(D)mm
[Interior] 86.2(W) x 391(H) x 68.5(D)mm
) button when canceling entry after entering an incorrect password to
or
Registration
and configuration
failed
( X )
Master password
New master password
Register
(Add)
Delete individual pass-
word
Delete
all passwords
Register
(Add)
Delete individual
keytag
Delete
all keytags
Register
(Add)
Delete individual
fingerprint
Delete
all fingerprints
❷ ❸
(2.5GHz, 5GHz), you must select 2.4GHz. (5GHz is not supported)
service-related matters.
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
Mortise Strike Plate
OR
•2 Keytags
•User Manual,
Mechanical override
•"AA" batteries (LR6)
•Installation components
(wrapped in plastic)
※ Product components may
vary depending on installation
environment.
Specifi cations
Fingerprint
sensor
Away mode
LED
Proximity
detector
Privacy mode
LED
Reset button
Exterior
Push-Pull lever
Battery tray
Wi-Fi module
installation unit
Volume
control switch
Auto/Manual lock
conversion switch
[DOUBLE LOCK]
button
Add / Register
( + )
0
1
2
3
1
2
3
1
2
3
1
Fingerprint
Can be registered
continuously
(Within 60 seconds)
2 Fingerprint
Can be deleted
continuously
(Within 60 seconds)
3
❹
Dust Box
Lower Exterior Unit
Micro USB Mechanical
power input override hole
Mortise
Dead bolt
Latch bolt
Door open
sensor
Be careful not to get
your hand jammed
during use.
[Register] button and
Delete individual
( - )
Change master password mode
Register user password mode
Register keytag mode
Register fingerprint mode
Password
Can be registered
Complete
continuously
(Within 60 seconds)
Password
Complete
Can be deleted
continuously
(Within 60 seconds)
Keytags
Can be registered
Complete
continuously
(Within 60 seconds)
Keytags
Complete
Can be deleted
continuously
(Within 60 seconds)
Complete
Complete
❺ ❻
5S
Register button
on the interior unit
A | M
