Wimbourne - 3 Door Centre Mirror Gents
Assembly Instructions
Dimensions
Width - 132.6cm
Depth - 61cm
Height - 198cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6403030
- Please keep for future reference
346/0575
346/5817
BK04100 - Issue 1 - 05/12/2014
Advertisement
Related Manuals for Heart of House Wimbourne
Summary of Contents for Heart of House Wimbourne
- Page 1 Wimbourne - 3 Door Centre Mirror Gents 346/0575 Assembly Instructions - Please keep for future reference 346/5817 Dimensions Width - 132.6cm Depth - 61cm Height - 198cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline:...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Assemble on a soft level • We do not components and tools listed on surface to avoid damaging the recommend the pages 2 and 3.
- Page 3 If you have damaged or missing components, call the Components - Panels Argos = 0345 6403030 Customer Helpline: Please check you have all the panels listed below Double wardrobe Single wardrobe (191 x 82.3 x 57.6 cm) (191 x 42.3 x 57.6 cm) Cornice section (132.6 x 11cm)
- Page 4 Components - Fittings Please check you have all the fi ttings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fi ttings may be supplied than are required. 15mm Screw x 1 15mm Washer x 2 Wall strap x 1 18mm Conecting bolt x 2...
- Page 5 Assembly Instructions Step 1 Position and connect the units Before connecting the units you will fi rst need to remove all doors and drawers. Loosen but do not remove bolt B in the centre of the hinge back plates which are attached to the wardrobe side panel.
- Page 6 Assembly Instructions Step 2 Re-fi tting the doors Starting from the top, slide the keyhole shaped groove in the hinge over bolt B on the hinge plate. Once located tighten bolt B and move on to the next hinge. Step 3 Remove and replace handles The handles are...
- Page 7 Assembly Instructions Step 3 - continued Replace the handle on the front of the unit. Fix in position by screwing the handle screw into each handle from inside the unit using a Philips screwdriver. Philips screwdriver Handle screw Handle Step 4 WARNING: Help may be required for this step.
- Page 8 Assembly Instructions Step 5 Fixing to wall It is recommended that the wardrobe is fi xed to a wall. Fix wall strap to the top of wardrobe using 15mm screw Using the correct type of screw screw through the washer and wall 15mm washer strap into a pre-drilled hole in the Warning: The...
-
Page 9: Customer Helpline
Customer Helpline: If you need help or have damaged or missing parts, call the Argos = 0345 6403030...
