- Page 1 CATALINA SEMI CASSETTE AWNING Use and Maintenance 1123 CATALINA SEMI-CASSETTE AWNING USE & MAINTENANCE Toll Free 877-792-1775 | Fax 877-792-0031 swsuncontrolpro.com | sales@swsuncontrol.com...
-
Page 2: Table Of Contents
CATALINA SEMI CASSETTE AWNING Use and Maintenance 1123 1 INTRODUCTION ........................3 2 SAFETY ..........................3 General safety information ........................3 Safety devices ............................3 Residual ricks ............................3 3 DESCRIPTION OF AWNING ....................4 Components .............................. 4 Intended use and place of use ........................5 Technical data ............................ -
Page 3: Introduction
1 INTRODUCTION This manual for the Catalina Semi-Cassette awning is for its users. It is an essential tool for the proper use and maintenance of the product. This manual must be kept intact in all its parts and in an easily accessible place until disposal of the awning. -
Page 4: Description Of Awning
3 DESCRIPTION OF THE AWNING The Catalina Semi-Cassette awning can be installed either on a wall or ceiling, with manual or motorized operation. In the latter case, on request it is possible to install the wind sensor, the rain sensor, the sun sensor and the manual override. -
Page 5: Intended Use And Place Of Use
CATALINA SEMI CASSETTE AWNING Use and Maintenance 1123 3.2 Intended use and place of use The function of the awning is to protect against sunlight and reduce reflection in the space under which it is located. The awning is intended to remain in the place it was installed. It is only meant to extend and retract to provide shade and glare control. -
Page 6: Using The Awning
CATALINA SEMI CASSETTE AWNING Use and Maintenance 1123 4 USING THE AWNING WARNING Before operating the awning, carefully read Chapter 2 on safety and Chapter 3.2 on intended use and location of use. WARNING Make sure that when opening/closing the awning, there are no individuals within its range of action. -
Page 7: Cleaning The Awning
CATALINA SEMI CASSETTE AWNING Use and Maintenance 1123 If any problems arise that are not included in the following tables, contact your local dealer. MANUAL AWNING PROBLEMS CAUSES SOLUTIONS The fabric does not roll up straight Incorrect symmetry of arms... -
Page 8: Routine Maintenance
See the instructions on assembly, installation and commissioning if it is necessary to disassemble the awning or parts thereof. Use original spare parts; otherwise the guarantee will no longer be valid. Request spare parts from SW Sun Control. 6 DISASSEMBLY AND DISPOSAL OF THE AWNING WARNING The awning must be disassembled by trained, qualified personnel.
