- Page 1 CATALINA SEMI CASSETTE AWNING Installation Manual 1123 CATALINA SEMI CASSETTE AWNING INSTALLATION MANUAL Toll Free 877-792-1775 | Fax 877-792-0031 swsuncontrolpro.com | sales@swsuncontrol.com...
-
Page 2: Table Of Contents
Diagrams of the covering and footprints ....................7 Cassette support brackets ........................8 Mounting brackets ............................. 9 Exploded view of Catalina Semi Cassette Awning components ............... 10 4 INSTALLATION OF MANUAL AWNING ................11 Fastening brackets to wall ......................... 11 Wall installation ............................ -
Page 3: Introduction
CATALINA SEMI CASSETTE AWNING Installation Manual 1123 1 INTRODUCTION This manual was prepared by the Manufacturer to provide the necessary information to those authorized to install and perform special maintenance on the product. It is prohibited to remove, rewrite or in any way modify the pages of the manual and their content. -
Page 4: Contents Of Packaging
CATALINA SEMI CASSETTE AWNING Installation Manual 1123 1.4 - Contents of packaging The awning is delivered complete with arms, fabric, control (manual or motorized) and any requested optional. INFORMATION AND PRECAUTIONS Never move the shoulders from the position in which they are supplied. -
Page 5: Technical Tables For Installation
CATALINA SEMI CASSETTE AWNING Installation Manual 1123 3 TECHNICAL TABLES FOR INSTALLATION 3.1 - Table of minimum dimensions MINIMUM FOOTPRINTS PROJECTION WIDTH (in) 1 PAIR OF ARMS 6'11" 8'6" 10'2" 11'9" 13'5" INFORMATION AND PRECAUTIONS It is advisable always to use an even number of arms. - Page 6 THE FOLLOWING TABLES ARE PURELY INDICATIVE. TO THE BEST OF OUR KNOWLEDGE THE INFORMATION IS UP TO DATE. SW SUN CONTROL DOES NOT PROVIDE ANY GUARANTEE REGARDING ACCURACY, RELIABILITY, AND COMPLETENESS OF THE INFORMATION CONTAINED HEREIN. INDEED, IT IS THE USER’S RESPONSIBILITY TO ENSURE THE SUITABILITY AND CORRECTNESS OF THIS INFORMATION.
-
Page 7: Diagrams Of The Covering And Footprints
CATALINA SEMI CASSETTE AWNING Installation Manual 1123 WIDTH up to 275 (in) COMPONENT PLACEMENT 6'11" 8'6" Shoulders 27.625 15.75 19.75 19.75 Mounting Brackets (4) Additional Mounting Bracket Center Center 10'2" 11'9" 13'5" Shoulders 15.75 15.75 15.75 Mounting Brackets (6) 7.875 94.5 7.875... -
Page 8: Cassette Support Brackets
CATALINA SEMI CASSETTE AWNING Installation Manual 1123 3.5 - Cassette Support Brackets WALL CEILING BRACKET 8.85 FIG. 1... -
Page 9: Mounting Brackets
CATALINA SEMI CASSETTE AWNING Installation Manual 1123 3.6 - Mounting Brackets WALL INSTALLATION .59” R.25” R.25” R.25” 1.77” .59” 1.18” 2.36” FIG. 5 CEILING BRACKET 1.79” .39” 3.34” 2.36” .59” 6.16” FIG. 6... -
Page 10: Exploded View Of Catalina Semi Cassette Awning Components
CATALINA SEMI CASSETTE AWNING Installation Manual 1123 3.7 - Exploded View of Catalina Semi Cassette Awning Components Gear Catalina arms with chain spin Hand brace Runners for spin arms Wall brackets Front bar Ceiling brackets Front bar end covers Square bar... -
Page 11: Installation Of Manual Awning
CATALINA SEMI CASSETTE AWNING Installation Manual 1123 4 INSTALLATION OF MANUAL AWNING The instructions below refer to wall-mounting; ceiling mounting is the same. If any options are in use, first read Chapter 6 "Optionals" CAUTION Ensure a minimum space of 19.75 inches between the open awning and any fixed obstacle. - Page 12 CATALINA SEMI CASSETTE AWNING Installation Manual 1123 SQUARE BAR WALL BRACKET TEMPLATE Scale 1:1...
- Page 13 CATALINA SEMI CASSETTE AWNING Installation Manual 1123 EXTRUDED WALL/CEILING SQUARE BAR BRACKET TEMPLATE Scale 1:1...
-
Page 14: Wall Installation
CATALINA SEMI CASSETTE AWNING Installation Manual 1123 INFORMATION AND PRECAUTIONS If the wall is off-square, it may difficult to install the awning on the mounting brackets. It is therefore advisable to check the alignment of the brackets and to provide inserts to ensure proper alignment for good installation. - Page 15 CATALINA SEMI CASSETTE AWNING Installation Manual 1123 CAUTION Make sure that when opening/closing the awning, there are no individuals within its range of action who are not involved in the work. FIG. 4 4) Once you reach the desired inclination, fasten the awning in position by tightening the screw (D) using a 3 mm Allen wrench.
-
Page 16: Installation Of Motorized Awning
CATALINA SEMI CASSETTE AWNING Installation Manual 1123 5 INSTALLATION OF MOTORIZED AWNING The instructions below refer to wall-mounting; ceiling mounting is the same. If any options are in use, first read Chapter 6 "Optionals" CAUTION IT IS PROHIBITED to install the motorized product in an explosive atmosphere. -
Page 17: Special Maintenance
CATALINA SEMI CASSETTE AWNING Installation Manual 1123 7 SPECIAL MAINTENANCE 7.1 - Troubleshooting table MANUAL AWNING PROBLEMS CAUSES SOLUTIONS The fabric does not roll up straight Incorrect symmetry of arms See manual for Assembly, Chap. 7 Uneven fabric Roll the fabric all the way back up...
