Reaction Tune
When the Spectrum Scout is in FILTER mode it can Reaction Tune a receiver connected through the
CI5 port on the top panel. Following are the procedures for Reaction Tuning the various receivers that
are compatible with the Spectrum Scout.
1. Press the FUNCTION button until Filter Mode is displayed. It must display Enabled.
2. Press the FUNCTION button until Interface Type is displayed. It must display Reaction Tune.
3. Press the FUNCTION button until Receiver Type is displayed. There are three options.
A. CI5: Following are the current CI-5 compatible receivers that the Spectrum Scout is
capable of Reaction Tuning.
The ICOM R10 and R7100 require special default settings for Reaction Tuning with the
Spectruml Scout.
ICOM R10:
ICOM R7100: Baud Rate = 9600, Transceive Mode = ON
9
ICOM R10, R20, R7000, R7100, R8500 and R9000.
Radio Shack PRO 2005/2006 (with OS456/Lite installed), Radio
Shack PRO 2035/2042 (with OS535 installed).
Optoelectronics R11 and Optocom.
Baud Rate = 9600, TRN = ON, CI-V ADDRESS = 52
