B. AOR: The Spectrum Scout can Reaction Tune the AOR AR8000 and AR8200.
C. PCR1000: The Spectrum Scout can Reaction Tune the ICOM PCR1000. The CBPCR Reaction
Tune cable is required and it interfaces through the RS232 jack on top of the Spectrum Scout. The
PCR1000 part of the cable plugs into the DB9 connector on the back of the receiver. Since the
PCR1000 has no hardware volume or squelch controls the Spectrum Scout is capable of controlling
these functions as well. See page 7 for details.
ICOM, OptoScan and Optoelectronics Optocom
Optoelectronics R11
AOR AR8000
AOR AR8200
ICOM PCR1000
The Spectrum Scout must send an initialization command to the receiver. Make sure the
Spectrum Scout is turned off. Turn the receiver on first then turn on the Spectrum Scout.
Cables Required For Reaction Tune
IMPORTANT:

Reaction Tune

CBCI5
CBRT
RT8000
RT8200
CBPCR
10
