Function Button
Frequency Display The two options for frequency display are Channel or Measured. The channel
frequency will be the actual channel that the transmitter is on and a measurement may look some-
thing like this 454.1250. The Measured frequency will be the actual frequency that is coming from
the transmitter and a measurement may look something like this 454.1248.
Interface Type Switch between CI-5 Command and Reaction Tune. CI-5 is used when interfacing
to a PC for memory download and datalogging. Reaction Tune is used when interfacing to compati-
ble receivers.
Receiver Type CI5 for ICOM, OptoScan and Optoelectronics receivers. AR8000 for AOR
receivers. PCR1000 for the ICOM PCR1000.
PCR1000 Volume When interfaced to an ICOM PCR1000 in Reaction Tune mode you may control
the volume of the receiver by pressing the UP/DOWN arrow button. See page 10 for details.
PCR1000 Squelch When interfaced to an ICOM PCR1000 in Reaction Tune mode you may control
the squelch level of the receiver by pressing the UP/DOWN arrow button. See page 10 for details.
Auto Power Off Enabled allows unit to automatically shut off after two minutes of inactivity.
Disabled will not allow the unit to shut off unless done so with the Power button.
Beeper Pressing the UP/DOWN arrow buttons will Enable or Disable the beeper. Each time a sig-
nal is detected the Digital Scout will beep once.
Vibrator Pressing the UP/DOWN arrow buttons will Enable or Disable the vibrator. Each time a
signal is detected the Digital Scout will vibrate for two seconds.
Note: If both the Vibrator and the Beeper are Enabled, only the Vibrator will function.
5
