DPG1M

The DPG1M has three operation buttons.
Each button has a specific function:
Symbol Description
Reminder
Bluetooth
Favourite
Operate the desk panel by tilting it.
1. Tilt and hold up DPG1M to drive desk up, press and hold down DPG1M to drive desk down.
2. Release DPG1M when you have reached your requested position.
Figure 8: Tilt and hold the DPG1M to drive the desk up
Desk height limits
In case the desk cannot be operated in its entire span (e.g. a shelf is blocking the upwards movement or a
filing cabinet is placed under the desk and blocking the downwards movement), it is possible to set an upper
limit and a lower limit for the desk height.
Setting upper limit
1. Adjust desk to maximum allowable height.
2. Press and tilt DPG1M up at the same time until light flashes.
3. Release and DPG1M.
Setting lower limit
1. Adjust desk to minimum allowable height.
2. Press and press DPG1M down at the same time until light flashes.
3. Release and DPG1M.
Figure 7: DPG1M operation buttons
Function
Setting reminders
Connecting the Desk Control
®
Saving favourite positions
App via Bluetooth
TM
Figure 9: Press and hold the DPG1M to drive the desk down
Page 21 of 71
wireless technology
®
