Page 1
DPG Desk Panel User Manual: DPG1M LINAK.COM/DESKLINE...
Page 2
• Displays actual height • Works via Bluetooth Low Energy Technology ® • Displays error codes and links to LINAK website • Available in English, German, French, Spanish, support Italian, Korean, Chinese and Japanese • Up to 4 memory positions...
Page 3
Operation of the DPG series: The desk panel is operated by tilting; Tilt and hold the DPG up to make the desk drive up, press and hold the DPG down to make the desk drive down. Release the DPG when you have reached your requested position. Figure 1: Tilt and hold the DPG1K to make the desk drive up Figure 2: Press and hold the DPG1K to make the desk drive down...
Page 4
Operation of the DPG1M Storing the memory positions Memory positions The DPG1M has a “store memory” button to the right symbolised with a star. Adjust the desk to a preferred position and press the “Star”-button for 2 seconds. The LED will now blink white two times to indicate that saving the position is in progress.
Page 5
Driving to memory positions After storing the memory positions, the positions can be reached simply by tilting the DPG1M. Tilt and hold - when a stored position is reached, the desk stops. This way the user can easily change between sitting and standing position without looking at the DPG1M in the meantime.
Page 6
Erase memory positions Pressing the “Memory” button for 8 seconds will erase all saved memory positions. The LED will blink red to indicate when the action is completed. Connecting Bluetooth ® Pressing the Bluetooth button in the middle for 2 seconds will enable pairing mode. ®...
Page 7
Reminder Setting the reminder interval The DPG1M has a “Reminder” button to the left symbolised with a bell. Pressing this button will adjust the interval of how often to get reminders to change position. The LED will light up in 3 different intensities which each represents an interval and the 3 standards are: - Interval 1: Reminder after 55 minutes sitting - Interval 2: Reminder after 50 minutes sitting...
Page 8
LED reminder The LED is placed in the lower left corner of the DPG1M. The LED is intended to indicate the status of the desk user. The status depends on the reminder interval chosen. When the user is in position in an appropriate amount of time according to the interval, the LED calmly pulsates green.
