NINJA
Proudly Made in the USA
DIN 300 PCP FILL STATION
SAFETY FIRST!
ALWAYS KEEP ALL PETROLEUM LUBRICANTS AWAY FROM PARTS OF
THE PCP FILL ADAPTER. PETROLEUM LUBRICANTS MAY CAUSE FIRE OR
EXPLOSION IF ENTERED INTO THE HIGH PRESSURE TUBE OF YOUR PCP
AIRGUN.
ALWAYS READ AND UNDERSTAND ALL FILL STATION INSTRUCTIONS.
WARNING: Compressed air will rush out of the vent hole (part #4) when relieving
pressure from the fill hose. Use caution in directing the venting air.
ALWAYS WEAR GLOVES AND SAFETY GLASSES WHEN OPERATING THIS
FILL STATION!!
WARNING: Do NOT disconnect the hose under pressure. Disconnecting the hose
under pressure could cause damage to the hose fitting and personal injury to the
operator.
