NINJA AIR SYSTEMS
Series 3000 PCP FILL STATION
FOR 3000 PSI MAXIMUM SERVICE
PRIOR TO USE READ AND UNDERSTAND ALL FILL STATION
KEEP ALL PETROLEUM LUBRICANTS AWAY FROM PARTS OF THE PCP
FILL ADAPTER. PETROLEUM LUBRICANTS MAY CAUSE FIRE OR
EXPLOSION IF INTRODUCED INTO THE HIGH PRESSURE TUBE OF YOUR
Date: February 2013
Proudly Made in the USA
SAFETY FIRST!
INSTRUCTIONS.
PCP AIRGUN.
1
Advertisement
Table of Contents
Related Manuals for Ninja 3000 Series
Summary of Contents for Ninja 3000 Series
- Page 1 NINJA AIR SYSTEMS Proudly Made in the USA Series 3000 PCP FILL STATION SAFETY FIRST! FOR 3000 PSI MAXIMUM SERVICE PRIOR TO USE READ AND UNDERSTAND ALL FILL STATION INSTRUCTIONS. KEEP ALL PETROLEUM LUBRICANTS AWAY FROM PARTS OF THE PCP FILL ADAPTER.
- Page 2 SETTING UP THE NINJA PCP FILL ADAPTER Your fill adapter is equipped with a standard “UFA” fitting on the input side. This fitting will connect to any Ninja high pressure regulator. On the backside of the fill station is a vent port.
- Page 3 www.Ninjapaintball.com 1.0 OPERATION with a HIGH PRESSURE COMPRESSED AIR BOTTLE THIS FILL ADAPTER WILL VENT GASES STORED UNDER HIGH PRESSURE MAKE CERTAIN THE VALVE VENT KNOB (part #5) IS CLOSED (turned fully clockwise) BEFORE CONNECTING TO A HIGH PRESSURE COMPRESSED AIR BOTTLE! 1.1 Close the vent station (part #4) by turning the vent knob (part #5) fully in a clockwise direction, do not over tighten.
- Page 4 WARNING: Do NOT disconnect the hose under pressure. Disconnecting the hose under pressure could cause damage to the hose fitting and personal injury to the operator. 3.0 Maintenance and Care of the Ninja PCP Fill Adapter Keep the Fill Adapter clean and dry.
