Rear
Rear view of the Firebox:
Cooling fans
The fans decrease the internal temperature of the device. When you connect the Firebox to power,
the fans start at a low speed. When you power on the Firebox, the fan speed increases to
maximum RPM. The device adjusts the fan speed based on the external temperature, CPU load,
and power supply load.
Power switch
Controls the power supplied to the Firebox. The Power switch activates both power supplies.
AC receptacles
Each AC receptacle accepts a detachable AC power cord supplied with the Firebox. Each power
supply is a WatchGuard standard auto-sensing AC power supply.
Replaceable power supplies
There are two power supplies on the Firebox M5800, each with a power indicator at the top.
For instructions to install a replacement power supply, see
Power Indicator Color
Green flashing
Green solid
Red flashing
https://www.watchguard.com/help/docs/help-center/en-US/Content/en-US/Hardware-Guides/firebox-m5800-hardware-guide.html
For a list of compatible transceivers, see
in the WatchGuard Knowledge Base.
XTM Appliances
When the Firebox is powered off, power supply fans continue to run at a lower RPM
while the Firebox is connected to power.
If a power supply fails or is not connected to power, the other power supply has a
higher load, and the power supply fan is louder.
Power Supply Status
Power is connected to at least one power supply, device is powered off
Power is connected, device is powered on
Power is not connected or power supply failed, device is powered on
Firebox M5800 Hardware Guide
Supported transceivers for Firebox and
Power Supply Installation.
