  • Page 1 USER MANUAL Si-CA 230 GAS ANALYZER www.sauermanngroup.com...

  • Page 2: Table Of Contents

    Table of contents 1. Safety instructions ..............................5 1.1 Warnings ................................5 1.2 Environment protection ............................ 5 1.3 Symbols used ..............................5 2. Introduction ................................6 2.1 Analyzer description ............................6 2.2 Main features ..............................7 3. First Start-up ................................ 10 4.

  • Page 3: Safety Instructions

    Send back the device at its end of working life to a waste collection center for electrical and electronic components (ac- cording to local regulations), or send it back to Sauermann to ensure a required waste collection in the respect of the environment.

  • Page 4: Introduction

    Color touch screen, 10.9 cm (4.3’’), 480 x 272 pixels with backlight. It allows to display measured parameters in a more The Si-CA 230 is a flue gas analyzer for emissions monitoring of boiler, engine, & other combustion applications with comfortable format for the operator.
  • Page 5 • ΔP: Differential pressure (also for Gas Tightness Test) tion, BS 7967:2015, BS EN 50543:2011, UNE 60670-10 and ES.02173.ES Hereby, Sauermann Industrie SAS declares that the radio equipment type Si-CA 230 is in compliance with Directive • Draft: Draft (static pressure) measurement 2014/53/EU.

  • Page 6: First Start-Up

    3. First Start-up 4. Features 4.1 General features When the analyzer is first started up, parameters of the analyzer must be set. Dimensions 28 x 11.2 x 5.5 cm (11 x 4.3 x 2’’) Keep pressed for 3 seconds to turn ON the analyzer. Weight 825 g (30 oz) DO NOT insert the gas probe in the flue/chimney/stack at this time.

  • Page 7: Parameter Specifications

    1 ppm < 60 s In case of any default or damage of the instrument, Sauermann After-sales service shall be ±5 % rdg > 100 ppm contacted. On the back of the analyzer, there is a label with the analyzer serial number. This ±1.5 ppm <...

  • Page 8: Perform A Draft Measurement With The Draft Probe

    5.3.2 Perform a draft measurement with the draft probe 5.8 Use the Zoom function The draft measurment can be performed thanks to the draft probe avalaible as option. From the gas analysis screen, the zoom function is available using The initial screen displays 8 measured values. If the draft probe is used, it will be necessary to drill another hole dedicated to this draft meas- urement in the duct.

  • Page 9: Set The General Parameters Of The Analyzer

    6. Set the general parameters of the analyzer 6.8 Set the brightness of the screen “Settings > General” screen is displayed. The settings menu allows to set the general parameters of the analyzer: • Tap “Brightness”. • Time • Set the brightness level from 1 to 5. •...

  • Page 10: Set The Parameters Of The Analysis

    7.1 Set the fuel If a very specific fuel must be created please contact the Sauermann Service Center for further information. This part allows to select the required fuels for the gas analysis but it also allows to add customized fuels.

  • Page 11: Set The Co Pump Cut-Off Level

    7.6 Set the NOx factor • Tap "CO dilution threshold". • Enter the required threshold between 100 and 4000 ppm. This part allows to set the NOx factor, which is the assumed NO to NO ratio used to calculate NOx when the NO sensor is included but the NO is not included.

  • Page 12: Zero Draft Sensor

    Alarms can be revised later (for example, different threshold value) if needed. During the measurements, an alarm remains ON even if the measurement goes below or above the threshold value until it is acknowledged. If the alarm is acknowledged and the value is always in alarm, the alarm remains ON. 7.11 Set the air temperature This part allows to set the air temperature for the incoming air into the combustion equipment if known.

  • Page 13: Set The Stack Cross-Sectional Area

    8. Set the measuring unit This part allows to define the measuring unit for each parameters measured or calculated by the analyzer. The following unit is avalaible according to the parameter: • Temperature: °C, °F • Pressure: mbar, iwg (inches water gauge), mmwg, mmHg, Pa, hPa, kPa, psi •...

  • Page 14: Set The Data Saving

    9. Set the data saving 10. Set the printer This part allows to define the data saving mode: manual or data logger This part allows to set the printer specifications: printer connection, custom header and number of copies. “Settings” screen is displayed. This printer is avalaible as option.

  • Page 15: Service And Calibration

    11.1.2 Service center contact • Model number / Serial number “Service / Calibration” screen is displayed. • Firmware version • Tap “Service Center Contact” to display the address of the Sauermann Service Center. • Battery status 11.1.3 Perform calibration • Memory status This screen allows the user to perform a calibration on a gas sensor.

  • Page 16: Perform Other Measurements

    12. Perform other measurements If Preliminary test is selected: • Select the fuel: natural gas or LPG. The analyzer can perform other measurements than a gas analysis: • Read the gas pressure inside the pipe. • CO monitor • Tap “Start stabilization”. •...

  • Page 17: Gas Pump Flow Rate

    12.3 Gas pump flow rate • For proper calculations of volumetric flow rate and mass flow rate, enter correct stack cross-sectional (see chapter "7.13 Set the stack cross-sectional area" on page 24) This screen shows the real-time measured flow rate of the gas passing through the analyzer as performed by the main flue gas sampling pump.

  • Page 18: Maintenance Of The Analyzer

    • CO-H2 sensor must be in CO position to replace it. To ensure the measurement accuracy, sensors have to be calibrated only in Assistance center qualified by • NO or low NO sensor must be in 6 position Sauermann. • NO , SO...

  • Page 19: Replace The Internal Filter

    14. Optional accessories 13.4 Replace the internal filter The following accessories are available: Part number Description Illustration The filter inside the analyzer is recommended be changed once a year. • Remove the protective rubber holster. 27520 (NO) NO or Low NO sensor for NOx 27521 (Low NO) •...

  • Page 20: Spare Parts

    15. Spare parts Sauermann Industrie Sauermann Italia SA The following spare parts are available: ZA Bernard Moulinet Via Golini 61/10 Item number Description 24700 Montpon 40024 Castel S.Pietro Terme (BO) France T. (+39)-051-6951033 27697 Bottom Shell Piece with Hose & Tc Connection Ports T.
