E2S A100 AlertAlarm Instructions/Service Manual page 4

Construction Product Regulation
•
A100DC024 is compliant to EN54-3:2001+A1+A2
•
Alarm devices – Sounder for use in fire detection and fire alarm systems installed in and around buildings
•
Type 3R / 13, IP66, Independently tested to EN60529:1991, (IP33C Compliant to EN54-3)
•
Type B Product, For Indoor & Outdoor use
• Observe Precautions for handling electrostatic devices
•
-25°C to +55°C compliant to EN54-3
•
Cable Glands must be suitably sealed and meet minimum IP33 for EN54-3 applications
•
Storage Temperature: -40°C to +70°C
•
Maintenance – None
•
Mounting - Units can be mounted using the 2-off ø6mm holes in the mounting lugs or through the back of
the housing using the supplied gasket seal.
Approved Tones for EN54-3 Applications:
•(Alternating Tone) 800/1000Hz @ 2Hz Alternating Tone 44
•(Rising Tone) 500/1200Hz @ 0.26Hz (3.3s on, 0.5s off) Tone 8
•(Fainting Tone) 1200/500Hz @ 1Hz Tone 2
•(Continuous Tone) 800Hz Tone 21
•(Pulsed Tone) 660Hz (150mS on, 150mS off) Tone 31
•(Alternating Tone) 544Hz(100mS)/440Hz (400mS) Tone 5
Horizontal Sound Output Max Voltage
Tone Tone
Angle
44 8
15° 98 99.9
45° 97.8 100.1
75° 101.5 102.9
105° 101.4 102.8
135° 97.4 100
165° 97.5 99.6
Vertical Sound Output Max Voltage
Tone Tone
Angle
44 8
15° 96.3 99.8
45° 97.6 99.9
75° 101.3 103
105° 101.3 102.8
135° 97.4 99.9
165° 96.7 100
E2S Warning Signals Impress House, Mansell Road, Acton, London W3 7QH
(60 Vdc) LAFmax,T dB(A)
Tone Tone Tone
2 21
99 95.7
99 97.6
102.4 101.4
102.5 101.4
98.9 97.2
98.9 95.8
(60 Vdc) LAFmax,T dB(A)
Tone Tone Tone
2 21
99 95.5
98.8 97.4
102.5 101.4
102.4 101.3
98.8 97.6
99 95.5
A100DC024 @ 1m
Tone Tone
31 5 44
94.8 95.4 94.7
94.7 96.6 95
98.3 100.4 98.7
98.1 100.4 98.6
94.9 96.4 94.6
94.7 95.4 94.3
Tone Tone
31 5 44
94.1 95.3 93.1
94.5 96.3 94.8
98.1 100.5 98.5
98.2 100.5 98.5
94.5 96.3 94.6
93.9 95.4 93.6
sales@e2s.com e2s.com
Order Code: A100DC024
Voltage Range: 18-60Vdc
Nominal Voltage: 24Vdc / 48Vdc
Max Current: 125mA @ 60Vdc
DP-2821-CPR-0107
S36282
Horizontal Sound Output
Min Voltage (18 Vdc) LAFmax,T dB(A)
Tone Tone Tone
8 2 21
96.8 95.9 93
97 96 94.8
100.2 99.5 98.8
100.2 99.5 98.8
96.9 95.9 94.5
96.4 95.8 93
Vertical Sound Output Min Voltage
(18 Vdc) LAFmax,T dB(A)
Tone Tone Tone
8 2 21
96.7 96 92.8
96.8 95.7 94.6
100.1 99.5 98.7
100.1 99.5 98.7
96.8 95.8 94.8
96.9 96 92.7
D218-00-001-IS Issue 1 10/05/2021
21
2821
Tone 31 Tone 5
91.9 92.7
92.1 94
94.9 97.9
94.9 97.9
92.2 93.8
91.8 92.8
Tone 31 Tone 5
91.2 92.6
91.9 93.8
95 97.8
95 97.7
91.9 93.7
91.1 92.7
