Q-Stoves Q05 Operation Manual
Outdoor wood pellet heater
Hide thumbs
Also See for Q05:
- Use and care manual (4 pages) ,
- Assembly instructions (4 pages) ,
- Assembly instructions manual (6 pages)
Table of Contents
Advertisement
Operation Manual
OUTDOOR WOOD PELLET HEATER
Model:Q05, Q05C, Q-Flame
IMPORTANT:
Your safety is very important, please read this manual thoroughly before you install,
operate or maintain this heater. Keep this manual for future reference. If you have
questions about assembly, operation, service or repair of this stove, please reach
out to us directly.
WARNING:
FOR OUTDOOR USE ONLY!
HOT SURFACE WHEN BURNING! KEEP CHILDREN AND
PETS AWAY.
SAVE THIS MANUAL FOR FUTURE REFERENCE
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Q-Stoves Q05
Summary of Contents for Q-Stoves Q05
- Page 1 Operation Manual OUTDOOR WOOD PELLET HEATER Model:Q05, Q05C, Q-Flame IMPORTANT: Your safety is very important, please read this manual thoroughly before you install, operate or maintain this heater. Keep this manual for future reference. If you have questions about assembly, operation, service or repair of this stove, please reach out to us directly.
-
Page 2: Table Of Contents
Table of Contents Important Warnings…………………………………………… .…………………………………………2-3 Specification………………………………………………………… ..………………………………………… 4 Installation………………………………………………………………………… .…………………………….5 Operation………………………………………………………………………….………………………………5-6 Storage……………………………………………………………………………..……………………………….6 Maintenance…………………………………………………………………………………………………… .7 How to stop the stove/heater during use/firing…………………………….……………………………….7 Service and Warranty Information…………………………………….………………………………..7 Warranty Terms………………………………………………………………………………………………… .7 FAQ /Best practices………………………………………………………………………………………………….8 IMPORTANT WARNINGs • Fuels used in gas,wood or oil-fired appliances and the products of combustion of such fuelscontain chemicals known to the State of California to cause cancer,birth defects and other reproductive harm.California Health and Safety Code Sec.25249.6 •... - Page 3 ash drawer when the heater is in use. Tap holes are provided in the feet for stabilization of the stove. It is strongly recommended that the stove be stabilized for safety precautions. Do not spray aerosols near the heater while in use. Do not clean heater with combustible or corrosive cleaners.
-
Page 4: Specification
Specifications* Model No………………………………………………………………………………………………………. Q05C Type of Fuel………………………. Woodpellets1/4’’ (.6cm) diameter by 1/2’’ (1.2 cm) Input rating………………………………………………………………………. 106,000 BTU/HR MAX Overall Height……………………………………………………………………………………76” (193cm) Stove Height………………………………28/19” (71/48cm) (with/without hopper) Stove Diameter…………………………………………………………………………………….12” (30cm) Reflector Diameter………………………………………………………………………………….24” (60cm) Chimney Diameter…………………………………………………………………………………….6” (15cm) Window……………………………………………………………………………4 ½ x 3 ½”(11.4cmx8.9 cm) Ignition ……….……………………manually light with a match and alcohol gel firelighter Electrical connection.………………………………………………………………………... -
Page 5: Installation
1. Installation 1.1 Installation warning The installation must conform with local,state and federal codes.In absence of such codes,install in accordance with the current American National Standard(ANSI)/National Fire ProtectionAssociation(NFPA)codes. 1.2 Minimum clearances A minimum 3ft. (.914 M) clearance from this heater and all its parts to combustible materials must be maintained at all times while the heater is in operation. -
Page 6: Storage
INITIAL FIRING OF THE HEATER:On initial firing only, fill the hoppers with about 5 Ibs. of pellets each, make the feeding tubes full.One time initial firing needs to be done to cure the paint and burn off any oils or residue on the unit.Open the air damper on the heater door and leave it open for the entire initial burn period.Fire the unit and let it burn through all of the pellets and then let the heater cool.The unit is now fully cured.When curing, the paint gives off smoke.This will happen for about the first 15 minutes of operation.Do not breath... -
Page 7: Maintenance
4. Maintenance 4.1 To obtain the best performance from your heater make sure you perform the following maintenance procedures on a regular basis. 4.2 After a burn and once the heater is completely cooled,clean out any remaining ashes from on top of the fire grate and in the ash pan.Do not dump an ash pan with hot embers or pellets into a garbage can or any other combustible area.It will start a fire. -
Page 8: Faq /Best Practices
FAQ / Best Practices Q: Why is my stove not getting as hot as is says it can? How do I reach maximum heat output? A: Using the pick tool provided, insert into the chromed eyelet just beneath the door and mildly shake the shaft, thus causing the wood pellets to level out and burn extremely hot. - Page 9 A: Congratulations, you got the stove really hot and it’s doing its job. Now you need to cool the hoppers off. Best thing to do is open the inner lids that touch the chimney. This will allow the hoppers to get cool air to them. You might also want to stir the pellets in the hoppers with the pick tool.
- Page 10 SEE MORE STOVES AND FIREPLACE PRODUCTS, CHECK THE ELECTRONIC VERSION OWNER’S MANUAL AND INSTALLATION VIDEO, PLEASE VISIT: QSTOVES ® WWW.QSTOVES.COM CAUTION! WEAR PROTECTIVE GLOVES WHEN ASSEMBLING. BLACK PAINT IS EXTREMELY FRAGILE PRIOR TO CURING. Qstoves Patented: QSTOVES INC. Copyright 2020 All Rights Reserved For patent, trademark and copyrighted information please email vp@qstoves.com v.6.0.2...
