Summary of Contents for Boundless ADDS 60

  • Page 1 Boundless Technologies User’s Guide...
  • Page 2 All features, functions, and operations described herein may not be marketed by Boundless Technologies in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult your Boundless Technologies representative or Boundless Technologies office for information that is applicable and current.
  • Page 3: Table Of Contents

    Contents User’s Guide ... Title Contents ...ii Note to Installers ... v Site Preparation ...v Preface ... v Notices... vi Trademarks and Service Marks ... vi Electronic Emission Notices... vii Federal Communication Commission (FCC) Statement ... vii Canadian Department of Communications Compliance Statement... vii Avis de conformité...
  • Page 4 Setting Connection A: Host DCE... 12 Setting Connection B: Host DTE ... 12 Setting Connection C: RS-232 with Modem... 12 Setting Connection D: RS-232-C with Modem... 12 Setting Connection E: Printer... 12 Setting Connection F: RS-232-C Printer ... 12 Setting Connections G and H: Parallel Printer... 12 STEP 7 –...
  • Page 5 Clock ...34 Calculator...35 ASCII Chart ...36 Diagnostic Window ...36 Appendix... 37 Local Keys...37 Page Configurations...40 Technical Support...41 Index ... 42...
  • Page 6: Note To Installers

    This product conforms with the protection requirements of EU Council Directive 89/336/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility. Boundless Technologies cannot accept responsibility for any failure to satisfy the protection requirements resulting from a non-recommended modification of the product, including the fitting of option cards not made by Boundless Technologies.
  • Page 7: Notices

    This publication could contain technical inaccuracies or typographical errors. Please report any such problems to Boundless Technologies. This publication may refer to products that are announced but are not currently available in your country. Boundless Technologies makes no commitment to make available any unannounced products referred to herein.
  • Page 8: Electronic Emission Notices

    Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. Boundless Technologies is not responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modifications to this equipment.
  • Page 9: Safety Notices

    Safety Notices Danger Notices A danger notice indicates a hazard that could possibly cause death or serious personal injury. The following danger notices are used throughout this manual: DANGER: To prevent a possible electrical shock when installing the device, ensure that the power cord for that device is unplugged before installing signal cables. DANGER: To prevent a possible electrical shock when adding the device to a system, disconnect all power cords, if possible, from the existing system before connecting the signal cable to that device.
  • Page 10: How To Connect Or Disconnect The Terminal

    How to Connect or Disconnect the Terminal To Connect: First, turn everything OFF. Attach all cables to devices. Attach signal cables to receptacles. Attach power cord to outlet. Turn device ON. Note: In the UK, by law, the telephone cable must be connected after the power cord.
  • Page 11: Chapter 1

    Setup also has a Quick menu that summarizes the options most critical to the operation of the terminal. The function keys at the top of every menu facilitate movement between the menus. Features Compatibility The ADDS 60 terminal is compatible with the following terminals: • ADDS-Viewpoint™ •...
  • Page 12: Character Sets

    Character Sets The ADDS 60 terminal supports the following character sets: • Numerous standard, graphic, and supplemental character sets • Support for different keyboard languages: US (English), UK (English), Danish, Finnish, French, German, Norwegian, Portuguese, Spanish, Swedish, Dutch, Belgian-Flemish, French-Canadian, Italian, Latin American, Swiss-French, Swiss-German, Turkish, Greek, Hungarian, Czech, Slovak, Polish,...
  • Page 13: Physical Features

    Physical Features 1. Keyboard Connector – insert the keyboard connector here. 2. Tilt and Swivel Base – use the tilt and swivel arrangement to adjust the viewing angle. Grasp the lower corners of the terminal and push up or down or twist left or right.
  • Page 14 & T ab Caps Lock < > Shift Ctrl 101-key EPC Keyboard - U.S. ASCII Keyboard & Caps Lock < > Shift Ctrl 102-key EPC Keyboard - International 106-key PC/+ Keyboard - U.S. ANSI Keyboard Caps Scroll Print Scroll Pause Lock Lock Lock...
  • Page 15: Usage Notes

    Usage Notes The following notations and symbols are used in this manual: • Ctrl+F1: the two keys, Ctrl and F1, are to be pressed simultaneously. • 1-num or 1-alpha: specifies that the number must be generated either from the numeric or alphanumeric keypads. •...
  • Page 16: Understanding Communications

    Understanding Communications This terminal is equipped with three ports. The two serial ports are intended for connecting to a host, a modem, or a serial printer. The remaining port is a Centronics-compatible printer port. The port you use as the printer port depends on whether you have a serial or a parallel interface to the printer. Also, if you use the parallel port for a printer (or don’t connect to a printer), you can use the serial ports to connect to two host computers.
  • Page 17: Host/Printer Port 2

    Host/Printer Port 2 This port, labeled “SES2-AUX,” is designed to connect to a host connection (computer or modem) or a serial printer, and can operate from 110 to 38,400 baud. This port uses an RS-232-C interface via a DB25P female connector, and is configured as a DCE (Data Communication Equipment) device. The following illustration shows the pins assignments: Host/Printer Port 2 Pin Assignments Note:...
  • Page 18: Terminal To Modem (Dce) Or Host

    Terminal to Modem (DCE) or Host Refer to the diagram below to understand why you may need a null modem adapter when connecting the second serial port (SES2-AUX) to a modem or a DCE host. The first host connects directly without a null modem since it is a DTE device. Terminal to Host (DTE) or Printer Refer to the diagram below to understand why a null modem adapter may be needed when connecting the first serial port (SES1-EIA) to a host port without a modem (most serial printers are DTE devices and most hosts are not).
  • Page 19: Understanding Screen Display And Pages

    Understanding Screen Display and Pages This terminal offers a variety of screen lengths, including 26, 30, 44, or 52 lines. These numbers include the top and bottom status lines (or label line), as well as the lines used to display data. A “page” of terminal memory represents the total number of lines that can be accessed, whether or not they are all viewable on the screen at once.
  • Page 20: Chapter 2

    Chapter 2 Installing This chapter provides a walk-through approach to the installation of your terminal. This approach enables you to physically connect the terminal to a printer and a host computer or modem, as well as to configure the Setup menu to suit your requirements and preferences. The terminal offers considerable flexibility.
  • Page 21: Step 6 - Using Communications Setup

    STEP 6 – Using Communications Setup To complete this step, you must recall the letters next to the connections that you made in Step 2. Also, you must be aware of the port/session designations made in Step 3 (see the Host/Printer Connection diagrams later in this chapter). The procedures below correspond directly to the individual connections made.
  • Page 22: Step 7 - Using Emulation Setup

    2. In the Setup Quick (press F1) menu, set the Printer portion of the “Host/Printer” selection to “Para” without changing the current Host option (“xxxx/ Para”). STEP 7 – Using Emulation Setup This step requires setting a selection in the Setup menu to configure the “Emulation” of the terminal. Determine the emulations with which your applications run. 1.
  • Page 23: Host/Printer Connection Guide

    Host/Printer Connection Guide SES1-EIA (DTE) DTE Host* Connection A: Connect a null modem adapter between the host cable and the EIA port. DCE Host or Modem Connection C: Connect the host or modem cable directly to the EIA port. DTE Serial Printer** Connection E: Connect a null modem...
  • Page 24: User Settings Chart

    User Settings Chart Use the following chart to document your system and terminal settings: Parameters Examples Connections made C and H Host/Printer EIA/Para Emulations ADDS-VP Baud 9600 Data Bits Stop Bits Parity None Parity Check Flow Control (In)* Xon-Xoff Flow Control (Out)** Xon-Xoff Modem Control Incoming flow control on the host should correspond to “EIA (or Aux) Rcv.”...
  • Page 25: Chapter 3

    Chapter 3 Using Setup The Setup menu serves as your control panel for this terminal. From the setup menu, you can configure the terminal to communicate with the host computer and set your personal preferences. Overview As you use the thirteen menus within the setup menu, keep in mind the following: •...
  • Page 26: Setup Map

    Setup Map Menu (Not all items appear for every emulation, keyboard, or video mode.) Quick Emulation, Comm Mode, EIA/AUX Baud Rate, Enhanced, EIA/AUX Data Format, Language, Sessions, Host/Printer General Emulation, Enhanced, Auto Wrap , Auto Font Load, Auto Page, Auto Scroll , Monitor Mode, Screen Saver, Bell Volume , Warning Bell, Host/Printer, Bell Length, Cursor Dir, Setup Language Display...
  • Page 27: Quick Menu (F1)

    Quick Menu (F1) Emulation: ADDS VP, Wyse 60, Wyse 50+, PC Term, VT300/8, VT300/7, VT200/8, VT200/7, VT100, SCO Console, AT386, TVI 925 Choose the “personality” of the terminal (the way in which it responds to commands). Note that SCO Console and AT386 emulations are not available with the ANSI keyboard.
  • Page 28: General Menu (F2)

    General Menu (F2) Note: This chapter lists all possible parameters for each menu, and all possible choices for each parameter. Depending on the emulation selected, and the key mode (ASCII or ScanCode), Setup will only present the valid set of parameters and choices in each menu. Emulation Choose the “personality”...
  • Page 29: Display Menu (F3)

    Display Menu (F3) Page Length: 24, 25, 42, 43, 48, 50, 84, 86, 96, 100, (168), (172), (192), (200), *24, *25, *42, *43 Choose the number of lines per page. As many as ten pages (0-9) may be available, but the number of pages in memory depends on the number of lines per page, the type of emulation, and whether 80-Only is selected for columns.
  • Page 30: Keyboard Menu (F4)

    Keyboard Menu (F4) Language: U.S., U.K., Danish, Finnish, French, German, Norwegian, Portuguese, Spanish, Swedish, Dutch, Belgian-Flemish, Fr-Canadian, Italian, Latin American, Swiss-French, Swiss-German, Turkish Choose the language type that matches your keyboard’s layout. Language: U.S., U.K., Danish, Dutch, Finnish, Belgian-Flemish, French, Fr-Canadian, German, Italian, Norwegian, Spanish, Swedish, Swiss-German, Swiss-French, Turkish Choose the language type which matches your keyboard’s layout.
  • Page 31: Keys Menu (F5)

    Keys Menu (F5) Enter Key: CR, CR-LF, TAB Choose the code the Enter key in the numeric keypad transmits. Return Key: CR, CR-LF, TAB Choose the code the Return key in the main alphanumeric keypad transmits. Alt Key (left): Meta, Compose, Funct, Scroll-Lock, Alt Key Choose how the left ALT key (or the Compose key on the ANSI keyboard) behaves.
  • Page 32 The three selections should either be kept in their defaults (as they appear on the keyboard), or all three should be changed to follow the mapping scheme described here. `~ Key: ` and ~ or ESC Choose the characters sent by the tic/tilde key. <or >...
  • Page 33: Ports Menu (F6)

    Ports Menu (F6) EIA Baud Rate: 134400, 115200, 76800, 57600, 38400, 19200, 9600, 4800, 2400, 2000, 1800, 1200, 600, 300, 150, 110 See the Quick menu earlier in this chapter. EIA Data Format: 7/1/N, 7/1/O, 7/1/E, 7/1/M, 7/1/S, 7/2/N, 7/2/O, 7/2/E, 7/2/M, 7/2/S, 8/1/N, 8/1/O, 8/1/E, 8/1/M, 8/1/S, 8/2/M, 8/2/N, 8/2/O, 8/2/E, 8/2/S See the description under Quick Menu (F1), on page 18.EIA (Aux) Parity Check: On, Off Choose whether the parity bit will be checked.
  • Page 34: Host Menu (F7)

    Host Menu (F7) Comm Mode: Full Duplex, Half Duplex, Full Block, Half Block Select the communications mode. Note: Half-duplex is not available when KeyMode is set to ScanCode. Receive <CR>: <CR>, <CR><LF> Select the way in which carriage returns received will be interpreted. Receive <DEL>: Ignore, Destruct <BS>...
  • Page 35: Print Menu (F8)

    Print Menu (F8) Print Mode: Normal, Auto, Controller Choose how printing is controlled: Normal indicates that printing is to occur when a print request (such as print screen) is received. Auto prints a line when the terminal receives a LF, a FF, or a VT code, or when autowrap occurs. Controller indicates that host data is sent to the printer (pass through mode).
  • Page 36: Ansi Emulations

    extended, only emulation indicator, Caps Lock, communications mode, protect, and write protect appear. Char Set: National, Multinational Choose whether the character set used is the 7-bit national chart or the 8-bit multinational chart when Language is not U.S. If you choose U.S., the character set becomes Multinational.
  • Page 37: Tabs Menu (F10)

    Tabs Menu (F10) Auto Init Tabs: On, Off When on, the tab settings always default at power up, as described under the next setting. Default Tabs: This action field sets tabs at every eighth column starting at column 9. When the cursor is placed in the Tab Map, the keys below will appear in the Choices field: <Space>...
  • Page 38: Program Menu (F12)

    Program Menu (F12) Program: F/Key, Sh-F/Key, Edit Key, Sh-Edit Key Specify the type of key to be programmed—function or edit key in its normal or shifted state. When Fkey Speed is Fast in the EMUL (F9) menu, the Program options are F/Key and Sh-F/Key. When SCO Console emulation is selected, the Program options are F/Key, Sh-F/Key, Ctl-F/Key, Ctl-Sh-F/Key, and Edit Key.
  • Page 39: Execute Menu (Prnt Scrn)

    Hint: • To program an ESC (escape) character into the key text, press Ctrl+[. • To program a DEL character into the text field, press Ctrl+Shift+* (alphanumeric keypad). • To program a carriage return or line feed into the key text field, press Ctrl+M or Ctrl+J, respectively. •...
  • Page 40: Edit Fields

    Edit Fields Setup uses overwrite mode in text editing fields. That is, the cursor keys cannot be used to move to a location in the text to insert characters. Upon entry to a text field, the cursor is placed at the last text location. Use the following keystrokes: •...
  • Page 41: Chapter 4

    Chapter 4 Desk Accessories This terminal features five desk accessories, which can be accessed one at a time through pop-up windows. Overview Desk Accessory Menu To see a menu listing the five desk accessories, press Ctrl+←. This function key: Note: To access this menu (with a PC keyboard), the selection “Desk Acc = ←”...
  • Page 42: Moving An Accessory Window

    Moving an Accessory Window To reposition any desk accessory window on your screen, hold down the Shift key while pressing a cursor control (arrow) key. Exiting an Accessory Window To exit any window and restore the original screen: On the PC keyboard, press Esc. On the ANSI keyboard, press F11.
  • Page 43: Clock

    Clock The clock menu (shown below) contains seven lines that you can modify: Jan. Date 1, 1995 Time 08:00:00 AM Display Type Column Alarm Set 12:00 PM Tone The following table describes the values you can set in the various fields: This field: Date Set the current date.
  • Page 44: Calculator

    Calculator The numeric keypad located on the right side of your keyboard serves as your calculator. See the figures below to relate the display to the keys on the numeric keypad that control it. Calculator Display (EPC keyboard) Note: The ANSI keyboard calculator display is identical to the PC/+ keyboard, save that the controlling keys on the numeric keypad differ: The ANSI keyboard control keys include PF1-PF4 keys and function keys F16-F20.
  • Page 45: Ascii Chart

    ASCII Chart When you open the ASCII Chart window (shown below), it appears centered on the character on which your cursor was last placed, and that character is highlighted. Characters appear in decimal, octal, hexadecimal, and binary number representations. The CHAR column contains the ASCII representation of the character. Use the following keys to change the display of the ASCII chart: The following keys control the ASCII Chart: Press this key:...
  • Page 46: Appendix

    Appendix Local Keys Scan Code Action Mode PC Keyboard Toggle Caps Lock Lock Toggle Num Lock Num+Lock Toggle Scroll Lock Scroll+Lock Toggle Auto Print Ctrl+Print+Scre Toggle Block Mode Ctrl+Shift+Paus Toggle Monitor Mode Ctrl+Shift+1 Ctrl+Shift+End Toggle Ins/Replace Ctrl+Insert Instant Screen Saver Ctrl+Shift+ Soft Reset Shift+Scroll...
  • Page 47 Scan Code Action Mode PC Keyboard Enter Desk Accessory Ctrl+← Mode Enter Setup Mode Ctrl+Scroll Lock Exit Setup Mode Pause Enter Clock Ctrl+Shift+F1 Enter Calendar Ctrl+Shift+F2 Enter Calculator Ctrl+Shift+F3 Enter ASCII Chart Ctrl+Shift+F4 Enter Diagnostics Ctrl+Shift+F5 Exit Any Desk Accessory Next Page Ctrl+Page Down Previous Page...
  • Page 48 NOTES: This key has this function only if “F1 to F5 keys” = Local in Setup. See Chapter 3, “Using Setup” (page 16). ** For this function to work, the Compose key selection (in the F5 setup menu) must be equal to Alt. *** By default, Funct = Alt in the F5 (Keys) menu.
  • Page 49: Page Configurations

    Page Configurations Number of Pages Lines per Page 80/132 2 (24/176) 2 (25/175) 2 (42/158) 2 (43/157) Note: When a page length (in the first column) is preceded by an asterisk (*),two pages are available. The first page contains the selected number of lines and the second page contains the remaining allowable lines in memory.
  • Page 50: Technical Support

    Technical Support Questions about this product should be directed to the Technical Support Department of the distributor from which you obtained your Boundless Technologies equipment. When requesting assistance, please have all pertinent information available including any error messages that may have appeared either on the terminal or the host.
  • Page 51: Index

    Index Accessories, Desk, 32 Accessory Window Exiting, 33 Moving, 33 Accessory Windows Blocking Access, 33 Accessory, Desk ASCII Chart, 36 Calculator, 35 Calendar, 33 Clock, 34 Diagnostic Window, 36 Accessory, Desk, Menu, 32 Action Fields, 16 ANSI Emulations (F9 - Emulation Menu), 27 Answerback Menu (F11), 28 ASCII Chart (Desk Accessory), 36 ASCII Emulation (F9 - Emulation Menu), 26...
  • Page 52 Setting Connection B (Host DTE), 12 Setting Connection C (RS-232 with Modem), 12 Setting Connection D (RS-232-C with Modem), 12 Setting Connection E (Printer), 12 Setting Connection F (RS-232-C Printer), 12 Setting Connections G and H (Parallel Printer), 12 Setting Physical Connections, 11 Setting the No Printer Option, 11 Using Communications Setup, 12 Using Emulation Setup, 13...
  • Page 53 Understanding Communications, 7 Screen Display and Pages, 10 Usage Notes, 6 User Settings Chart, 15 Using Additional Setup Options (Installing), 13 Communications Setup (Installing), 12 Emulation Setup (Installing), 13 Menus, 16 Setup, 16 Visual Effects of Screen and Page Lengths, 10 Warning Notice, viii Window, Accessory Exiting, 33...
  • Page 54 50 Engineers Lane, Unit 2 http://www.boundless.com Farmingdale, NY *598-0013003* 598-0013003 11735-1208 Part Number:...
