Daewoo COMPACT LYTE User Manual page 6

Selecting Your Wet and Dry Vacuum Cleaner Attachment
Before using the vacuum, attach the appropriate accessory if required as follows:
1. Insert the Crevice Tool (11) or the Rubber Nozzle (12) directly into the Air Outlet (8) of
the vacuum as below:
11
2. Attach the Brush Attachment (14) to the Air Outlet (8) using the Adaptor (13) as below:
14
3. If the Flexible Hose (10) is required to give a longer reach, attach this to the Air Outlet
(8) via the Adaptor (13)
4. Alternatively, the vacuum can be used without any attachment for general cleaning.
Using Your Wet and Dry Vacuum Cleaner
Right: Slide the On/off Switch (2)
forward to power up the vacuum. The
Indicator Light (3) will illuminate green.
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
8
12
13 8
7.4V Compact Lyte Wet & Dry Vacuum Cleaner
FLR00006
User Manual
6
