Stand/Wall Mounting (Type 05 MK2 only)
The Type 05 MK2 speaker is equipped with two M6 (6mm) strew threads on the rear side
for stand/wall mounting. Spacing between the two screws is 60mm. Please contact us for
more information on suitable mounting hardware.
Please refer to the Product Overview for the location of the M6 strew threads.
SHELVING FILTER [dB]
ANALOG/AES
A
NALOG
M -4
ONO L EFT
R
IGHT
ALL "0" and "↑" POSITION = FACTORY SETTING
PUSH
2 1
3
LF RANGE
INP. SENS. [dB] DESK FILTER
0 O
FF
+4 L S
ARGE MALL
M
ED.
-10
TYPE 05 MK2
PUSH
2 1
3
© 2021 HEDD Audio GmbH | Heinz Electrodynamic Designs | www.hedd.audio
M6 Screw Mount
available with Type 05 MK2 only
