HEDD 05 MK2 Operation Manual page 16

Input Selection
ANALOG/AES
A
NALOG
M
ONO
R
For multi-channel audio that exceeds
stereo, for example 5.1 surround sound,
the monitors have to be fed through
the analog XLR input.
Input Sensitivity
The "Input Sensitivity" rotary switch levels the voltage of the analog input. It can be used
to optimize the signal to noise ratio for the A/D converter. In case of weak input signals
the gain can be added for up to +4 dB. In case of very loud signals (>2 V) either -4 or -10
dB gain reduction can be applied to avoid an A/D converter overload.
The setting has no effect when the signal is received through the digital AES input.
Desk Filter
Monitors sitting on meter bridges or desks may suffer by early reflections from the desk
surface that potentially blur the sound. The "Desk Filter" is a 3-position PEQ (Parametric
Equaliser) that minimizes the effect. Please note that we cannot give an exact
recommendation because the acoustical environments play a vital role. Please find out
in how far these filters may improve the sound.
- 16 -
This 4-position rotary switch selects which signal to reproduce.
INP. SENS. [dB]
"Analog" takes an analog signal from a symmetrical source.
The other 3 positions refer to an incoming digital AES signal. Left,
L
EFT
Right or Mono can be extracted from the data.
IGHT
Small
Med.
Large
DESK FILTER
PUSH
2 1
3
ANALOG IN
up to 80 x 150 cm [d x w]
up to 100 x 180 cm [d x w]
for larger consoles or desktops
PUSH
2 1
3
AES IN AES THROUGH
