Getting Started

Make sure the main power switch is in the "0" position, then connect the power cord to the
power socket.
Set the power switch to "1". Please note that the LED becomes green immediately but it
may take up to 15 sec to power up and play music. Warning: High volume may damage your
hearing! Consider lowering the volume first.
Connect your audio source via the balanced XLR socket, then select the desired input with
the ANALOG / AES rotary switch on the back plate (bottom left). For digital AES input,
please choose the signal (left, right, mono).
As there are quite a number of control knobs on the backplate we recommend to start
playing music with all the markers in the "Up" position:

Status LED

The front LED panel of the speaker will indicate its operational status as follows:
The monitors automatically jump into stand-by after 30 minutes. They wake back up when
audio is played.
- 6 -
ALL "0" and "↑" POSITION = FACTORY SETTING
Green Light
power on
Red Light
overload: please decrease the input sensitivity
White Light
stand-by
