G0830

AMI

BIOS Flash

SOP

(with USB HUB)

Date

2019/01/31

Release by

Andy Yao

Version

1.0

Need help?

Do you have a question about the G0830 and is the answer not in the manual?

Page 1 G0830 BIOS Flash (with USB HUB) Date 2019/01/31 Release by Andy Yao Version...
Page 2 Preparation： 1. Bootable USB Flash Disk (FAT32). 2. USB HUB with external power. 3. OTG Cable (USB to Micor USB). 4. USB Keyboard. 5. Flash tool. 6. BIOS files. (1) How to create a bootable USB dongle： 1. Run rufus-3.4.exe on your PC and follow instruction to run process. 2.
Page 3 2. Copy BIOS Flash tool into Bootable USB Flash Disk. 3. Disable Secure Boot. 3.1 Power on G0830 and press Delete key get into BIOS menu. 3.2 Select Secure Boot menu from Security sheet. 3.3 Disable Secure Boot then press F10 to save configuration and exit.
Page 5 4. Turn on G0830 and press F11 get into boot menu. 5. Select “EFI shell” to boot from USB Flash Disk. 6. Type command at shell as below. 5.1：Fs1: 5.2：XXX.nsh(Ex: 027.nsh) 5.3：The device will shutdown once flash process is completed.
Page 7 Warning： 1. Please don’t remove USB dongle or G0830 from USB HUB because the system will not boot anymore. 2. Please reflash BIOS again if process was failed.
