Arbor Technology Gladius G1050 Series User Manual

10.4" intel atom z530p rugged tablet pc
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Gladius G1050 Series
10.4" Intel
Atom™ Z530P
®
Rugged Tablet PC
User's Manual
Version 1.2
2013.06
P/N: 4012105000120P

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Gladius G1050 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Arbor Technology Gladius G1050 Series

Summary of Contents for Arbor Technology Gladius G1050 Series

  • Page 1 Gladius G1050 Series 10.4" Intel Atom™ Z530P ® Rugged Tablet PC User's Manual Version 1.2 2013.06 P/N: 4012105000120P...
  • Page 2 This page is intentionally left blank. - II -...

  • Page 3: Revision History

    Section 1.7 title 2012/03/15 expand description on p.3 The updates include: G1050C is included: The manual title changes to “Gladius G1050 Series User’s Manual“ New manual structure: Changes are applied throughout 2013/06/28 the manual. Section 3.1. Use Touch Screen is newly added.
  • Page 4 This page is intentionally left blank. - ii -...

  • Page 5: Table Of Contents

    Contents Contents Revision History ....................i Contents .......................iii Preface......................vi Copyright Notice....................vi Declaration of Conformity..................vi CE .......................vi FCC Class B ....................vi RoHS ......................vii SVHC / REACH ..................vii Important Safety Instructions ................vii Warning ......................viii General Cleaning Tips..................viii We recommend you to follow the cleaning steps ..........ix Introducing the Rechargeable Battery Pack............ix Disposing of Your Old Computer ................x Symbols Description ...................xi...

  • Page 6: Contents

    Contents 2.7.5. Network with Other Devices .............33 2.8. Dual-Bay External Battery Charger (Optional) ..........34 2.8.1. Overview ..................34 2.8.2. Dimensions ..................35 2.8.3. Specifications ...................36 2.8.4. Charge Batteries ................37 2.8.5. Status LED ..................38 2.9. VESA-Mount Bracket (Optional) ..............39 2.8.1. Overview ..................39 2.8.2. Install ....................39 2.10.
  • Page 7 Contents 3.5.2. Take A Picture ..................72 3.5.3. Shoot A Video ...................72 3.5.4. Configure Video Shooting ..............73 3.6. Use 3.75G (HSUPA) (Configure-to-Order) ..........74 3.7. Use GPS (Configure-to-Order)..............76 3.8. Use RFID Reader (Configure-to-Order) ............81 3.9. Use Barcode Scanner (Configure-to-Order) ..........85 3.9.1. Data Capture ..................85 3.9.2.

  • Page 8: Preface

    Preface Preface Copyright Notice All Rights Reserved. The information in this document is subject to change without prior notice in order to improve the reliability, design and function. It does not represent a commitment on the part of the manufacturer. Under no circumstances will the manufacturer be liable for any direct, indirect, special, incidental, or consequential damages arising from the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 9: Rohs

    -- Consult the dealer or an experienced radio/TV technician for help. RoHS ARBOR Technology Corp. certifies that all components in its products are in compliance and conform to the European Union’s Restriction of Use of Hazardous Substances in Electrical and Electronic Equipment (RoHS) Directive 2002/95/EC.

  • Page 10: Warning

    Preface 10. Remove dirt with a lightly moistened cloth and a mild solvent detergent. Then wipe the cabinet with a soft dry cloth. 11. The openings on the enclosure are for air convection and protect the equipment from overheating. DO NOT COVER THE OPENINGS. 12.

  • Page 11: We Recommend You To Follow The Cleaning Steps

    Preface Try not to put any food, drink or cigarette around the device. Cleaning Tools Although many companies have created products to help improve the process of cleaning your devices and peripherals, users can also use household items to clean their devices and peripherals.

  • Page 12: Disposing Of Your Old Computer

    Preface • Using the Computer for the First Time Be sure to fully charge (approx. 4 hours) the computer when you plug it in for the first time. Long-Term Storage & Maintenance • If you do not plan to use the computer’s battery for more than three months, it is recommended that you store the battery separately, fully charged, and then recharge it every three month.

  • Page 13: Symbols Description

    Preface Symbols Description This symbol of “CAUTION” indicates that there is a danger of injury to the user or a risk of damage to the product, should warning notices be disregarded. Battery Recycle This symbol indicates electrical warning. Change of electric current: Internal: positive current External: negative current Technical Support...
  • Page 14 This page is intentionally left blank. - xii -...

  • Page 15: Chapter 1 - Introduction

    Chapter 1 Introduction Chapter 1 - Introduction - 1 -...

  • Page 16: The Computer

    Introduction 1.1. The Computer The G1050 Series incorporates multiple data readers and powerful networking to deliver uncompromised data capture. Featuring the slim design, high portability and long battery life, the G1050 Series is ideal for mobile POS and logistics application. With this series, users are able to instantly transmit, receive and analyze critical data and eventually enhance the productivity in the vertical markets including healthcare, field...

  • Page 17: Specifications

    Introduction 1.3. Specifications System Intel Atom™ Z530P 1.6GHz processor ® Graphics Controller Intel GMA 500 ® Memory 2GB DDR2 SO-DIMM memory module installed Chipset Intel System Controller Hub US15WPT ® BIOS AMI BIOS Azalia HD Audio: • 1 x integrated microphone; Audio •...
  • Page 18 Introduction Button & Indicator 10 x numeric keys (0 ~ 9) 1 x enter key 1 x 4-way navigation keys 4 x function keys Function Keys 1 x ESC key 1 x backspace key 1 x dot (.) key 1 x brightness control key; Power Button 1 x power on/off button 1 x battery LED...
  • Page 19 Introduction Mechanical & Environmental Operating Temp. -20 ~ 45ºC (-4 ~ 113ºF) Storage Temp. -20 ~ 60ºC (-4 ~ 140ºF) Charging Temp. 0 ~ 40ºC (32 ~ 104ºF) Operating Humidity 10 ~ 95% @ 45ºC (non-condensing) Dimensions 205 x 294 x 25 mm (8.07" x 11.57" x 0.98") (W x D x H) Gross Weight 1.1 kg (2.42 lb) for G1050-Lite or G1050S-Lite...

  • Page 20: Inside The Package

    Introduction 1.4. Inside the Package Upon opening the package, carefully inspect the contents. If any of the items is missing or appears damaged, contact your local dealer or distributor. The package should contain the following items: 1 x G1050-Series computer 1 x Driver CD 1 x User’s Manual 1 x Europe Standard cordset...

  • Page 21: Ordering Information

    Introduction 1.5. Ordering Information 10.4" Intel Atom™ Z530P rugged tablet PC with resistive touch screen, dual ® G1050-Full battery packs, camera, Bluetooth, WiFi, HSUPA, RFID reader and barcode scanner 10.4" Intel Atom™ Z530P rugged tablet PC with resistive touch screen, ®...

  • Page 22: Configure-To-Order Service

    Introduction VSB-100 VESA-75 to VESA-100 Adapter Bracket VMB-1050 VESA Mount Bracket for G1050 Series DTC-1050 G1050 Series Desktop Cradle CHR-1050 Dual Bay External Battery Charger 1.5.2. Configure-to-Order Service Make the computer more tailored to your needs by selecting one or more components from the list below to be fabricated to the computer.
  • Page 23 Introduction SRS-1050 Smart Card Reader and RS-232 2in1 Kit MSR-1050 MSR Module Kit - 9 -...
  • Page 24 This page is intentionally left blank. - 10 -...

  • Page 25: Chapter 2 - Getting Started

    Chapter 2 Getting Started Chapter 2 - Getting Started - 11 -...

  • Page 26: System Overview

    Getting Started 2.1. System Overview Understanding the computer help you jump seamlessly from component to component when using the computer. This section will quickly familiarize you with the computer. 2.1.1. Dimensions The following illustration shows the dimensions of the computer, with the measurements of width, depth, and height called out.

  • Page 27: Tour The Computer

    Getting Started 2.1.2. Tour the Computer The computer has some controls, I/O ports, mechanical parts and status LED lights around its enclosure. The following illustration shows the computer in different views, with all the said components called out. RFID Reader Barcode Scanner (configure-to-order) (configure-to-order)

  • Page 28: Getting Started

    Getting Started • (Physical) Function Keys After the driver for the function keys is installed as described in 2.11.7. Install Function- Keys Driver on page 48, they are able to turn on/off some features of the computer as described in 4.1.2.
  • Page 29 Getting Started - Radio LEDs Printed Subject Color Description Graphic Lights orange when the RFID reader (optional) Yellow is activated. RFID / Lights green when the HSUPA (optional) is Green HSUPA activated. Lights both orange and green when both Yellow & Green modules are activated.

  • Page 30: Top & Bottom Sides

    Getting Started 2.1.2.2. Top & Bottom Sides Barcode Scanner (configure-to-order) 35-pin Pogo Connector for connection with desktop cradle 2.1.2.3. Left & Right Sides Audio-out Jack USB 2.0 port SD/SDHC Slot External Power Jack Hot-swappable Battery 1 port of USB 2.0 (default) or ExpressCard/34 - 16 -...

  • Page 31: Rear View

    Getting Started 2.1.2.4. Rear View Auto Focus Camera Battery Latch Hand Strap External Hot-swappable Battery Integrated 2W Battery Latch Speaker Stylus SIM Card Slot Pin Header to for optional Connect Internal 3G module Battery Pack To install batteries, see 2.2.3. Instructions for Rechargeable Battery Pack on page 22.

  • Page 32: Batteries

    Getting Started 2.2. Batteries The computer is equipped with one 3S1P internal battery, which makes the rechargeable 4S1P external battery hot-swappable. This means users can replace the external battery without turning off the computer. 2.2.1. Install/Replace External Battery To replace the external battery: Disconnect the computer from the external power.
  • Page 33 Getting Started Slide the external battery out of the battery bay. Slide another battery into the battery bay. Slide the two battery latches back to the lock positions. Slide the battery latch to the lock position. Slide the battery latch to the lock position. - 19 -...

  • Page 34: Install/Replace Internal Battery

    Getting Started 2.2.2. Install/Replace Internal Battery Unlike the external battery, the internal battery needs no frequent replacement. However, when it is necessary to replace the internal battery, follow the guide below: Turn off the computer and disconnect the computer from the external power. Remove any peripheral devices connected to the computer.
  • Page 35 Getting Started Find the power connector for the internal battery inside the battery chamber as illustrated above. Have an internal battery. Plug the internal battery’s power cable to the said power connector. Connect the power cable. Fit the internal battery into the chamber. Restore the chamber door.

  • Page 36: Instructions For Rechargeable Battery Pack

    Getting Started 2.2.3. Instructions for Rechargeable Battery Pack Instructions for Rechargeable Battery Pack How to recharge: • To recharge the lithium-ion battery, install the battery the computer and then connect the power adapter to the computer’s power jack. You can find power adapter & cord in accessory box.
  • Page 37 Getting Started How to use: • It’s recommended to supply power via the adapter without the battery installed when you are to use the computer for a long time. And reinstall the battery in the contrary situation. • The lithium-ion battery is currently one of the most popular battery pack. The best advantage is that it has no memory effect, so users needn’t worry about that issue.

  • Page 38: Install Sim Card

    Getting Started 2.3. Install SIM Card For the computer, 3.75G module is optional. Please note the computer will still have a SIM card slot even if the computer isn’t 3G-enabled. However the SIM card slot won’t function. If the computer is 3G-enabled, install a SIM card to the computer so it can network with Turn off the computer and disconnect the computer from the external power.
  • Page 39 Getting Started Find the SIM card slot inside the battery chamber as illustrated above. Have an SIM card. Position the SIM card as the graphic inside the chamber directs. Then click the SIM card into the slot. Click the SIM card into the slot.

  • Page 40: Install Hand Strap

    Getting Started 2.4. Install Hand Strap Attach the hand strap to the rear of the computer to make it easier to hold the computer in one hand. Find the four holes and fasten the strap onto the computer. - 26 -...

  • Page 41: Install Shoulder Strap (Optional)

    Getting Started 2.5. Install Shoulder Strap (Optional) Except hand strap, the computer also provides a shoulder strap (SST-0720) for shoulder-carrying the computer. Install as below: Press one clasp against one upper bumper as illustration until it hooks on the computer tightly. Repeat the same procedure to fasten the opposite end.

  • Page 42: Install Neck Strap (Optional)

    Getting Started 2.6. Install Neck Strap (Optional) To install the neck strap: Untie one end of the neck strap. Thread it through one of the upper corner bumpers of the computer and re-tie the end. Repeat the same action in step 1 to the other end of the neck strap. Wear the neck strap around your neck.

  • Page 43: Desktop Cradle (Optional)

    Getting Started 2.7. Desktop Cradle (Optional) The (optional) desktop cradle is developed for the computer to extend its networking features. The desktop cradle features the following connectors: 2.7.1. Overview Power RJ-45 jack ports port 35-pin POGO connector 2.7.2. Specifications Features & Peripherals Color &...
  • Page 44 Getting Started 2.7.3. Dimensions 177.1 177.1 Unit: mm - 30 -...

  • Page 45: Seat The Computer

    Getting Started 2.7.4. Seat the Computer Follow the guide below to seat the computer into the cradle. Seat the computer into the cradle with a slanted angle. Make sure the 35-pin POGO connector on the computer meet the docking connector in the cradle.
  • Page 46 Getting Started Note: You may notice that there are two small holes beside the POGO connector on the tablet, and two small bulging poles near the POGO connector on the cradle. These will help you fit the computer into the cradle. - 32 -...

  • Page 47: Network With Other Devices

    Getting Started 2.7.5. Network with Other Devices To use the cradle to network with other devices: Use USB cables to connect the computer with the external devices such as CD-ROM, hard disk drives, Power Jack: camera or card reader. To charge the computer, simply use the computer’s power adapter.

  • Page 48: Dual-Bay External Battery Charger (Optional)

    Getting Started 2.8. Dual-Bay External Battery Charger (Optional) This (optional) battery charger features two channels to charge two 4S1P external batteries for the computer. Go through this section to find out more about this battery charger. 2.8.1. Overview Power Jack: To charge batteries, simply use the computer’s power adapter.

  • Page 49: Dimensions

    Getting Started 2.8.2. Dimensions 168.87 42.6 45.1 Unit: mm - 35 -...

  • Page 50: Specifications

    Getting Started 2.8.3. Specifications Features & Peripherals Color & Material Gray, Plastic I/O Ports 1 x DC Plug (Back side) Mechanical & Environmental Charging Temp. 0 ~ 40ºC (32 ~ 104ºF)* Storage Temp. -20 ~ 60°C (-4 ~ 140°F) Operating Humidity 5 to 95% (non-condensing) Dimensions 168.87 x 123.7 x 45.1 mm (6.64”...

  • Page 51: Charge Batteries

    Getting Started 2.8.4. Charge Batteries Follow the guide below to charge batteries using the battery charger. Connect the battery charger to external power by plugging the power cable (with the power adapter) to the charger’s power jack. Put the first battery into one battery channel. Be sure the metallic parts meet each other.

  • Page 52: Status Led

    Getting Started Install another battery, the status LED on the left will light the color as described in 2.8.5. Status LED on page 38. Monitor the charging progress by the color of the LED light. 2.8.5. Status LED The battery charger comes with two status LED lights. When a battery is placed into one battery channel, the responsible LED will light the color according to the battery level as tabulated below.

  • Page 53: Vesa-Mount Bracket (Optional)

    Getting Started 2.9. VESA-Mount Bracket (Optional) Through the VESA-mount bracket (VMB-1050), the computer can be further connected to the wall-mount or RAM ball mount for easier operation. The outer four screw holes are VESA-75 compliant. 2.8.1. Overview connect RAM ball mount 2.8.2.
  • Page 54 Getting Started When mounting the computer, align the two holes at the computer’s bottom with the two positioning columns on the VESA-mount bracket. After the computer is mounted, turn the computer over and check if the access to the POGO connector is clear. Rotate the knob tightly to fix the computer to the VESA-mount bracket.

  • Page 55: Vesa-75 To Vesa-100 Adapter (Optional)

    Getting Started 2.10. VESA-75 to VESA-100 Adapter (Optional) Further to the VESA-mount bracket as mentioned in 2.9. VESA-Mount Bracket (Optional) on page 39, use an adapter bracket (VSB-100) to make the computer compatible with VESA-100. To use the adapter bracket, lock the bracket unto the VESA-mount bracket as illustrated below.

  • Page 56: Driver Installation

    Getting Started 2.11. Driver Installation The computer supports Windows 7 and Windows XP and comes pre-installed with Windows 7. Find the necessary device drivers on the CD that comes with your purchase. 2.11.1. Installation Sequence Always follow the sequence below to install the drivers to prevent errors: Chipset →...

  • Page 57: Start To Install

    Getting Started 2.11.2. Start to Install Before installing the drivers (and utilities), prepare the following: a USB keyboard a USB CD-ROM drive Follow the guideline below to install device drivers and utilities: Connect the computer to external power by the power cable and adapter included in the accessory box.
  • Page 58 Getting Started Power on the computer if it isn’t powered on yet. Insert the driver CD to the CD-ROM drive. Insert the driver CD to the CD-ROM drive In a few seconds, a dialog opens asking whether to auto-run the driver CD or open the CD contents in Windows Explorer.

  • Page 59: Install Chipset Driver

    Getting Started Click/tap Win7 Driver Install. Click/tap the Browse CD button to view the CD contents in Windows Explorer. A list of device drivers then opens onscreen. Click on the title of a driver to install it. Always follow the sequence described in 2.11.1.

  • Page 60: Install Graphics Driver

    Getting Started 2.11.4. Install Graphics Driver To install the graphics driver: Launch the driver installer as described in 2.11.2. Start to Install on page open the driver list. The driver list then opens onscreen. Click/tap the VGA icon Follow the onscreen instructions to proceed. 2.11.5.

  • Page 61: Install Touch Screen Driver

    Getting Started 2.11.6. Install Touch Screen Driver To install the touch screen driver: Launch the driver installer as described in 2.11.2. Start to Install on page open the driver list. The driver list then opens onscreen. For Windows 7, click/tap the Resistive Touch icon if the computer is powered by resistive touch.

  • Page 62: Install Function-Keys Driver

    Getting Started 2.11.7. Install Function-Keys Driver To install the function-key driver: Launch the driver installer as described in 2.11.2. Start to Install on page open the driver list. The driver list then opens onscreen. Click/tap the Function keys icon from the driver list. Follow the onscreen instructions to proceed.

  • Page 63: Install Wifi Driver

    Getting Started 2.11.8. Install WiFi Driver To install WiFi driver: Launch the driver installer as described in 2.11.2. Start to Install on page open the driver list. The driver list then opens onscreen. Click/tap the WiFi icon Follow the onscreen instructions to proceed. - 49 -...

  • Page 64: Install Bluetooth Driver

    Getting Started 2.11.9. Install Bluetooth Driver To install the Bluetooth driver: Launch the driver installer as described in 2.11.2. Start to Install on page open the driver list. The driver list then opens onscreen. Click/tap the Bluetooth icon Follow the onscreen instructions to proceed. Once the Bluetooth driver is installed, a Bluetooth icon will show up in the notification area with the Bluetooth feature enabled.

  • Page 65: Install 3G Driver & Utility (Configure-To-Order)

    Getting Started 2.11.10. Install 3G Driver & Utility (Configure-to-Order) To install the 3G driver and utility: Launch the driver installer as described in 2.11.2. Start to Install on page open the driver list. The driver list then opens onscreen. Click/tap the 3G icon Follow the onscreen instructions to proceed.

  • Page 66: Install Cradle Lan Driver (Optional)

    Getting Started 2.11.11. Install Cradle LAN Driver (Optional) If you have purchased a cradle for the computer, install the cradle LAN driver on the computer so the computer is able to network with the cradle’s LAN port. To install the cradle LAN driver: Connect the cradle to power supply.
  • Page 67 Getting Started Click/tap the LAN icon Follow the onscreen instructions to proceed. Once the driver is installed, the computer is able to connect to a local area network (LAN) by the cradle’s LAN port. See also 2.7. Desktop Cradle (Optional) on page to know how to use the desktop cradle.

  • Page 68: Install Rfid Reader Driver (Configure-To-Order)

    Getting Started 2.11.12. Install RFID Reader Driver (Configure-to-Order) If the computer has an RFID reader built in, proceed to install the driver for the RFID reader: Launch the driver installer as described in 2.11.2. Start to Install on page open the driver list. The driver list then opens onscreen.

  • Page 69: Program Your Own Rfid Application

    Getting Started 2.11.12.1. Program Your Own RFID Application For your daily RFID data collection, you can install your own application. You can even build your own application by the programming resources included in the driver CD. The programming resources include an reader DLL (dynamic-link library) that covers a variety of reader functions and also a sample application.

  • Page 70: Install Smart Card Reader Driver (Configure-To-Order)

    Getting Started 2.11.13. Install Smart Card Reader Driver (Configure-to-Order) If you have ordered the computer with an Smart Card reader, install the driver for the Smart Card reader: Launch the driver installer as described in 2.11.2. Start to Install on page open the driver list.

  • Page 71: Install Rs232 Driver (Configure-To-Order)

    Getting Started 2.11.14. Install RS232 Driver (Configure-to-Order) If the computer has the RS232 / GPS 2-in-1 module or the RS-232 /Smart Card reader 2-in-1 module, install the RS232 driver prior to make it run. To install the RS232 driver: Launch the driver installer as described in 2.11.2.

  • Page 72: Install Gps Driver & Utility (Configure-To-Order)

    Getting Started 2.11.15. Install GPS Driver & Utility (Configure-to-Order) Since the GPS shares the module with RS232 (GRS-1050 - GPS & RS232 2-in-1 kit), install the GPS driver after the RS232 driver is installed so the two can run without problem.

  • Page 73: Chapter 3 - Use The Computer

    Chapter 3 Use the Computer Chapter 3 - Use the Computer - 59 -...

  • Page 74: Use Touch Screen

    Use the Computer 3.1. Use Touch Screen The computer comes with either a resistive or projected capacitive touch screen. Touch control is the main way and an intuitive way to interact with the computer. Users are able to manipulate icons, graphic buttons, menus, property sheets, the onscreen keyboard or any onscreen items with touch control.

  • Page 75: Text Input

    Use the Computer 3.1.3. Text Input The computer doesn't have a physical keyboard to receive user's text input. To input text on the computer, it relies on either an external USB keyboard, or the "onscreen keyboard", or the O.S.-featured handwriting recognition. 3.1.3.1 Onscreen Keyboard An "onscreen keyboard"...

  • Page 76: Handwriting Recognition

    Use the Computer 3.1.3.2. Handwriting Recognition “Handwriting Recognition” is an input method that interprets and converts handwriting to text. The O.S. features a “writing pad” to get the job done. To launch the O.S.-featured “writing pad”: Open the onscreen keyboard as mentioned in Approach 1 on page 61.

  • Page 77: Use (Physical) Function Keys

    Use the Computer 3.2. Use (Physical) Function Keys Four function keys, F1 through F4, are built on the front bezel of the computer. As long as the driver for these physical function keys is installed as described in 2.11.7. Install Function-Keys Driver on page 48, they are able to turn on/off some features of the computer by default.

  • Page 78: Use Wi-Fi

    Use the Computer 3.3. Use Wi-Fi The computer is built-in with a WiFi module for Wi-Fi networking. Once the driver is installed as described in 2.11.8. Install WiFi Driver on page 49, a WiFi signal strength icon shows up in the notification area. WiFi signal strength icon in the notification area Follow the guide below to connect the computer to a WiFi hotspot:...
  • Page 79 Use the Computer Tap the desired network to connect it. If the network to connect is a secured network, a dialog will open and request for the password. If it is an open network, it will be connected in a few seconds. Enter the password to access the Wi-Fi network.

  • Page 80: Use Bluetooth

    Use the Computer 3.4. Use Bluetooth Bluetooth enables the wireless connection over a short distance about 8 meters. It is specified as a “wireless personal area network” (WPAN). The computer is Bluetooth-enabled to synchronize data with other Bluetooth-capable devices such as PCs, laptops, hands-free, headsets, printers, PDAs and cell phones.

  • Page 81: Bluetooth Device Name

    Use the Computer 3.4.2. Bluetooth Device Name By default, the computer’s Bluetooth device name is the computer name that is viewable at Control Panel | System and Security | System. 3.4.3. Hide/Expose Computer By default, the computer is NOT discoverable by other Bluetooth devices. To hide or expose the computer: Launch the Bluetooth module as described in 3.4.1.
  • Page 82 Use the Computer A context menu opens. Select Open Settings from the context menu. The O.S.-featured Bluetooth Settings then open and show the Options tabbed page. On the Options tabbed page, find the Discovery group box. Select or deselect All Bluetooth devices to find this computer. - 68 -...

  • Page 83: Pair/Connect With Other Bluetooth Devices

    Use the Computer 3.4.4. Pair/Connect with Other Bluetooth Devices Before the computer can connect with other Bluetooth devices, it has to pair with them. To pair/connect with other Bluetooth devices: Launch the Bluetooth module as described in 3.4.1. Launch Bluetooth on page 66.
  • Page 84 Use the Computer An Add a device window opens. Select the Bluetooth device to connect, (sometimes it is necessary to see the document of the Bluetooth device to connect.), and follow the onscreen instructions to proceed. Note: On the computer, the Bluetooth-exchanged files are save to local disk (e.g. C:\) | Users | (your username) | My Documents.

  • Page 85: Use Camera (Configure-To-Order)

    Use the Computer 3.5. Use Camera (Configure-to-Order) The computer can have a 2.0 mega-pixel camera that doubles as a camcorder. Due to the location in the computer’s rear, the camera can help users with photos/video documenting while they are working on the computer’s screen. 3.5.1.

  • Page 86: Take A Picture

    Use the Computer 3.5.2. Take A Picture To take a picture: Launch the camera as described in 3.5.1. Launch Camera on page 71. The camera application program auto launches. And the camera LED lights blue. From the camera application program’s tool bar, tap the take-a-picture icon The camera then proceeds to take a picture and save it to local disk (by default at C:\) | Users | (your username) | My Documents | ccd.) 3.5.3.

  • Page 87: Configure Video Shooting

    Use the Computer 3.5.4. Configure Video Shooting To configure the video shooting: Launch the camera (also the camcorder) as described in 3.5.1. Launch Camera page 71. The camera application program auto launches. And the camera LED lights blue. From the camera application program’s tool bar, tap the configuration icon The Properties sheet opens.

  • Page 88: Use 3.75G (Hsupa) (Configure-To-Order)

    Use the Computer 3.6. Use 3.75G (HSUPA) (Configure-to-Order) With the 3.75G module, the computer is able to be online (connected to the Internet) even when it is on the go. To network with 3.75G, install the driver and utility as described in 2.11.10.
  • Page 89 Utilities And the AirCard Watcher shows “Searching...“ The AirCard Watcher searches for the 3.75G network. As soon as the mobile network is discovered, the AirCard Watcher shows the name of the service provider and a “3G” gauge in its screen, with the signal strength bars in green.

  • Page 90: Use Gps (Configure-To-Order)

    Utilities 3.7. Use GPS (Configure-to-Order) With the GPS module, the computer is able to discover your location on earth. The GPS module is a GPS receiver that needs no 3G connection for positioning. However it requires a clear view of the sky to be location-aware. When the computer has the GPS and RS232 2-in-1 module, some drivers are needed to make them run.
  • Page 91 Utilities Assign a function key to launch the GPS module as described in 4.1.2. Use ARBOR System Suite on page 91. Launch the GPS module by hitting the function key. The system shows that GPS is on at the bottom-right of the screen.
  • Page 92 Utilities Note u-center only supports the COM settings listed below. Parity None Data Bits Stop Bits Flow Control None Click the down arrow besides the Connect/disconnect button. A list of available COM ports opens. Select the GPS COM port as described in Step 1. - 78 -...
  • Page 93 Use the Computer Click the Autobauding button As soon as u-center is synchronized to the module, the Connect/disconnect button on the Receiver Toolbar will change to green color and the software’s screen will start to show the information about the satellite constellation, signal to noise ratio, time etc.
  • Page 94 Use the Computer To view the NMEA text, click View | Text Console from the menu bar of the u-center. Then a small window “Text Console” will open and show the NMEA text. To conserve power, always power off the GPS module when it isn’t used. - 80 -...

  • Page 95: Use Rfid Reader (Configure-To-Order)

    Utilities 3.8. Use RFID Reader (Configure-to-Order) Once the driver for the RFID reader is installed as described in 2.11.12. Install RFID Reader Driver (Configure-to-Order) on page 54, an RFID NFC Demon shortcut will show up on the desktop and also at Start button | All Programs | RFID | NFC_Demo | DemoAP.
  • Page 96 Utilities In the Interface group box, select USB_HID and then click the Connect button. The Status column then changes to a green “Connected” message, meaning that the RFID reader COM port is opened. From the menu bar, click Mode | Reader. A Reader Mode window opens.
  • Page 97 Utilities Click the Inventory tab. The Inventory tabbed page opens. Click the Start button. The table on the Inventory tabbed page starts to show the column titles including UID No, Read Count and Protocol. And the RFID reader is ready to read any supported RFID tag in range.
  • Page 98 Utilities Find the RFID reader at the upper-right of the computer’s front side. RFID reader Tap (slightly contact) the RFID reader with the RFID tag. The read and decoded data will be displayed in the table. - 84 -...

  • Page 99: Use Barcode Scanner (Configure-To-Order)

    Utilities 3.9. Use Barcode Scanner (Configure-to-Order) If the computer you purchased has a barcode scanner, it can collect barcode data. The barcode scanner is able to read and decode a number of 1D/2D symbologies. See 3.9.2. Supported Symbologies on page 87. 3.9.1.
  • Page 100 Utilities Hit the function key that is assigned to trigger scanning as described in step 1. The system shows that barcode scanner is on , and the scanning light beams. The barcode scanner is ready to read any supported printed barcode within the reach of the scanning light.

  • Page 101: Supported Symbologies

    Utilities 3.9.2. Supported Symbologies See the following table for the 1D/2D symbologies supported by the barcode scanner. Linear Matrix BC412 (requires end-user license from IBM) Aztec China Post Chinese Sensible Code (Han Xin Code) Codabar (NW7) Data Matrix Code 11 Grid Matrix Code Code 128 MaxiCode...
  • Page 102 This page is intentionally left blank. - 88 -...

  • Page 103: Chapter 4 - Utilities

    Chapter 4 Utilities Chapter 4 - Utilities - 89 -...

  • Page 104: Arbor System Suite

    Utilities 4.1. ARBOR System Suite The ARBOR System Suite is an application program to control the computer’s physical function keys F1 through F4. With this ARBOR System Suite, users can associate a function key to turn on/off one of the computer’s features or to launch a specific application program installed on the computer.

  • Page 105: Use Arbor System Suite

    Utilities 4.1.2. Use ARBOR System Suite The ARBOR System Suite is based on grafphic user interface to present a handful of graphic buttons and bars that are tabulated below: Title bar ARBOR System Suite Status bar Graphic / Description Facility Title bar Delivers the title and version of the application program.
  • Page 106 Utilities Associates a function key to turn on/off Bluetooth. When the function key is associated with Bluetooth, the Bluetooth graphic becomes highlighted in blue. 3.4. Use Bluetooth on page to know how to use Bluetooth. Associates a function key to turn on/off the camera. When the function key is associated with camera control, the camera graphic becomes highlighted in blue.
  • Page 107 Utilities Associates a function key with a specific application program installed on the computer so the application program can be launched when the function key is hit. When the function key is associated to launch a specific application program, the graphic becomes highlighted in blue. 4.1.3.

  • Page 108: Customize Function Keys

    Utilities 4.1.3. Customize Function Keys To customize a (physical) function key is to associate it to an application program installed on the computer. To associate a function key to a specific application program: Launch ARBOR System Suite as described in 4.1.1.

  • Page 109: Penmount Utilities (Resistive Touch Only)

    Utilities 4.2. PenMount Utilities (Resistive Touch Only) The computer’s resistive touch screen is powered by PenMount touch panel. PenMount features two utilities to configure the touch system: Utility Description Tunes the touch screen for “calibration” or "edge compensation" PenMount (edge sensitivity optimization). See 4.2.1.
  • Page 110 Utilities A summary of these three tabbed pages: Tabbed Page Description Configures the touch device selected. See 4.2.1.2. Device tabbed Device page on page for the settings. Tool Presents the tool(s) to test the performance of the touch screen. About Delivers the developer, version and others of the software.

  • Page 111: Device Tabbed Page

    Utilities 4.2.1.2. Device tabbed page The Device tabbed page helps users calibrate the touch screen. The available calibration is Standard Calibration and Advanced Calibrations. To open the Device tabbed page: Open PenMount Control Panel as described in 4.2.1.1. Launch PenMount Control Panel on page 95.
  • Page 112 Utilities 4.2.1.2.1. Device # Window Access this Device # window to perform Calibration and Edge Compensation for the touch screen. Calibration helps the touch screen recover accuracy after serving for a period of time while Edge Compensation optimizes the mouse pointer’s accuracy at the edges of the touch screen.
  • Page 113 Utilities The available tabbed pages on Device 0 window are summarized below: Tabbed Page Description Calibrates the touch screen by aligning the coordinates of the touch Calibrate screen and those of the display underneath. See Calibrate tabbed page on page 99. Optimizes the mouse pointer’s accuracy at the edges of the touch screen.
  • Page 114 Utilities Proceed to Calibrate Basically the more points are calibrated, the more accuracy is promised. Since different point of calibration are similar, the following will demonstrate the 4-point Standard Calibration only. Open the Calibrate tabbed page as described in Calibrate tabbed page on page The Calibrate tabbed page opens.
  • Page 115 Utilities Use a stylus to accurately tap-and-hold the said red square until a message Lift off to proceed prompts onscreen. Repeat the same action for the other four red squares which are to consecutively show onscreen. Note: If no action is taken within 12 seconds, the calibration will auto-abort. The utility may start over the countdown for an ineffective tap-and-hold.
  • Page 116 Utilities Adjust the mouse pointer accuracy at the screen’s four edges. 0 to 30 configurable. 5 is the default. Tap the OK button to apply the change and quit the setting, or tap Back to Default to recover the defaults. •...

  • Page 117: Tools Tabbed Page

    Utilities 4.2.1.3. Tools tabbed page The Tools tabbed page features the tool(s) to test the performance of the touch screen. Only drawing test is featured for the computer. Open PenMount Control Panel as described in 4.2.1.1. Launch PenMount Control Panel on page 95.
  • Page 118 Utilities Tap the Draw button. A blank screen opens. Drawing tool opens. Draw on the touch screen with a stylus or simply your fingertip. Tap the upper left Menu | Exit to quit the test. - 104 -...

  • Page 119: About Tabbed Page

    Utilities 4.2.1.4. About tabbed page Access this About tabbed page to view the software’s title, version, and support contact info. About tabbed page - 105 -...

  • Page 120: Penmount Gesture

    Utilities 4.2.2. PenMount Gesture PenMount Gesture enables the touch screen to recognize a series of gestures and sets the gestures to launch a variety of functions within the operating system. 4.2.2.1. Launch PenMount Gesture To launch PenMount Gesture: The PenMount Gesture is a utility installed with the touch screen driver. As long as the touch screen driver is installed as described in 2.11.6.
  • Page 121 Utilities Select Enable to make all settings available. Gesture Setting The user interface of PenMount Gesture is explicated as below: Group Setting Description Default Enables/disables the touch screen to Deselected Enable recognize PenMount-supported gestures. (Disabled) Adjusts the gesture sensing time between Sensing 200 ms (0.2 ms) and 2500 ms (2.5 sec).
  • Page 122 Utilities Selects a gesture. The available gestures are: Slash-up Description (Default Gesture values in Windows 7) Zooms in Slash ([Pad] +) Zooms out Slash ([Pad] -) down Rotates counter-clockwise Slash (Ctrl + ,) left Rotates clockwise Slash (Ctrl + .) right Opens the oncreen Gesture...
  • Page 123 Utilities Associates the selected gesture to launch an action from the O.S. The available actions are: • Shutdown (system shutdown), • Send Right Mouse Click Deselected Action • Send Middle Mouse Click (Click (Disabled) mouse scroll wheel) • Mouse Scroll Forward •...
  • Page 124 This page is intentionally left blank. - 110 -...

  • Page 125: Chapter 5 - Bios

    Chapter 5 BIOS Chapter 5 - BIOS - 111 -...

  • Page 126: Bios Main Setup

    BIOS 5.1. BIOS Main Setup The AMI BIOS provides a Setup Utility program for specifying the system configurations and settings. The BIOS RAM of the system stores the Setup Utility and configurations. When you turn on the computer, the AMI BIOS is immediately activated. To enter the BIOS Setup Utility, continuously hit the “Delete”...

  • Page 127: System Time

    BIOS System Time Set the system time. The time format is: Hour : 00 to 23 Minute : 00 to 59 Second : 00 to 59 System Date Set the system date. Note that the ‘Day’ automatically changes when you set the date. The date format is: Day : Sun to Sat Month : 1 to 12...

  • Page 128: Advanced Settings

    BIOS 5.2. Advanced Settings The “Advanced” setting page provides you options to configure the details of your hardware, such as IDE, WLAN/3G, RFID, BT (Bluetooth), CCD, etc. WLAN/3G, RFID, BT, CCD Configuration Attention, even though you set these configurations as enable or disable, after entering into OS, they still work according to Function Key setting described in Section Function Key instead of the configurations in BIOS Setup Utility here.

  • Page 129: Ide Configuration

    BIOS 5.2.1. IDE Configuration When entering the setup, BIOS automatically detects the presence of IDE devices. This item shows status of auto-detected IDE devices and allows you to configure subitems. - 115 -...

  • Page 130: Boot Settings

    BIOS 5.3. Boot Settings This item allows you to set your device’s booting preferences. There are totally three submenus in it, including: - Boot Settings Configuration - Boot Device Priority - Hard Disk Drives - 116 -...

  • Page 131: Boot Settings Configuration

    BIOS 5.3.1. Boot Settings Configuration Quiet Boot This setting determines if the BIOS should replace the normal POST messages with the motherboard or system manufacture’s full-screen logo. When it is enabled, the BIOS will display the full-screen logo during the boot-up sequence, hiding normal POST messages. When it is disabled, the BIOS will display the normal POST messages instead of the full- screen logo.

  • Page 132: Boot Device Priority

    BIOS 5.3.2. Boot Device Priority This setting determines the priority that the BIOS uses to look for a boot device, from which the operating system is loaded during the DOS boot process. - 118 -...

  • Page 133: Hard Disk Drives

    BIOS 5.3.3. Hard Disk Drives This function displays the information of HDD detected. Through it, you can also set boot sequence from available HDD detected. - 119 -...

  • Page 134: Security

    BIOS 5.4. Security Supervisor Password Set Change Supervisor Password to enter and change the options of the setup menus. When you select this function, the following message will appear at the center of the screen to assist you in creating a password. Enter New Password: Type the password up to six characters in length, and press <Enter>.
  • Page 135 BIOS To clear the password, just leave the field blank and press <Enter> when you are prompted to enter a new password. Once the password is cleared, the following message will appear at the center of the screen. Password Uninstalled. - 121 -...

  • Page 136: Exit Options

    BIOS 5.5. Exit Options Save Changes and Exit Pressing <Enter> on this item. Then, a message will prompt you to confirm: Save configuration changes and exit setup? Pressing [OK] stores the selection made in the menus in CMOS - a special section of memory that stays on after you turn your system off.
  • Page 137 BIOS Load Optimal Defaults When you press <Enter> on this item, you get a confirmation dialog box containing a message as below: Load Optimal Defaults? [OK] [Cancel] Pressing [OK] loads the BIOS Optimal Default values for all the setup configurations. - 123 -...

Table of Contents
