- Page 1 MIL-6800 10.4" Core™ 2 Duo Rugged Tablet PC User’s Manual 2011.10...
- Page 2 This page is intentionally left blank.
-
Page 3: Table Of Contents
2.2.4 Illustration of Right View ........11 2.2.5 Illustration of Back View ........11 2.2.6 Important Notice ..........12 Chapter 3 - The Engine of MIL-6800 ....... 13 3.1 System Connector ...........14 Chapter 4 - Maintenance ......... 15 4.1 User Maintenance Instructions ......16 Chapter 5 - Power Management ...... - Page 4 Index 5.2 Monitoring Battery Power ........18 5.3 Low Battery Alarms ..........19 5.4 Battery Charging............19 5.5 When to Replace the Battery ........19 5.6 Heat Considerations ..........20 - II -...
-
Page 5: Copyright Notice
Copyright Notice All Rights Reserved. The information in this document is subject to change without prior notice in order to improve the reliability, design and function. It does not represent a commitment on the part of the manufacturer. Under no circumstances will the manufacturer be liable for any direct, indirect, special, incidental, or consequential damages arising from the use or inability to use the product or documentation, even if advised of the possibility of such damages. -
Page 6: Technical Support
Technical Support If you have any technical difficulties, please consult the user’s manual first ftp://ftp.arbor.com.tw/pub/manual Please do not hesitate to call or e-mail our customer service when you still can not find out the answer. http://www.arbor.com.tw E-mail:info@arbor.com.tw Warranty This product is warranted to be in good working order for a period of one year from the date of purchase. -
Page 7: Ordering Information
SSD 4GB, 60W power adapter and carry bag MIL-6600/MIL-6800 Universal Mounting Kit UMK-6600 MIL-6600/MIL-6800 Mil-Std I/O Cable Kit, including 2 x COM (RS-232C) ports, 1 x VGA (DB-15) port, 1 MCK-6600 x Audio (Speaker-out), 1 x MIC-in, 1 x LAN (Female RJ-45) port, 2 x USB 2.0 ports... - Page 8 This page is intentionally left blank. - iv -...
-
Page 9: Chapter 1 - General Information
General Information Chapter 1 General Information Chapter 1 - General Informa- tion - 1 -... -
Page 10: Introduction
General Information 1.1 Introduction ARBOR would like to thank you for selecting MIL-6800. MIL-6800 is designed as a forward-thinking product that is modularized in design and upgradable. We thank you, our customers, for giving us the inspiration for the following features: •... -
Page 11: Specifications
- Do not step on or place anything on the power cord. - When you use MIL-6800 with an extension cord, make sure that the total ampere ratings of all the devices sharing the extension do not exceed the rating of the extension cord or the rating of the wall outlet. -
Page 12: Mechanical & Environmental
General Information 1.4 Mechanical & Environmental Operating Temp. -40 ~ 60ºC (-40 ~ 140ºF) Storage Temp. -40°C to 70°C (-40°F to 158°F) Storage Humidity 5 ~ 95% (non-condensing) Transit Drop 3ft (1.5 meter) Dimension (W x D x H) 340.3 x 225 x 50.75 mm (13.4" x 8.9" x 2") Net Weight 3.5kg with battery (7.7lb) IP Rating... -
Page 13: Power Adapter & Battery
General Information 1.7 Power Adapter & Battery AC Input 100 ~ 240V 1.7A, 50 ~ 60HzDC Output 60W (Max.), DC 20V@3.25A Adapter Connector Mil-Std D38999 (MS3112E 8-4P) 4-cells Li-battery pack built-in, 19V@3,600mAh, Battery 3 hours battery life 1.8 Dimensions 12.5 24.5 6.75 28.4... - Page 14 General Information This page is intentionally left blank. - 6 -...
-
Page 15: Chapter 2 - System Quick Start
System Quick Start Chapter 2 System Quick Start Chapter 2 - System Quick Start - 7 -... -
Page 16: Packing List
Your system vendor can obtain these approved accessories. If you use items that are not approved for use with MIL-6800, you may cause your MIL-6800 to malfunction, or to emit or receive electro-magnetic radiation in exceed of local regulations. For non-proprietary accessories, such as PC Cards or printers, make sure that the accessories work properly in your MIL-6800 before your purchase. -
Page 17: Getting Start
System Quick Start 2.2 Getting Start Before you power on the system, please refer to the following illustrations, and make sure that you use right connectors with right ports. 2.2.1 Illustration of Front View LED Status Indicator 55-pin MIL-STD Connector DC Power Input Programmable Function Keys Space... -
Page 18: Illustration Of Power Indicators
System Quick Start 2.2.2 Illustration of Power Indicator The power indicators show which power source the system is using. They also show battery status and low battery power alerts. The power indicators remain active and viewable even when the LCD panel is off. Icon Light Description... -
Page 19: Illustration Of Right View
System Quick Start 2.2.4 Illustration of Right View DC Power Input 2.2.5 Illustration of Back View 55-pin MIL-STD Connector Battery Cover DC Power Input - 11 -... -
Page 20: Important Notice
System Quick Start 2.2.6 Important Notice Note: Your vendor should install Windows XP and device drivers ready for your system. If you want to install the different operation system, please connect the external USB CD-ROM to I/O cable’s USB connector, insert the operation system CD to CD-ROM, reboot the system from CD-ROM and follow the on screen instructions, then you are on your way to install the new operation system. -
Page 21: Chapter 3 - The Engine Of Mil-6800
The Engine of MIL-6800 Chapter 3 The Engine of MIL-6800 Chapter 3 - The Engine of Gladius - 13 -... -
Page 22: System Connector
The Engine of MIL-6800 3. 1 System Connector 3.1.1 Power Connector P/N: D38999/ (MS3112E 8-4P) 4-pin DC+20V DC+20V 3.1.2 I/O Connector P/N: D38999/ (20WE35SN) Pin M39029/ 56-348 Signal Signal Signal DCD (COM1) VCC (USB1) TX- (LAN) RX (COM1) P- (USB1) -
Page 23: Chapter 4 - Maintenance
Maintenance Chapter 4 Maintenance Chapter 7 - Maintenance - 15 -... -
Page 24: User Maintenance Instructions
Maintenance 4. User Maintenance Level MIL-6800 system is built as MIL-STD 810F specifications: users are only allowed to do a certain level of maintenance, such as: Battery replacement. If you need more intensive service, please contact your local dealer or distributor. -
Page 25: Chapter 5 - Power Management
Power Management Chapter 5 Power Management Chapter 3 - The Engine of Gladius - 17 -... -
Page 26: Checking The Battery Level
Power Management 5. Power Management 5.1 Checking the Battery Level You can check the remaining battery power in the Windows® battery status indicator located at the lower right-hand corner of the task tray. The Battery status icon only appears in the task tray while the unit is running on the battery power. -
Page 27: Low Battery Alarms
Battery Charge icon will turn off. If your MIL-6800 is turned off, a fully discharged battery will take about 3 hours to recharge. If your MIL-6800 is turned on and is not in suspend mode, it will take about 6~10 hours to recharge the battery. -
Page 28: Heat Considerations
Power Management 5.6. Heat Considerations MIL-6800 processor has been specially designed to consume low power, and generate very low heat. However, working in a hot environment, or work- ing for long periods of time may raise the temperature. If the temperature continues to rise up, processor’s activity will be reduced.
