Wiring Instructions

I M P O R T A N T ! W i r e u s e d f o r t h i s i n s t a l l a t i o n m u s t h a v e a t e m p e r a t u r e r a t i n g o f a t l e a s t 9 0 ° C . b e e i t h e r 1 4 o r 1 6 A W G ,
a n d b e c o l o r c o d e d . S p l i c i n g a l a r m p o w e r w i t h T L S C o n s o l e p o w e r w i l l c a u s e i m p r o p e r o p e r a t i o n o f t h e m o n i t o r .

Wiring Overfill Alarm with Acknowledgement Switch

1 . P u l l t w o w i r e s f r o m t h e s w i t c h t o t h e O v e r f i l l A l a r m .
2 . P u l l t w o w i r e s f o r l i n e a n d n e u t r a l f r o m t h e s w i t c h t o t h e p o w e r p a n e l .
3 . P u l l o n e w i r e f r o m t h e s w i t c h t o t h e T L S C o n s o l e f o r c o n n e c t i o n t o t h e a l a r m r e l a y .
4 . P u l l o n e w i r e f o r l i n e f r o m t h e a l a r m r e l a y i n t h e T L S C o n s o l e t o t h e p o w e r p a n e l .
OFF
5 . T u r n p o w e r O f f a n d c o n n e c t w i r i n g a c c o r d i n g t o t h e w i r i n g d i a g r a m i n F i g u r e 3 a n d T a b l e 1 .
console\ovakwir.eps
Overfill Alarm
(cover open)
Horn Time
Delay Relay
Customer supplied
junction box
To Console Relay -
See Console Connection
Table in this manual
N L
To power panel

Figure 3. Overfill Alarm/Acknowledgement Switch wiring connections

5
ATTACHMENT J
Ack Switch
(cover open)
