Power and Speaker Wiring
Tri-Mode
Tri-mode operation allows you to connect this amplifier to a pair of main speakers
plus a subwoofer on one pair of output channels. The main speakers will operate
in STEREO while the subwoofer simultaneously operates in MONO.
To set up the amplifier to run in this mode, put the crossover switches in the FULL
position. Insert high pass filter capacitors and a low pass filter inductor into the
wiring as shown below. Be sure to check the table at the bottom of this page to
determine the correct capacitor and inductor values for the crossover frequency
you wish to achieve.
Tri-Mode
Component values for
6dB Passive Crossover
FREQUENCY INDUCTOR CAPACITOR
80 Hz
7.5mH
100 Hz
6.5mH
120 Hz
5.5mH
150 Hz
4mH
to REMOTE TURN-ON
terminal of head unit
Battery
OUTLAW MOSFET Amplifier User's Manual - page 10
470uF
330uF
330uF
220uF
Chassis
ground
point
FUSE
SPEAKER
IMPEDANCE
8 OHMS
+
+
4
3
2
CH
CH
CH
+
CH3/4
CH1/2
BRIDGED MODE
High pass filter
crossover
High pass filter
crossover
LEFT
Subwoofer
SPEAKER
IMPEDANCE
8 OHMS
4-Channel Amplifiers
OL1800 and OL2400
RIGHT
Subwoofer
High pass filter
crossover
CH2
–
Speaker
+
–
+
CH1
Speaker
High pass
filter
crossover
+
1
+
CH
SPEAKER
CONNECTIONS
+
BRIDGED MODE
CH3
Speaker
MINIMUM
SPEAKER
IMPEDANCE
4 OHMS
CH4
Speaker
Low pass
filter inductor
MINIMUM
SPEAKER
IMPEDANCE
4 OHMS
Low pass
filter inductor
