User Manual
Service Manual
MODEL: GT1500D
SPECIFICATIONS
Maximum power output (2 Ohms): 800W x 1ch
RMS power Output: 540W x 1ch
Bridged Power Output: 1500W x 1ch
Frequency response: 50 - 150Hz
S/N Ratio: 100dB
Low Pass Crossover (Variable) 50Hz-150Hz
Power Source Voltage: 14.4V
Ground: Negative
External dimensions: 236(W)x55(H)x298(D)mm
Advertisement
Related Manuals for Boss Audio Systems GT1500D
Summary of Contents for Boss Audio Systems GT1500D
-
Page 1: Specifications
Service Manual MODEL: GT1500D SPECIFICATIONS Maximum power output (2 Ohms): 800W x 1ch RMS power Output: 540W x 1ch Bridged Power Output: 1500W x 1ch Frequency response: 50 - 150Hz S/N Ratio: 100dB Low Pass Crossover (Variable) 50Hz-150Hz Power Source Voltage: 14.4V... - Page 2 To engineers in charge of repair or inspection of our products. Before repair or inspection, make sure to follow the instructions so that customers and Engineers in charge of repair or inspection can avoid suffering any risk or injury. 1. Use specified parts. The system uses parts with special safety features against fire and voltage.
-
Page 3: Exploded View
EXPLODED VIEW - 3 -... -
Page 4: Printed Circuit Board
PRINTED CIRCUIT BOARD - 1 - 4 -... - Page 5 CIRCUIT DIAGRAM 1 - 5 -...
- Page 6 CIRCUIT DIAGRAM 2 - 6 -...
- Page 7 PARTS LIST - 1 - 7 -...
- Page 8 PARTS LIST - 2 - 8 -...
- Page 9 PARTS LIST - 3 - 9 -...
- Page 10 PARTS LIST - 4 - 10 -...
