SPECIFICATIONS

Maximum power output (2 Ohms): 300W x 2ch

RMS power Output: 110W x 2ch

Bridged Power Output: 600W x 1ch

Frequency response: 9 - 50KHz

Harmonic distortion: 0.01%

S/N Ratio: 130dB

Power Source Voltage: 14.4V

Ground: Negative

Power consumption: 25A(with 110Wx2 rated output)

External dimensions: 300(W)x65(H)x235(D)mm

- 1 -

Table of Contents

Do you have a question about the CHAOS AMPLIFIERS CH450 and is the answer not in the manual?

Page 1: Specifications
MODEL: CH450 SPECIFICATIONS Maximum power output (2 Ohms): 300W x 2ch RMS power Output: 110W x 2ch Bridged Power Output: 600W x 1ch Frequency response: 9 - 50KHz Harmonic distortion: 0.01% S/N Ratio: 130dB Power Source Voltage: 14.4V Ground: Negative Power consumption: 25A(with 110Wx2 rated output) External dimensions: 300(W)x65(H)x235(D)mm - 1 -...
Page 2 To engineers in charge of repair or inspection of our products. Before repair or inspection, make sure to follow the instructions so that customers and Engineers in charge of repair or inspection can avoid suffering any risk or injury. 1. Use specified parts. The system uses parts with special safety features against fire and voltage.
Page 3 EXPLODED VEIW - 3 -...
Page 4 PRINTED CIRCUIT BOARD - 4 -...
Page 5 CIRCUIT DIAGRAM - 5 -...
Page 6 PARTS LIST - 1 - 5 -...
Page 7 PARTS LIST - 2 - 6 -...
Page 8 PARTS LIST - 3 - 7 -...
