- Page 1 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. Home Decorators Collection BF-20192HAMPTON BAY COLLECTION SINGE TILT-OUT HAMPERS ASSEMBLY INSTRUCTIONS Made In China...
- Page 2 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. T h a n k y o u p u r c h a s i n g t h i s q u a l i t y p r o d u s t . B e s u r e t o c h e c k a l l p a c k i n g m a t e r i a l c a r e f u l l y f o r s m a l l p a r t s , w h i c h m a y h a v e c a m e l o o s e i n s i d e t h e c a r t o n d u r i n g s h i p m e n t .
- Page 3 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. NOTE: UPON OPENING THOROUGHLY CLEAN ALL WOODS SURFACES WITH FURNITURE POLISH TO REMOVE DUST AND DIRT THAT MAY HAVE SETTLE ONTO FINISH DURING SHIPMENT.IN PRODUCT .PLEASE ASSEMBLE ORDER TO PROTECTING THE THE PRODUCT WITH AT LEAST TWO PEOPLE.
- Page 4 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. ASSEMBLE DIRTY CLOTHING BUCKET ASSEMBLE STICK PANEL(H)USING SCREWS(V)AND ATTACH KNOB(O)UISNG SCREWS(P). ATTACH SIDE PANEL(G)USING SCREWS(V). INSERT BASE PANEL(I)INTO SLOT IN SIDE PANEL(G). ATTACH BACK PANEL(H1)USING SCREWS(V).
- Page 5 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. ASSEMBLE BOTTOM PANEL(D) ATTACH THE FEET(M)USING SCREWS(N). PUT THE BAG(J)INTO DIRTY CLOTHING BUCKET.
- Page 6 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. ASSEMBLE THE SIDE PANEL ATTACH BAFFLE PANEL(C)USING DOWEL(Q). ROTATE CAM-BOLTS(L)INTO BOTTOM PANEL(D). PUSH BOLTS INTO HOLES IN SIDE PANEL(B/B1)AND ATTACH USING CAM-LOCKS(K).
- Page 7 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. ASSEMBLE TOP PANEL ROTATE CAM-BOLTS(L)INTO TOP PANEL(A). PUSH BOLTS INTO HOLES IN SIDE PANEL(B/B1)AND ATTACH USING CAM-LOCKS(Q). ATTACH THE BAFFLE PANEL USING SCREWS(V)
- Page 8 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. ASSEMBLE DIRTY CLOTHING BUCKET INSERT THE HIGNE(R)BETWEEN IN HOLES IN SIDE PANEL(G)AND SIDE PANEL(B/B1).
- Page 9 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. ASSEMBLE BACK PANEL ATTACH BACK PANEL(E)USING SCREWS(S).OK! ASSEMBLE COPLETE.
